pengenalan
Thank you for choosing the Oraolo BS15 Portable Bluetooth Speaker. This manual provides essential information for setting up, operating, and maintaining your speaker. Please read it thoroughly before use to ensure optimal performance and safety.
Kandungan Pakej
Sahkan bahawa semua item terdapat dalam pakej anda:
- Oraolo BS15 Bluetooth Speaker × 1
- Kabel Pengecasan Jenis-C × 1
- Manual Pengguna × 1
Image: Contents of the Oraolo BS15 package, including the speaker, charging cable, and user manual.
Produk Selesaiview
Kawalan dan Pelabuhan
Imej: Terperinci view of the Oraolo BS15 speaker, highlighting the button functions and physical dimensions.
- Butang Hidup / Mati: Tekan dan tahan untuk menghidupkan atau mematikan pembesar suara.
- Butang Kelantangan + / Lagu Seterusnya: Short press to increase volume, long press to skip to the next track.
- Butang Kelantangan - / Lagu Sebelumnya: Tekan pendek untuk mengurangkan kelantangan, tekan lama untuk pergi ke trek sebelumnya.
- Suis Mod Cahaya: Press to cycle through different RGB light modes.
- Port Pengecasan Jenis-C: Located under a protective flap for charging.
Ciri-ciri Utama
- 15W Immersive Sound: Delivers clear audio with deep bass.
- Lampu RGB Dinamik: Features 8 radiant hues and 4 pulsing modes that sync with music.
- Kalis Air IPX7: Direka untuk menahan rendaman dalam air sehingga 1 meter selama 30 minit.
- Bluetooth 6.0: Provides stable and fast wireless connection up to 100ft.
- Masa Main 10 Jam: Extended battery life for continuous audio playback.
- Panggilan Bebas Tangan: Built-in noise-cancelling microphone for clear calls.
- Portable Lanyard Design: Integrated lanyard for easy carrying and attachment.
Image: Illustration of the speaker's internal driver, emphasizing its 15W sound capability.
Image: The Oraolo BS15 speaker in a shower environment, illustrating its IPX7 waterproof feature.
Image: The Oraolo BS15 speaker on rough ground, highlighting its anti-impact and shockproof construction.
Image: The Oraolo BS15 speaker attached to a backpack via its silicone lanyard, emphasizing its portable design.
Persediaan
1. Mengisi Speaker
Before first use, fully charge the speaker. Connect the provided Type-C charging cable to the speaker's charging port (located under the protective flap) and the other end to a USB power adapter (not included) or a computer's USB port.
- Lampu penunjuk pengecasan akan menyala semasa pengecasan.
- Lampu akan padam atau bertukar warna apabila dicas sepenuhnya.
Image: The Type-C charging port of the Oraolo BS15 speaker, shown with its protective cover open.
2. Menghidupkan/Mematikan
Tekan dan tahan butang Hidupkan/Mati Kuasa button for approximately 3 seconds until you hear an audible prompt and the indicator lights illuminate.
Untuk mematikan, tekan dan tahan Hidupkan/Mati Kuasa butang lagi selama 3 saat.
3. Berpasangan Bluetooth
The speaker will automatically enter pairing mode when powered on for the first time or if no device is connected. The indicator light will flash, indicating it's ready to pair.
- Pastikan Bluetooth peranti anda didayakan.
- Cari untuk "Oraolo BS15" in your device's Bluetooth settings.
- Select "Oraolo BS15" to connect. A confirmation sound will indicate successful pairing.
- Pembesar suara akan menyambung semula secara automatik ke peranti terakhir yang dipasangkan apabila dihidupkan, jika tersedia.
Image: A smartphone screen showing the Bluetooth pairing process, with the Oraolo BS15 speaker visible and ready for connection.
Arahan Operasi
Main balik Muzik
- Main/Jeda: Tekan pendek Hidupkan/Mati Kuasa butang.
- Kelantangan: Tekan pendek Jilid + butang.
- Perlahankan suara: Tekan pendek Isipadu - butang.
- Lagu Seterusnya: Tekan lama Jilid + butang.
- Trek Sebelumnya: Tekan lama Isipadu - butang.
Panggilan Bebas Tangan
When connected to your smartphone via Bluetooth, you can manage calls directly from the speaker.
- Jawab Panggilan: Tekan pendek Hidupkan/Mati Kuasa butang.
- Tamatkan Panggilan: Tekan pendek Hidupkan/Mati Kuasa butang semasa panggilan.
- Tolak Panggilan: Tekan lama Hidupkan/Mati Kuasa butang.
