Innoflame 36-inch Electric Fireplace Instruction Manual

1. Pengenalan

Terima kasih kerana membeliasing the Innoflame 36-inch Electric Fireplace. This manual provides essential information for the safe operation, installation, and maintenance of your new electric fireplace. Please read this manual thoroughly before installation and use, and retain it for future reference.

This electric fireplace offers a realistic flame effect with adjustable colors and brightness, a 1400W heating function, and multiple installation options including freestanding, wall-mounted, and recessed. It is designed to provide supplemental heat and aesthetic ambiance to your living space.

2. Amaran Keselamatan Penting

Failure to follow these instructions may result in fire, electric shock, injury to persons, or property damage.

• Baca semua arahan sebelum menggunakan perapian ini.
• This appliance is hot when in use. To avoid burns, do not let bare skin touch hot surfaces. Keep combustible materials, such as furniture, pillows, bedding, papers, clothes, and curtains at least 3 feet (0.9 m) from the front of the fireplace and keep them away from the sides and rear.
• Amat berhati-hati adalah perlu apabila mana-mana pemanas digunakan oleh atau berhampiran kanak-kanak atau orang yang tidak sah dan apabila pendiangan dibiarkan beroperasi dan tanpa pengawasan.
• Jangan kendalikan mana-mana pendiang api dengan kord atau palam yang rosak atau selepas pendiang api tidak berfungsi, terjatuh atau rosak dalam apa jua cara.
• Jangan gunakan tali di bawah permaidani. Jangan tutup tali dengan permaidani lempar, pelari, atau penutup yang serupa. Susun kord jauh dari kawasan lalu lintas dan di mana ia tidak akan tersandung.
• Sambung ke alur keluar yang dibumikan dengan betul sahaja.
• Jangan masukkan atau biarkan objek asing memasuki sebarang bukaan pengudaraan atau ekzos kerana ini boleh menyebabkan kejutan elektrik atau kebakaran, atau merosakkan pendiang api.
• Untuk mengelakkan kebakaran yang mungkin berlaku, jangan sekat saluran masuk atau ekzos udara dalam apa jua cara. Jangan gunakan pada permukaan lembut, seperti katil, di mana bukaan mungkin tersumbat.
• This fireplace has hot and arcing or sparking parts inside. Do not use it in areas where gasoline, paint, or flammable vapors or liquids are used or stored.
• Gunakan perapian ini hanya seperti yang dijelaskan dalam manual ini. Sebarang penggunaan lain yang tidak disyorkan oleh pengeluar boleh menyebabkan kebakaran, kejutan elektrik, atau kecederaan pada orang.
• Sentiasa pasangkan pemanas terus ke salur keluar dinding/bekas. Jangan sekali-kali gunakan dengan kord sambungan atau paip kuasa yang boleh dipindahkan (alur keluar/jalur kuasa).
• The front tempered glass remains cool to touch, making it safe for households with children and pets.
• The control panel is situated above the fireplace to prevent accidental activation by children.

3. Apa yang ada di dalam Kotak

Carefully unpack all components and ensure you have received all items listed below. If any parts are missing or damaged, please contact customer support.

This image displays all components included in the product package: the main fireplace unit, a remote control, a wall-mounted bracket, table top supports for freestanding use, various screws for installation, and decorative crystals for the ember bed.

• Unit Perapian Elektrik
• Alat Kawalan Jauh
• Wall-Mounted Bracket (attached to fireplace)
• Table Top Supports (for freestanding installation)
• Perkakasan Pemasangan (skru, sauh dinding)
• Kristal Hiasan
• Manual Arahan

4. Arahan Pemasangan

This electric fireplace offers three flexible installation options: freestanding, wall-mounted, or recessed. Choose the method that best suits your space and preferences.

This visual guide demonstrates the three versatile installation options for the electric fireplace: fully recessed into a wall, mounted directly onto a wall surface, and freestanding with its included base.

This technical diagram provides precise dimensions for the 36-inch electric fireplace, detailing measurements for its overall size and specific requirements for recessed and wall-mounted installations.

4.1. Persediaan Umum

• Ensure the power cord is unplugged before any installation.
• Choose a location that is away from water, direct sunlight, and high traffic areas.
• Ensure the chosen location has a grounded 120V AC outlet within reach of the power cord. Do not use an extension cord.
• Kekalkan jarak minimum 3 kaki (0.9 m) daripada bahan mudah terbakar.

4.2. Freestanding Installation

1. Attach the two table top supports to the bottom of the fireplace unit using the provided screws. Ensure they are securely fastened.
2. Place the fireplace on a stable, level surface.
3. Carefully place the decorative crystals into the ember bed area.
4. Plug the fireplace into a grounded 120V AC outlet.

4.3. Pemasangan Dipasang di Dinding

1. Remove the table top supports if they were previously attached.
2. Determine the desired mounting height. Ensure the bottom of the fireplace is at least 20 inches (50.8 cm) from the floor.
3. Locate wall studs for secure mounting. If studs are not available, use appropriate wall anchors (provided) for drywall or masonry.
4. Mark the positions for the wall-mounted bracket (pre-attached to the fireplace). Use a level to ensure the marks are straight.
5. Gerudi lubang pandu pada kedudukan yang ditanda.
6. Securely fasten the wall-mounted bracket to the wall using the provided screws.
7. Carefully lift the fireplace and hook it onto the wall-mounted bracket. Ensure it is securely seated.
8. Carefully place the decorative crystals into the ember bed area.
9. Plug the fireplace into a grounded 120V AC outlet.

