Arahan Keselamatan Penting
Sila baca dan fahami semua arahan sebelum pemasangan dan penggunaan produk ini. Kegagalan mematuhi arahan ini boleh mengakibatkan kecederaan atau kerosakan pada produk.
- Jauhkan semua bahan pembungkusan dari kanak-kanak.
- Pasang produk di atas permukaan yang lembut dan bersih untuk mengelakkan calar.
- Ensure all parts are securely fastened before use. Periodically check and re-tighten fasteners as needed.
- Do not overload the cabinet. Refer to the specifications section for weight limits.
- This product is designed for indoor use only. Do not expose to moisture or direct sunlight.
- To prevent tipping, always use the included anti-tip kit to secure the cabinet to a wall.
Kandungan Pakej
Sebelum memulakan pemasangan, sahkan bahawa semua komponen yang disenaraikan di bawah ada dan tidak rosak. Jika mana-mana bahagian yang hilang atau rosak, sila hubungi sokongan pelanggan.
- Panel kabinet (atas, bawah, sisi, belakang)
- Door panels (4 pieces)
- Adjustable shelves (quantity as per model)
- Kaki dan tapak kaki boleh laras
- Hardware pack (screws, bolts, magnetic catches, hinges, anti-tip kit)
- Alat pemasangan (cth, kunci Allen)
- Manual arahan
Arahan Perhimpunan
Follow the illustrated instructions provided in the package. All parts are numbered for quick and easy assembly. It is recommended to have two people for assembly.
- Buka bungkus dan Kenalpasti Bahagian: Carefully unbox all components and lay them out. Match each part to the corresponding number in the instruction manual.
- Pasang Bingkai: Attach the side panels to the bottom panel using the provided hardware. Ensure all connections are firm.
- Pasang Panel Belakang: Slide or fasten the back panel into place.
- Lampirkan Panel Atas: Pasangkan panel atas pada bingkai yang telah dipasang.
- Install Legs and Adjustable Feet: Attach the legs to the bottom of the cabinet. Screw in the adjustable feet.
- Pasang Rak: Masukkan rak boleh laras ke dalam kedudukan yang dikehendaki.
- Pasang Pintu: Mount the door hinges to the cabinet frame and then attach the doors.
- Install Magnetic Catches: Secure the magnetic catches to ensure doors close properly.
- Pasang Kit Anti-Petua: Follow the instructions for the anti-tip kit to secure the cabinet to a wall. This is a crucial safety step.
Arahan Operasi
This metal storage cabinet is designed for versatile use in various rooms, offering flexible storage solutions.
Rak boleh laras
The cabinet features adjustable shelves, allowing you to customize the storage space according to your needs. Each shelf level can be adjusted by 2 cm increments.
Magnetic Door Closure
The four doors are equipped with magnetic catches to ensure they remain securely closed, keeping your stored items tidy and out of sight.
Multifunction Perforated Panels
The top sections of the cabinet feature perforated panels. These holes promote air circulation and can also be used to attach hooks (not included) for hanging small items like keys or accessories.
Penempatan Serbaguna
The cabinet's classic color and essential design make it suitable for various environments, functioning effectively as a sideboard in a living room or a storage unit in a kitchen.
Penyelenggaraan dan Penjagaan
Proper care will ensure the longevity and appearance of your SONGMICS storage cabinet.
- Pembersihan: The steel body is easy to maintain. Wipe surfaces with a soft, damp cloth. For stubborn marks, use a mild detergent and dry immediately.
- Pengeringan: Always keep the top surface dry and clean to prevent water stains and ensure durability.
- Elakkan Bahan Kimia Keras: Do not use abrasive cleaners, solvents, or harsh chemicals, as these can damage the powder coating and anti-rust finish.
- Penggunaan Dalaman: This cabinet is not suitable for outdoor use. Protect it from extreme temperatures and humidity.
Menyelesaikan masalah
Jika anda menghadapi sebarang masalah dengan kabinet anda, rujuk masalah dan penyelesaian biasa berikut:
- Kabinet goyah:
Penyelesaian: Ensure all screws and bolts are tightened. Use the adjustable feet at the bottom of the legs to level the cabinet on uneven floors. - Pintu Tidak Tertutup Dengan Betul:
Penyelesaian: Check if the magnetic catches are correctly aligned and securely installed. Adjust hinges if necessary to ensure doors are flush. - Bahagian Hilang atau Rosak:
Penyelesaian: Do not proceed with assembly. Contact SONGMICS customer support immediately for replacement parts. - Kesukaran Semasa Perhimpunan:
Penyelesaian: Review the assembly instructions carefully. Ensure you are using the correct hardware for each step. If issues persist, contact customer support.
Spesifikasi Produk
| Ciri | Spesifikasi |
|---|---|
| Nombor Model | LSC205BD01 |
| Dimensi (L x W x H) | 141 x 40 x 76 cm (55.5 x 15.7 x 29.9 inci) |
| Berat badan | 30.1 kg (66.4 lbs) |
| bahan | Reinforced Steel Alloy, Engineered Wood (top surface) |
| warna | Ink Black + Vintage Coklat |
| Bilangan Pintu | 4 |
| Rak boleh laras | Yes, adjustable by 2 cm increments |
| Static Load Capacity (Top Surface) | 75 kg (165 lbs) |
| Static Load Capacity (Each Shelf) | 20 kg (44 lbs) |
Waranti dan Sokongan
SONGMICS products are designed for quality and durability. This product comes with a standard manufacturer's warranty against defects in materials and workmanship.
- Tempoh Waranti: Please refer to your purchase documentation or the official SONGMICS webtapak untuk butiran dan tempoh jaminan tertentu.
- Sokongan Pelanggan: For any questions, concerns, or assistance with assembly or parts, please contact SONGMICS customer service. Have your model number (LSC205BD01) and purchase information ready.
- Sumber Dalam Talian: Lawati SONGMICS rasmi weblaman web untuk maklumat produk tambahan, Soalan Lazim dan sokongan.
