1. Pengenalan
Welcome to the JMGO PicoPlay Portable Mini Projector user manual. This guide provides essential information for the safe and efficient use of your new projector. Please read it thoroughly before operation and retain it for future reference.
Maklumat Keselamatan
- Do not look directly into the projector lens when the device is operating.
- Jauhkan peranti daripada air atau cecair lain.
- Pastikan pengudaraan yang betul untuk mengelakkan terlalu panas.
- Gunakan hanya penyesuai kuasa yang disediakan.
- Avoid dropping or subjecting the projector to strong impacts.
2. Produk Lebihview
The JMGO PicoPlay is a versatile portable mini projector designed for immersive entertainment. It combines a 1080P FHD projector, an immersive Bluetooth speaker, and dynamic ambient lighting.
Ciri-ciri Utama:
- Resolusi HD Penuh 1080P: Delivers crisp and clear images up to 200 inches.
- 400 ISO Lumens: Provides bright visuals for various environments.
- Google TV dengan Netflix Berlesen: Access a wide range of streaming apps and content.
- 8W Dolby Audio Speakers: Offers rich and powerful sound.
- 88° Rotatable Gimbal: Allows flexible projection angles from wall to ceiling.
- Automatic Image Optimization: Features auto-focus, auto-keystone correction, and intelligent screen alignment.
- 3D and HDR10 Support: Enhances visual depth and color.
- Reka Bentuk Mudah Alih: Padat dan ringan untuk pengangkutan yang mudah.
- Mod Cahaya Ambien: Customizable lighting to set the mood.
Figure 2.1: The JMGO PicoPlay Portable Mini Projector, showcasing reka bentuk dan lensanya yang padat.
Apa yang ada di dalam Kotak:
- JMGO PicoPlay Projector
- Manual Pengguna
- Alat Kawalan Jauh
- Kord Kuasa
- Optical Filter (for ambient light mode)
- Beg Bawa
Figure 2.2: All items included in the JMGO PicoPlay packaging.
3. Persediaan
3.1 Menghidupkan
- Sambungkan kord kuasa yang disediakan ke port input kuasa projektor.
- Palamkan penyesuai kuasa ke salur keluar dinding.
- Alternatively, connect to a 65W Type-C external battery for portable use (sold separately).
- Tekan butang kuasa pada projektor atau alat kawalan jauh untuk menghidupkan peranti.
Figure 3.1: The PicoPlay projector connected to an external battery for extended use.
3.2 Initial Setup & Remote Pairing
- Sebaik sahaja kuasa dihidupkan buat kali pertama, projektor akan membimbing anda melalui proses persediaan awal.
- Follow the on-screen instructions to select your language and connect to a Wi-Fi network.
- To pair the remote control, press and hold the indicated buttons on the remote until pairing is successful.
- Log in to your Google account to access Google TV features and licensed Netflix.
3.3 Pelarasan Imej
The PicoPlay features Flexismart System for automatic image optimization:
- Autofokus: The projector automatically adjusts the focus for a clear image.
- Pembetulan Auto-Keystone: Corrects distorted images caused by angled projection.
- Penjajaran Skrin Pintar: Automatically aligns the projected image to the screen or wall.
- 88° Rotatable Gimbal: Manually adjust the projection angle by rotating the projector on its base to project from wall to ceiling.
Figure 3.2: Illustration of the automatic focus, keystone correction, and screen alignment.
Figure 3.3: The projector's 88° rotatable gimbal allows for flexible projection angles.
4. Arahan Operasi
4.1 Navigasi dan Kawalan
Control your PicoPlay using the included remote control, the JMGO app, or the touch buttons on the device.
- Kawalan Jauh: Use the directional pad and dedicated buttons for navigation, volume, and quick access to apps like Netflix and YouTube.
- On-Device Touch Buttons: Located on the projector, these buttons allow basic control for volume, power, and menu navigation.
- Apl JMGO: Download the official JMGO app for advanced control and settings adjustments from your smartphone.
Figure 4.1: Various control methods for the PicoPlay projector.
4.2 Ketersambungan
The PicoPlay offers multiple connectivity options:
- HDMI (ARC): Connect external devices like laptops, gaming consoles, or Blu-ray players.
