1. Pengenalan
Thank you for choosing the HTC N15 Wireless Clip-On Earbuds. These open-ear earphones are designed to provide audio while allowing you to remain aware of your surroundings. This manual provides detailed instructions for setup, operation, and maintenance to ensure optimal performance and longevity of your device.
Image 1.1: HTC N15 Wireless Clip-On Earbuds and Charging Case.
2. Kandungan Pakej
Sila semak kandungan pakej semasa membuka kotak. Jika ada item yang hilang atau rosak, hubungi sokongan pelanggan.
- 1 Pair HTC N15 Clip-On Earbuds
- 1 Kes Pengecasan
- 1 Kabel Pengecas USB-C
- 1 Manual Pengguna (dokumen ini)
Video 2.1: Unboxing the HTC N15 Wireless Clip-On Earbuds, showing the earbuds, charging case, and USB-C cable.
3. Produk Lebihview
3.1 Earbud Features
- Reka Bentuk Telinga Terbuka: Allows awareness of surroundings.
- Clip-On Fit: Secure and comfortable for various activities.
- Kawalan Sentuh: Intuitive control for audio and calls.
- Mikrofon terbina dalam: For clear communication.
- ringan: Each earbud weighs approximately 4.7g.
- 13mm Driver: For enhanced sound quality.
3.2 Charging Case Features
- Port Pengecasan USB-C: Untuk pengecasan yang mudah.
- Penunjuk Bateri: LEDs show charging status and battery level.
Imej 3.1: Selesaiview of HTC N15 earbuds and charging case, highlighting battery life and Type-C charging port.
4. Persediaan
4.1 Mengecas Fon telinga dan Sarung
Sebelum penggunaan pertama, cas sepenuhnya fon telinga dan bekas pengecas.
- Letakkan fon telinga ke dalam bekas pengecasan.
- Sambungkan kabel pengecas USB-C ke port pengecasan pada kes dan ke sumber kuasa.
- The LED indicators on the case will illuminate to show charging status. A full charge for the case takes approximately 1.5 hours.
- The earbuds provide up to 8 hours of playback on a single charge, and the charging case extends total playtime to 22 hours.
Image 4.1: Visual representation of charging times and battery life for the HTC N15 earbuds and case.
4.2 Berpasangan dengan Peranti
The HTC N15 earbuds use Bluetooth 6.0 for fast and stable connections.
- Pastikan fon telinga dicas dan di dalam bekas pengecasan.
- Buka bekas pengecas. Fon telinga akan memasuki mod berpasangan secara automatik, ditunjukkan oleh lampu LED yang berkelip.
- Pada peranti anda (telefon pintar, tablet, komputer riba), pergi ke tetapan Bluetooth dan hidupkan Bluetooth.
- Cari untuk peranti yang tersedia dan pilih "HTC NE15" daripada senarai.
- Setelah disambungkan, LED fon telinga akan berhenti berkelip dan anda akan mendengar nada pengesahan.
Fon telinga akan menyambung semula secara automatik ke peranti gandingan terakhir apabila dialih keluar daripada sarung, jika Bluetooth didayakan pada peranti.
Image 4.2: The HTC N15 earbuds offer flexible connectivity with various devices including notebooks, TVs, desktops, watches, phones, and iPads.
5. Arahan Pemakaian
For optimal sound and comfort, ensure the earbuds are worn correctly.
- Kenal pasti fon telinga Kiri (L) dan Kanan (R).
- Confirm the direction of the earbud, ensuring the clip is oriented to hook over the top of your ear.
- Gently clip the earbud onto the thinnest part of your ear, sliding it down until it feels secure.
- Adjust the earbud tip to align with your ear canal for the best sound experience and comfort.
Image 5.1: Step-by-step guide on how to properly wear the HTC N15 Clip-On Earbuds for a secure and comfortable fit.
Image 5.2: Illustration of the ergonomic open-ear clip design and wearing tips for optimal sound alignment.
6. Arahan Operasi
The HTC N15 earbuds feature smart touch controls for easy management of audio and calls.
Image 6.1: Diagram illustrating the touch control functions for the HTC N15 earbuds.
6.1 Kawalan Muzik
- Main/Jeda: Double-click either earbud.
- Lagu Seterusnya: Triple-click the Right (R) earbud.
- Lagu Sebelumnya: Triple-click the Left (L) earbud.
