pengenalan
The GODOX TRF TTL Hot Shoe Riser is designed to extend the height of your Godox flash unit when mounted on compatible Fuji cameras. This accessory helps to reduce lens shadow and provides greater flexibility for flash positioning, including bounce flash capabilities. It supports TTL (Through-The-Lens) auto flash and HSS (High-Speed Sync) functions for precise exposure control.
Image: The GODOX TRF TTL Hot Shoe Riser shown mounted on various camera bodies with compatible Godox flash units, illustrating its primary function as a height extender.
Arahan Persediaan
- Attach to Camera: Slide the GODOX TRF Hot Shoe Riser onto your Fuji camera's hot shoe mount until it clicks securely into place. Ensure it is firmly seated to maintain a stable connection.
- Mount Flash Unit: Slide your compatible Godox flash unit (weighing less than 300g) onto the hot shoe of the TRF riser. Secure the flash unit according to its specific mounting mechanism.
- Hidupkan kuasa: Power on your camera and flash unit. The TRF riser will facilitate communication between the camera and flash for TTL and HSS functions, provided the flash unit supports these features.
Imej: Depan view of the GODOX TRF Hot Shoe Riser with a Godox flash attached to a camera, demonstrating the mounted configuration.
Imej: Belakang view of the GODOX TRF Hot Shoe Riser with a Godox flash attached to a camera, showing the connection points.
Arahan Operasi
TTL and High-Speed Sync (HSS) Functionality
The TRF riser supports TTL auto flash and HSS functions when used with compatible Godox flash units and Fuji cameras. This allows for automatic exposure calculation and flash synchronization at shutter speeds faster than the camera's native sync speed.
Note: If using a single-contact flash unit, TTL and HSS functions are not supported. The flash will operate in manual mode.
Image: An illustration demonstrating the TTL Auto Flash mode, which eliminates manual exposure adjustments for precise automatic exposure.
Image: A visual comparison of a scene shot with and without High-Speed Sync (HSS), highlighting how HSS helps avoid overexposure in bright conditions and provides clear fill light.
Angle Adjustment (0-90°)
The TRF riser features a 0-90° tilt adjustment mechanism, allowing you to direct the flash head for both direct and bounce flash photography. This flexibility helps in achieving desired lighting effects and reducing harsh shadows.
Image: A diagram illustrating the 0-90 degree tilt adjustment capability of the TRF riser, along with its dimensions.
Imej: Sisi view of a camera with the GODOX TRF riser and flash unit, demonstrating the flash tilted upwards for bounce lighting.
Lens Shadow Reduction
Mengikut increasing the distance between the flash head and the camera lens by approximately 30mm, the TRF riser effectively reduces lens shadow, especially when using longer lenses. This ensures clearer images without obstructions from the flash unit.
Image: A diagram illustrating how the TRF riser increases flash height by 3cm (1.18 inches), preventing light blockage and reducing shadows.
Penyelenggaraan
- Pembersihan: Use a soft, dry cloth to clean the exterior of the riser. Avoid using harsh chemicals or abrasive materials.
- Storan: Store the riser in a cool, dry place away from direct sunlight and extreme temperatures when not in use.
- Pengendalian: Handle the riser with care to prevent damage to the hot shoe contacts. Avoid dropping or subjecting it to strong impacts.
Menyelesaikan masalah
- Flash not firing or inconsistent firing:
- - Ensure the TRF riser is securely mounted on the camera's hot shoe and the flash unit is securely mounted on the riser.
- - Check that the camera and flash unit are powered on and their batteries are adequately charged.
- - Verify compatibility between your flash unit and camera system. The TRF is designed for Godox flashes and Fuji cameras.
- TTL/HSS functions not working:
- - Confirm that your flash unit supports TTL and HSS functions with your Fuji camera.
- - If using a single-contact flash, TTL and HSS are not supported through the TRF riser. Manual flash operation is required.
- - Check camera and flash settings to ensure TTL/HSS modes are enabled.
- Sambungan longgar:
- - Re-seat the riser on the camera and the flash on the riser. Ensure all locking mechanisms are engaged.
Spesifikasi
| Ciri | Perincian |
|---|---|
| Model | TRF for Fuji |
| Dimensi (L x W x H) | 40.66mm x 32.42mm x 36.3mm (1.60 x 1.28 x 1.43 inci) |
| Berat badan | 26.5g (1.13 auns) |
| Height Increase | Lebih kurang 30mm (1.18 inci) |
| Pelarasan Sudut | 0-90° Tilt |
| Keserasian | Godox iT20F, iT30ProF, and other Godox flash units weighing less than 300g, compatible with Fuji cameras. |
| Komponen yang Disertakan | TRF*1 |
Image: A detailed product information table showing the name, net weight, dimensions, and applicable models for the TR-SCNFO TTL Hot Shoe Riser.
Maklumat Waranti
GODOX products are typically covered by a limited manufacturer's warranty. Please refer to the warranty card included with your purchase or visit the official GODOX webtapak untuk terma dan syarat waranti khusus yang terpakai untuk wilayah anda.
Sokongan Pelanggan
For technical assistance, troubleshooting, or service inquiries, please contact GODOX customer support. You can find contact information on the official GODOX webtapak atau melalui pengedar tempatan anda.
GODOX Rasmi Webtapak: www.godox.com