- USB-A: Untuk menyambungkan pemacu USB atau peranti persisian lain.
- USB-C: For power input or data transfer.
- Wi-Fi: Sambung ke rangkaian rumah anda untuk penstriman dan ciri dalam talian.
- Bluetooth: Pair with external speakers or use the PicoPlay as a standalone Bluetooth speaker.
Rajah 4.2: Belakang view of the PicoPlay showing available ports.
4.3 Using Google TV & Streaming
With integrated Google TV, you can access a vast library of entertainment:
- Navigate the Google TV interface to browse movies, TV shows, and apps.
- Enjoy licensed Netflix directly on the projector.
- Use Google Cast to stream content from your smartphone or tablet.
- Utilize Google Assistant for voice commands.
Figure 4.3: The Google TV home screen displaying available streaming applications.
4.4 Mod Pembesar Suara Bluetooth
Transform your PicoPlay into a powerful Bluetooth speaker:
- Place the projector in a vertical position.
- Select Bluetooth speaker mode from the menu or by pressing the dedicated action button.
- Pair your smartphone or other Bluetooth device with the PicoPlay to play music.
Figure 4.4: The PicoPlay in Bluetooth speaker mode, providing immersive audio.
4.5 Ambient Light Mode
Use the optical filter to create dynamic ambient lighting:
- Attach the optical filter to the projector lens.
- Select Ambient Light mode from the settings.
- Customize colors and effects to create your desired atmosphere.
Figure 4.5: The PicoPlay projecting customizable ambient lighting.
5. Penyelenggaraan
5.1 Pembersihan
- Kanta: Gunakan kain lembut dan bebas lin yang direka khusus untuk kanta optik. Jangan gunakan pembersih yang kasar.
- Luaran: Wipe the projector's exterior with a soft, dry cloth. For stubborn marks, use a slightly damp kain dan keringkan serta merta.
- Gril Pengudaraan: Use a soft brush or compressed air to gently remove dust from the ventilation grilles.
5.2 Penyimpanan
When not in use, store the projector in a cool, dry place, away from direct sunlight and extreme temperatures. Use the provided carrying pouch for protection during transport or storage.
6. Penyelesaian masalah
Isu dan Penyelesaian Biasa:
| Isu | Kemungkinan Punca | Penyelesaian |
|---|---|---|
| Tiada Kuasa | Kabel kuasa tidak disambungkan; masalah soket kuasa. | Pastikan kabel kuasa disambungkan dengan kukuh. Cuba soket lain. |
| Tiada Imej | Input source incorrect; cable loose; lens cap on. | Select correct input source. Check HDMI/USB connections. Remove lens cap. |
| Imej Kabur | Out of focus; projector too close/far. | Allow auto-focus to adjust. Adjust projector distance from screen. |
| Imej Herot | Projector not aligned with screen. | Allow auto-keystone correction to adjust. Manually adjust if needed. |
| Tiada Bunyi | Volume too low; external audio device connected. | Increase volume. Disconnect external audio or select internal speakers. |
7. Spesifikasi
| Ciri | Perincian |
|---|---|
| Jenama | JMGO |
| Model | PicoPlay |
| Teknologi Paparan | DLP, LED |
| Resolusi Asli | 1920 x 1080 (HD Penuh) |
| Kecerahan | 400 Lumen ISO |
| Audio | 8W Dolby Audio Speakers |
| Ketersambungan | Wi-Fi, HDMI (ARC), USB-A, USB-C |
| Ciri Khas | HDR10, 3D, APP Control, Google TV, Netflix, 88° Rotatable Gimbal, Auto-focus |
| Dimensi (L x W x H) | 8.5 x 8.5 x 16.6 cm |
| Faktor Bentuk | Mudah alih |
| Penggunaan yang Disyorkan | Home cinema, Gaming, Business, Education |
8. Waranti dan Sokongan
8.1 Waranti Pengeluar
The JMGO PicoPlay projector comes with a 2-year manufacturer warranty. Please retain your proof of purchase for warranty claims.
8.2 Sokongan Pelanggan
For technical assistance, troubleshooting, or warranty inquiries, please contact JMGO customer service. You can find contact information on the official JMGO webtapak atau melalui peruncit anda.
Untuk maklumat lanjut, lawati JMGO Brand Store.