- Kelantangan: Click the Right (R) earbud.
- Perlahankan suara: Click the Left (L) earbud.
6.2 Kawalan Panggilan
- Jawab/Tamatkan Panggilan: Click either earbud.
- Tolak Panggilan: Tekan dan tahan salah satu fon telinga selama 2 saat.
6.3 Voice Assistant & Game Mode
- Aktifkan Pembantu Suara: Hold the Left (L) earbud for 2 seconds.
- Mod Permainan: Hold the Right (R) earbud for 2 seconds to activate low-latency mode.
Image 6.2: The HTC N15 earbuds feature a low-latency Game Mode, reducing audio delay to 40ms for an improved gaming experience.
7. Penyelenggaraan
7.1 Pembersihan
- Bersihkan fon telinga dan bekas pengecas dengan kerap menggunakan kain yang lembut, kering dan tidak berbulu.
- Jangan gunakan pembersih yang melelas, alkohol atau pelarut kimia.
- Pastikan sesentuh pengecasan pada kedua-dua fon telinga dan bekas bersih dan kering.
7.2 Penyimpanan
- Simpan fon telinga dalam bekas pengecasnya apabila tidak digunakan untuk melindunginya dan memastikan ia dicas.
- Elakkan menyimpan dalam suhu yang melampau atau kelembapan yang tinggi.
7.3 Tahan Air dan Habuk
The HTC N15 earbuds are rated IP45 for water and dust resistance. This means they are protected against dust ingress and low-pressure water jets from any direction. They are suitable for workouts and light rain but should not be submerged in water.
Image 7.1: The HTC N15 earbuds are IP45 rated, offering protection against dust and water splashes, making them suitable for outdoor activities.
8. Penyelesaian masalah
| Masalah | Kemungkinan Punca | Penyelesaian |
|---|---|---|
| Fon telinga tidak berpasangan | Low battery; Bluetooth off on device; Earbuds not in pairing mode; Interference. | Charge earbuds and case. Ensure Bluetooth is enabled on your device. Place earbuds in case, close, then open to re-enter pairing mode. Move closer to your device. |
| Tiada bunyi atau kualiti bunyi yang buruk | Volume too low; Earbuds not properly seated; Device not connected; Dirty earbuds. | Increase device volume. Adjust earbuds for a proper fit. Reconnect earbuds to your device. Clean earbuds as per maintenance section. |
| Fon telinga tidak dicas | Charging cable not connected properly; Dirty charging contacts; Faulty cable/adapter. | Ensure USB-C cable is securely connected. Clean charging contacts. Try a different USB-C cable or power adapter. |
| Kawalan sentuhan tidak bertindak balas | Earbuds not active; Moisture on touch surface; Software glitch. | Ensure earbuds are active and connected. Wipe touch surface dry. Place earbuds back in case, close, then reopen to reset. |
9. Spesifikasi
| Ciri | Spesifikasi |
|---|---|
| Nama Model | HTC NE15 |
| Versi Bluetooth | 6.0 |
| Teknologi Ketersambungan | Wayarles (Bluetooth) |
| Earbud Type | Clip-On, Open-Ear |
| Saiz Pemandu | 13mm |
| Kaedah Kawalan | Sentuh |
| Mikrofon | terbina dalam |
| Waktu Main Caj Tunggal | Sehingga 8 jam |
| Jumlah Masa Main (dengan kes) | Sehingga 22 jam |
| Case Fast Charging | lebih kurang 1.5 jam |
| Port Pengecasan | USB-C |
| Tahan Air | IP45 (Kalis Air dan Habuk) |
| Berat Earbud | lebih kurang 4.7g (setiap satu) |
| Peranti Serasi | Smartphones, Tablets, Bluetooth-enabled Devices (iOS, Android) |
| UPC | 768649989642 |
10. Waranti dan Sokongan
HTC provides customer support for its products. If you encounter any issues or have questions not covered in this manual, please contact our support team.
- Sokongan Pelanggan: 7*24 Live Chat Support is available. Refer to the product packaging or official HTC weblaman web untuk maklumat hubungan.
- Maklumat Waranti: Please retain your proof of purchase for warranty claims. Specific warranty terms and conditions may vary by region. Refer to the warranty card included in your package or the official HTC webtapak untuk maklumat terperinci.
