1. Pengenalan dan Lebihview
The SHARP KI-TX100-H is a high-performance humidifying air purifier equipped with Plasmacluster NEXT technology. It is designed to provide a clean and comfortable indoor environment by purifying air and maintaining optimal humidity levels. This manual provides essential information for the safe and effective use of your appliance.
Figure 1: Sharp KI-TX100-H Humidifying Air Purifier. This premium model features Plasmacluster NEXT technology, aiming for Class 8 cleanroom air quality. It displays key performance metrics such as recommended room size, maximum humidification, maximum airflow, and purification speed.
Ciri-ciri Utama:
- Plasmacluster NEXT (50000): High-density ion generation for superior air purification.
- AI AUTO Mode: Intelligent operation that adjusts purification based on detected particle levels, aiming for Class 8 cleanroom standards.
- AI Monitor: Visualizes indoor particle count and provides notifications for maintenance and water levels.
- Coanda Flow: Efficiently collects dust and particles from distant areas of the room.
- Large Capacity Humidification: Up to 1,100 mL/h for rapid and effective humidification.
- Automatic Humidifying Filter Cleaning: Simplifies maintenance by automatically cleaning the humidifying filter.
- COCORO AIR App: Wireless LAN connectivity for remote control, monitoring, and customized operation.
2. Persediaan
Membongkar dan Meletakkan:
- Keluarkan penulen udara daripada pembungkusannya dengan berhati-hati. Simpan semua bahan pembungkusan untuk pengangkutan atau penyimpanan pada masa hadapan.
- Place the unit on a flat, stable surface. Ensure there is adequate space around the unit for proper airflow (at least 30 cm from walls or furniture).
- The unit is equipped with casters for easy movement. Use the stoppers to secure the unit in place once positioned.
Figure 2: Product dimensions. Height: 700mm, Width: 427mm, Depth: 305mm. Ensure sufficient space for optimal performance.
Pemasangan Penapis:
The air purifier comes with pre-installed filters. Before first use, ensure all protective packaging is removed from the filters.
- Open the back panel of the unit.
- Remove the plastic bags from the pre-filter, deodorizing filter, and HEPA filter.
- Reinstall the filters in the correct order: pre-filter, deodorizing filter, then HEPA filter.
- Close the back panel securely.
Figure 3: Filter system diagram. The unit utilizes a multi-layer filtration system including an electrostatic HEPA filter, a deodorizing filter, and an antibacterial/anti-mold pre-filter to capture various airborne particles and odors.
Water Tank Filling (for Humidification):
- Pull out the water tank from the side of the unit.
- Open the water tank cap and fill with clean tap water. Do not use hot water or water with additives.
- Securely close the cap and reinsert the water tank into the unit until it clicks into place.
3. Arahan Operasi
Hidupkan/Mati Kuasa:
Tekan butang kuasa pada panel kawalan untuk menghidupkan atau mematikan unit.
Mod Pengendalian:
- AI AUTO Mode: This intelligent mode automatically adjusts fan speed and humidification based on detected air quality and humidity levels. It aims to maintain a clean room standard Class 8 level air environment.
- Mod Pembersihan Udara: Operates solely as an air purifier.
- Humidification Mode: Provides humidification. Can be used independently or in conjunction with air purification.
- Plasmacluster Spot Mode: Concentrates Plasmacluster ions in a specific area for intensive deodorization or sterilization.
Figure 4: AI AUTO Mode operation. This mode significantly reduces fine particle counts, demonstrating its effectiveness in achieving high air quality standards.
AI Monitor Display:
The AI Monitor on the unit's display provides real-time information about air quality, humidity, and operational status.
- Particle Count: Displays the current level of fine particles in the air.
- Suhu dan Kelembapan: Shows current room temperature and humidity.
- Makluman Penyelenggaraan: Notifies when filters need cleaning or replacement, or when the water tank is empty.
