Manual Pengguna PC Mini LETSUNG Golite11

1. Pengenalan

This manual provides instructions for the setup, operation, maintenance, and troubleshooting of your LETSUNG Golite11 Mini PC. The Golite11 is a compact desktop computer designed for various tasks, from web browsing and office applications to light gaming and multimedia playback. It features an Intel Celeron N4000 processor, 6GB LPDDR4 RAM, and a 128GB M.2 SSD, offering efficient performance in a small form factor.

Image 1.1: LETSUNG Golite11 Mini PC, front view.

2. Apa yang ada di dalam Kotak

Sahkan bahawa semua item terdapat dalam pakej:

• 1 x Golite 11 Mini PC
• 1 x Kabel HDMI
• 1 x VESA Mount
• 1 x Penyesuai Kuasa
• 1 x Panduan Pengguna

3. Produk Lebihview

3.1. Pemproses dan Memori

The Golite11 Mini PC is equipped with an Intel Celeron N4000 processor, providing efficient performance for daily computing tasks. It includes 6GB of LPDDR4 RAM for smooth multitasking.

Image 3.1: Intel Celeron N4000 Processor.

Image 3.2: DDR4 Memory Module.

3.2. Penyimpanan

The device comes with a 128GB M.2 SATA SSD, offering fast boot times and data access. Storage can be expanded up to 512GB.

Image 3.3: M.2 SATA SSD.

3.3. Pelabuhan dan Penyambung

The Golite11 Mini PC features a variety of ports for connectivity:

• Butang Kuasa: Untuk menghidupkan atau mematikan peranti.
• Bicu Fon Kepala 3.5mm: Untuk output audio.
• Port USB 3.2 Gen 1: Multiple ports for connecting peripherals.
• Port LAN RJ45: Untuk sambungan rangkaian berwayar.
• Port HDMI 1.4: Dua port untuk menyambungkan paparan.
• Bicu DC: Untuk input kuasa.

Imej 3.4: Terperinci view of ports and connectors.

4. Persediaan

Follow these steps to set up your LETSUNG Golite11 Mini PC:

1. Sambung ke Paparan: Use the provided HDMI cable to connect the Mini PC to a monitor or TV. The device supports dual displays.
2. Sambung Peranti: Pasangkan papan kekunci dan tetikus USB anda ke port USB yang tersedia.
3. Sambungkan Kuasa: Connect the power adapter to the DC jack on the Mini PC, then plug the adapter into a power outlet.
4. Hidupkan kuasa: Press the power button located on the device. The system will boot up.
5. Persediaan Windows Awal: Follow the on-screen instructions to complete the initial Windows operating system setup, including language, region, and network configuration.

5. Arahan Operasi

5.1. Operasi Asas

Once the initial setup is complete, your Mini PC is ready for use. Navigate the operating system using your connected keyboard and mouse. You can install applications, browse the internet, and perform other computing tasks.

5.2. Persediaan Paparan Dwi

The Golite11 supports connecting two displays simultaneously for an extended desktop experience. Connect a second monitor using the additional HDMI port. The operating system should automatically detect the second display. You can configure display settings (e.g., extend, duplicate) through the display settings in your operating system.

Image 5.1: Dual display setup with the Mini PC.

5.3. Kesambungan Rangkaian

• Wi-Fi: The Mini PC supports WiFi 5.0. To connect to a wireless network, go to your operating system's network settings, select your desired Wi-Fi network, and enter the password.
• Ethernet: For a wired connection, connect an Ethernet cable from your router or modem to the RJ45 LAN port on the Mini PC.

5.4. Peranti Bluetooth

The Mini PC supports Bluetooth 4.2. To pair Bluetooth devices (e.g., headphones, speakers), enable Bluetooth in your operating system's settings, search for devices, and follow the pairing instructions.

6. Penyelenggaraan

6.1. Pembersihan

To maintain optimal performance, keep the Mini PC clean. Use a soft, dry cloth to wipe the exterior. For dust accumulation in vents, use compressed air. Ensure the device is powered off and unplugged before cleaning.

Image 6.1: Internal cooling system for efficient heat dissipation.

6.2. Kemas Kini Perisian

Regularly update your operating system and drivers to ensure security, stability, and optimal performance. Check for updates through your operating system's settings.

6.3. Peluasan Storan

The internal M.2 SATA SSD can be upgraded up to 512GB. Refer to the detailed instructions for internal component access if you plan to upgrade the storage. It is recommended to seek professional assistance for hardware upgrades.

7. Penyelesaian masalah

Jika anda menghadapi masalah dengan Mini PC anda, rujuk masalah dan penyelesaian biasa berikut:

• Tiada Kuasa:
  • Pastikan penyesuai kuasa disambungkan dengan selamat ke PC Mini dan salur keluar kuasa yang berfungsi.
  • Sahkan alur keluar kuasa berfungsi dengan memasang peranti lain.
• Tiada Paparan:
  • Periksa sama ada kabel HDMI disambungkan dengan kukuh pada kedua-dua Mini PC dan monitor.
  • Pastikan monitor dihidupkan dan ditetapkan kepada sumber input (HDMI) yang betul.
  • Cuba kabel HDMI atau monitor lain jika boleh.
• Prestasi Perlahan:
  • Tutup aplikasi yang tidak perlu berjalan di latar belakang.
  • Check for and install any available operating system updates.
  • Pastikan terdapat ruang kosong yang mencukupi pada SSD.
• Isu Ketersambungan Rangkaian:
  • For Wi-Fi, ensure the correct password is entered and the signal strength is adequate.
  • For Ethernet, check the cable connection and ensure your router/modem is working correctly.
  • Mulakan semula penghala/modem anda dan Mini PC.

8. Spesifikasi

9. Waranti dan Sokongan

LETSUNG products are designed for reliability and performance. For warranty information, please refer to the warranty card included with your purchase or visit the official LETSUNG website. For technical support, troubleshooting assistance beyond this manual, or service inquiries, please contact LETSUNG customer support through the contact information provided on the official webtapak atau platform pembelian anda.

Sila simpan bukti pembelian anda untuk tuntutan waranti.
