AWOW AK10 Pro Mini PC User Manual

1. Pengenalan

This manual provides detailed instructions for setting up, operating, maintaining, and troubleshooting your AWOW AK10 Pro Mini PC. Please read this manual thoroughly before using the device to ensure proper functionality and to maximize your user experience.

2. Apa yang ada di dalam Kotak

Selepas membuka pakej, sahkan bahawa semua item yang disenaraikan di bawah ada dan dalam keadaan baik:

• AWOW AK10 Pro Mini PC
• Penyesuai Kuasa
• Kabel HDMI
• Screws for internal drive installation
• Manual Pengguna (dokumen ini)

3. Produk Lebihview

The AWOW AK10 Pro is a compact and efficient mini PC designed for various applications, including home, office, and educational use. It features an Intel N100 processor, 8GB RAM, and a 256GB PCIe 3.0 SSD, supporting 4K display output and multiple connectivity options.

3.1 Ciri-ciri Utama

• Pemproses: Intel N100 Quad-Core (up to 3.4GHz)
• Ingatan: 8GB DDR4 RAM (3200MHz)
• Storan: 256GB PCIe 3.0 SSD (expandable up to 4TB with M.2 SSD + 2.5" SATA drive)
• Grafik: Intel UHD Graphics with 4K@60Hz dual display support (HDMI 2.0, DisplayPort 1.4)
• Ketersambungan: Dual-band 802.11ac WiFi (2.4GHz/5GHz), Bluetooth 5.2, Gigabit Ethernet
• Pelabuhan: USB 3.2 x2, USB 2.0 x2, HDMI, DisplayPort, RJ45 Gigabit Ethernet, 2-in-1 Audio Jack, DC 12V Power Input, CMOS CLR button

3.2 Pengenalan Komponen

Rajah 3.1: Dalaman view highlighting the Intel N100 processor, 4K@60Hz capability, and 8GB DDR4 memory, along with a CPU Mark Rating comparison.

Rajah 3.2: Depan dan sisi view of the AWOW Mini PC, illustrating its compact dimensions (4.9 x 4.9 x 1.7 inches) and key features like Intel N100 CPU, 8GB DDR4, 256GB SSD, WiFi 5, and Bluetooth 5.0.

Rajah 3.3: Detailed diagram of the AWOW Mini PC's ports, including USB 3.2 x2, 2-in-1 Audio, Power Button, CMOS CLR, DC 12V, RJ45, HDMI, DisplayPort, and USB 2.0 x2.

4. Arahan Persediaan

Follow these steps to set up your AWOW AK10 Pro Mini PC:

1. Sambung ke Kuasa: Insert the DC 12V power adapter into the power input port on the mini PC, then plug the adapter into a power outlet.
2. Sambung ke Paparan: Connect your monitor(s) to the mini PC using either the HDMI 2.0 port or the DisplayPort 1.4. For dual display setup, use both ports.
3. Sambung Peranti: Plug in your USB keyboard and mouse into the available USB 2.0 or USB 3.2 ports.
4. Sambungan Rangkaian (Pilihan): For a wired internet connection, connect an Ethernet cable from your router or modem to the RJ45 Gigabit Ethernet port. For wireless, ensure your WiFi network is available.
5. Hidupkan kuasa: Press the power button located on the front of the mini PC. The power indicator light will illuminate.
6. Persediaan Awal: Follow the on-screen instructions to complete the operating system setup (e.g., Windows 11 initial configuration).

5. Arahan Operasi

5.1 Operasi Asas

• Hidupkan/Mati Kuasa: Press the power button to turn on the device. To shut down, use the operating system's shutdown function. A short press on the power button can also put the PC to sleep.
• Mulakan semula: Gunakan fungsi mula semula sistem pengendalian.
• Akses BIOS: To enter the BIOS settings, press the DEL key repeatedly during startup. To select a boot device, press F7 semasa permulaan.

5.2 Persediaan Paparan Dwi

The AWOW AK10 Pro supports dual 4K@60Hz displays via its HDMI 2.0 and DisplayPort 1.4 outputs. After connecting both monitors, you can configure display settings within your operating system (e.g., Windows Display Settings) to extend or duplicate your desktop.

Rajah 5.1: Example of a dual monitor setup, demonstrating extended desktop functionality for increased productivity.

5.3 Pengembangan Storan

The mini PC's storage can be expanded. It supports an additional 2.5-inch SATA SSD/HDD (up to 2TB) and an M.2 SSD (up to 2TB). To install an additional drive:

1. Ensure the mini PC is powered off and disconnected from the power source.
2. Carefully open the chassis. Refer to the product's official support resources or contact AWOW service for detailed instructions on opening the case to avoid damage.
3. Install the 2.5-inch SATA drive or M.2 SSD into the designated slot. Use the provided screws for secure installation.
4. Close the chassis and reconnect power. The new drive may need to be initialized and formatted within the operating system's Disk Management utility before use.

6. Penyelenggaraan

• Pembersihan: Regularly clean the exterior of the mini PC with a soft, dry cloth. Use compressed air to clear dust from ventilation grilles to ensure proper airflow and prevent overheating. Do not use liquid cleaners directly on the device.
• Kemas Kini Perisian: Pastikan sistem pengendalian dan pemacu anda dikemas kini untuk memastikan prestasi dan keselamatan yang optimum.
• Pengurusan Storan: Periodically check your storage usage and remove unnecessary files untuk mengekalkan kelajuan sistem.
• Keadaan Persekitaran: Operate the mini PC in a well-ventilated area, away from direct sunlight, heat sources, and excessive moisture.

7. Penyelesaian masalah

If you encounter issues with your AWOW AK10 Pro Mini PC, refer to the following common problems and solutions:

Tiada Kuasa / Sistem Tidak Boleh But:

• Pastikan penyesuai kuasa disambungkan dengan selamat pada kedua-dua PC mini dan salur keluar kuasa yang berfungsi.
• Sahkan alur keluar kuasa berfungsi dengan memasang peranti lain.
• If the issue persists, try pressing the CMOS CLR button (if available and accessible) to reset BIOS settings.

Tiada Paparan pada Monitor:

• Check that the HDMI or DisplayPort cable is securely connected to both the mini PC and the monitor.
• Ensure the monitor is powered on and set to the correct input source (HDMI/DP).
• Uji dengan kabel atau monitor yang berbeza jika boleh.

Noisy Fan:

• Ensure the mini PC is placed in a well-ventilated area and that the air vents are not obstructed.
• Clean any dust accumulation from the vents using compressed air.
• If the fan noise is excessive or constant, it may indicate a hardware issue. Contact AWOW support.

External Drives Not Recognized:

• Ensure the external drive is properly connected and powered (if required).
• Check Disk Management in your operating system to see if the drive is detected but needs initialization or formatting.
• Try connecting the drive to a different USB port or another computer to rule out drive issues.

8. Spesifikasi

9. Waranti dan Sokongan

AWOW is committed to providing excellent customer service and technical support for your product.

• Perkhidmatan Selepas Jualan: AWOW offers comprehensive after-sales service.
• Sokongan Teknikal: 24/7 technical support is available from experienced computer experts to assist with any technical issues.
• Local Customer Service: Local customer service is available during business hours (9:00 am to 5:00 pm EST).
• OEM Customization: Pre-sales services for OEM customization are also available.
• For support, please refer to the contact information provided with your purchase or visit the official AWOW webtapak.