4.4. Pemasangan Tersembunyi

1. Remove the table top supports if they were previously attached.
2. Construct a framed opening in the wall according to the dimensions provided in the technical drawing (approximately 33.6 inches wide x 15.8 inches high x 4.9 inches deep). Ensure the opening is structurally sound.
3. Ensure there is a grounded 120V AC outlet inside the framed opening or nearby for the power cord.
4. Carefully slide the fireplace unit into the framed opening.
5. Secure the fireplace to the framing using the appropriate screws through the mounting holes on the sides of the unit.
6. Carefully place the decorative crystals into the ember bed area.
7. Plug the fireplace into a grounded 120V AC outlet.

5. Arahan Operasi

Your Innoflame electric fireplace can be operated using either the touch control panel located on the top of the unit or the included remote control.

Imej ini memberikan yang terperinci view of the fireplace's control panel and the included remote control, indicating the functions of each button for power, heating, flame, ember bed, temperature adjustment, timer, and brightness.

5.1. Hidupkan/Mati Kuasa

• Tekan ke kuasa butang () on the control panel or remote to turn the fireplace ON or OFF.

5.2. Flame Settings

This diagram illustrates the 16 different flame and crystal bed color combinations available for the electric fireplace, demonstrating the variety of ambiance options.

This image shows the five distinct brightness levels (L1 through L5) for the fireplace flames, allowing users to adjust the intensity of the visual effect.

• Nyalaan Hidup/Mati: Tekan ke nyala api butang () to activate or deactivate the flame effect.
• Warna nyalaan: Tekan ke Change Flame Color button (often represented by a color palette icon or similar) on the remote to cycle through 16 different flame color options.
• Ember Bed Color: Tekan ke Warna Katil Bara button (often represented by a crystal icon or similar) on the remote to change the color of the decorative crystals.
• Kecerahan: Tekan ke Kecerahan butang () to adjust the flame brightness through 5 levels (L1-L5).
• Kelajuan Nyalaan: Some models may have a flame speed adjustment. Refer to your remote for a dedicated flame speed button if available.

5.3. Tetapan Haba

This graphic details the key features of the 1400W fireplace heater, including adjustable temperature (64-82°F), overheat protection, realistic flame effects, cool-to-touch tempered glass, a 1-9 hour timer, and low noise operation.

• Heater On/Off: Tekan ke Pemanas butang () to turn the heating function ON or OFF. The heater operates at 1400W.
• Pelarasan Suhu: Gunakan + dan - buttons on the remote to adjust the desired temperature between 64°F and 82°F (18°C and 28°C). The fireplace will automatically maintain the set temperature.
• Pemasa: Tekan ke Pemasa butang () to set an automatic shut-off timer from 1 to 9 hours. Each press increases the timer by one hour.

6. Penyelenggaraan

Penyelenggaraan tetap memastikan jangka hayat dan prestasi optimum perapian elektrik anda.

6.1. Pembersihan

• Always unplug the fireplace from the power outlet and allow it to cool completely before cleaning.
• Panel Kaca: Lap panel kaca dengan lembut, damp cloth. Do not use abrasive cleaners or spray liquids directly onto the glass.
• Permukaan Luaran: Bersihkan permukaan luar dengan lembut, damp kain. Elakkan bahan kimia keras yang boleh merosakkan kemasan.
• Bolong Udara: Use a vacuum cleaner with a brush attachment to gently remove dust and debris from the air intake and exhaust vents. Ensure vents are clear for proper airflow.

6.2. Penyimpanan

• Jika menyimpan pendiang api untuk tempoh yang lama, cabut plagnya dan pastikan ia bersih dan kering.
• Store the fireplace in a cool, dry place, preferably in its original packaging to protect it from dust and damage.

7. Penyelesaian masalah

If you encounter any issues with your electric fireplace, please refer to the following common problems and solutions before contacting customer support.

8. Spesifikasi

This graphic emphasizes the safety and durability aspects of the fireplace, including its premium steel construction, double-layer safety shield, smart overheating prevention, cool-to-touch tempered glass, and the ability to set a timer for worry-free operation.

• Jenama: Innoflame
• Nombor Model: ZF36D03F-S1
• Dimensi (Keseluruhan): 10.7D x 91.4L x 40.6T Sentimeter (4.2D x 36L x 16T Inci)
• Recessed Opening Dimensions: Approximately 33.6W x 15.8H x 4.9D Inches
• Berat Barang: 11.9 kg (26.2 lbs)
• Bahan: Logam, Kaca Tempered
• warna: Hitam
• Sumber Kuasa: Elektrik Bertali
• Output Pemanas: 1400W (5000 BTU)
• Kawasan Pemanasan: Sehingga 400 kaki persegi.
• Termostat Boleh Laras: 64°F - 82°F (18°C - 28°C)
• Tetapan Nyalaan: 16 Multicolor Flame options, 5 Brightness Levels
• Pemasa: 1-9 Jam
• Ciri-ciri Keselamatan: Overheat Protection, Safety Shut Off, Cool-to-Touch Tempered Glass
• Pilihan Pemasangan: Freestanding, Wall Mounted, Recessed

9. Waranti dan Sokongan

For warranty information, technical support, or to inquire about replacement parts, please contact Innoflame customer service. Refer to the product packaging or the official Innoflame weblaman web untuk maklumat hubungan.

Please have your model number (ZF36D03F-S1) and purchase date available when contacting support.