Image: The Oraolo BS15 speaker facilitating a hands-free call while a user is in a bath, demonstrating its convenience.
Mod Cahaya RGB
The speaker features dynamic RGB lights. Press the Suis Mod Cahaya button to cycle through the available light effects:
- 8 radiant hues
- 4 pulsing modes
Image: The Oraolo BS15 speaker illuminated with a spectrum of colors, demonstrating its customizable RGB light modes.
Pasangan Stereo Tanpa Wayar Sejati (TWS)
You can pair two Oraolo BS15 speakers together for a stereo sound experience.
- Pastikan kedua-dua pembesar suara dihidupkan dan tidak disambungkan ke mana-mana peranti Bluetooth lain.
- Pada satu pembesar suara (ini akan menjadi pembesar suara utama), tekan dua kali pada Hidupkan/Mati Kuasa butang. Ia akan memasuki mod berpasangan TWS.
- Pembesar suara utama akan mencari dan menyambung secara automatik ke pembesar suara kedua.
- Once connected, you will hear a confirmation sound. The primary speaker's indicator light will flash, and the secondary speaker's light will be solid.
- Connect your device to the primary speaker via Bluetooth as described in the "Bluetooth Pairing" section.
Image: Two Oraolo BS15 speakers set up outdoors, demonstrating their ability to be paired for a stereo audio experience.
Penyelenggaraan
Pembersihan
- Lap pembesar suara dengan lembut, damp kain. Jangan gunakan pembersih atau pelarut yang melelas.
- Ensure the Type-C charging port's protective flap is securely closed before cleaning or exposing to water.
Penyimpanan
- Simpan pembesar suara di tempat yang sejuk dan kering jauh dari cahaya matahari langsung dan suhu yang melampau.
- If storing for an extended period, charge the speaker to about 50% every few months to preserve battery life.
Menyelesaikan masalah
| Masalah | Kemungkinan Punca | Penyelesaian |
|---|---|---|
| Speaker tidak dihidupkan. | Bateri lemah. | Cas pembesar suara menggunakan kabel Jenis-C yang disediakan. |
| Tiada bunyi. | Kelantangan terlalu rendah; peranti tidak disambungkan; sumber audio salah. | Increase speaker and device volume; ensure Bluetooth is connected; check audio output settings on your device. |
| Gandingan Bluetooth gagal. | Speaker too far from device; interference; speaker already connected to another device. | Move speaker closer to device; turn off other Bluetooth devices; disconnect from other devices and try pairing again. |
| Kualiti bunyi yang buruk. | Low battery; device too far; interference. | Charge the speaker; move device closer; reduce interference from other wireless devices. |
| Gandingan TWS gagal. | Pembesar suara sudah disambungkan ke peranti lain; prosedur pemasangan yang salah. | Ensure both speakers are disconnected from all devices before initiating TWS pairing. Follow TWS pairing steps carefully. |
Spesifikasi
| Ciri | Perincian |
|---|---|
| Nama Model | BS15 |
| Jenis Pembesar Suara | Pembesar suara mudah alih |
| Kuasa Output Maksimum Pembesar Suara | 15 Watt |
| Versi Bluetooth | 6.0 |
| Julat Maksimum | 30 Meter (100 kaki) |
| Tahap Ketahanan Air | IPX7 (kalis air) |
| Masa bermain | Sehingga 10 jam |
| Port Pengecasan | Jenis-C |
| Dimensi Produk | 4"D x 4"W x 2.3"H (10.2 cm x 10.2 cm x 5.9 cm) |
| Berat Barang | 300 Gram (10.6 auns) |
| bahan | plastik |
| Bateri | 1 AA batteries required (internal rechargeable) |
Waranti dan Sokongan
Oraolo products are designed and manufactured to the highest quality standards. For warranty information or technical support, please refer to the warranty card included in your package or contact Oraolo customer service through the retailer where you purchased the product.
You can also visit the official Oraolo website for further assistance and contact information.
Maklumat Keselamatan
- Do not disassemble, repair, or modify the speaker. This may cause electric shock, malfunction, or fire.
- Jangan dedahkan pembesar suara kepada suhu yang melampau (panas atau sejuk) atau cahaya matahari langsung untuk tempoh yang lama.
- Keep the speaker away from heat sources, such as radiators, stoves, or other heat-producing appliances.
- Ensure the charging port's protective flap is securely closed when the speaker is near water to maintain its IPX7 rating.
- Do not use the speaker at excessively high volumes for extended periods, as this may cause hearing damage.
- Lupuskan pembesar suara dan baterinya secara bertanggungjawab mengikut peraturan tempatan.