- Estimated Electricity Cost: Provides an estimate of power consumption.
Figure 5: AI Monitor particle visualization. The display clearly indicates air quality, transitioning from 'dirty' to 'clean' as the unit purifies the air.
Figure 6: AI Monitor notifications. The display provides alerts for humidification status, maintenance schedules, low water levels, and estimated electricity usage. For detailed maintenance instructions, refer to the official support page: Sokongan Tajam.
COCORO AIR App (Wireless LAN):
Connect your air purifier to the COCORO AIR app via wireless LAN for enhanced control and monitoring.
- Kawalan Jauh: Operate the unit from your smartphone.
- Customized Operation: Adjust settings based on your preferences or schedule.
- Pemantauan: View air quality history and receive alerts.
- Mod Haiwan Peliharaan: Special operating modes for households with pets.
- Penyesuaian Suara: Change the unit's voice notifications.
Figure 7: COCORO AIR app interface. The app allows for remote control, customization, and monitoring of the air purifier's functions, including timer settings and maintenance alerts.
4. Penyelenggaraan
Penyelenggaraan tetap memastikan prestasi optimum dan jangka hayat pembersih udara anda.
Pembersihan pra-penapis:
Clean the pre-filter approximately once a month or when indicated by the AI Monitor.
- Matikan unit dan cabut palamnya daripada salur keluar kuasa.
- Remove the back panel and carefully detach the pre-filter.
- Use a vacuum cleaner to remove dust from the pre-filter. For stubborn dirt, wash with water and mild detergent, then air dry completely before reinstalling.
Humidifying Filter Cleaning:
The unit features an automatic cleaning function for the humidifying filter. Perform this when prompted by the AI Monitor or approximately once a month.
- Pastikan tangki air diisi.
- Add a small amount of citric acid (not included) to the water tank.
- Press the 'Internal Humidification Cleaning' button on the control panel. The unit will perform an automatic cleaning cycle.
Figure 8: Automatic humidifying filter cleaning process. Add citric acid to the water tank and press the designated button for automated cleaning. A visual comparison shows the filter before and after cleaning.
Water Tank and Tray Cleaning:
Clean the water tank and humidifying tray regularly to prevent mold and bacteria growth.
- Remove the water tank and humidifying tray.
- Wash with water and a soft brush. For stubborn stains, use a mild detergent.
- Pastikan semua bahagian dibilas dan dikeringkan dengan teliti sebelum dipasang semula.
Figure 9: Features for clean humidification. This includes an Ag+ ion cartridge for water tank hygiene, an antibacterial/anti-mold humidifying filter, and a flat tray design for simplified cleaning.
Penggantian Penapis:
The deodorizing filter and HEPA filter have a lifespan and should be replaced when indicated by the AI Monitor or after several years of use, depending on environmental conditions.
- Refer to the AI Monitor or the COCORO AIR app for filter replacement timing.
- Purchase genuine SHARP replacement filters.
- Follow the installation steps outlined in the 'Filter Installation' section.
5. Penyelesaian masalah
If you encounter any issues with your air purifier, refer to the following common problems and solutions:
| Masalah | Kemungkinan Punca | Penyelesaian |
|---|---|---|
| Unit tidak dihidupkan | Kord kuasa tidak disambung dengan betul; Kuasa terputustage; Unit malfunction | Check power cord connection; Check household circuit breaker; Contact customer support |
| No air purification effect | Filters are dirty or clogged; Filters not installed correctly; Room size exceeds capacity | Clean or replace filters; Reinstall filters correctly; Ensure unit is suitable for room size |
| Tiada pelembapan | Water tank is empty; Humidifying filter is dirty; Humidifying unit not installed correctly | Fill water tank; Clean humidifying filter; Reinstall humidifying unit |
| Bunyi yang tidak biasa | Unit not on a flat surface; Obstruction in fan; Filters not installed correctly | Place on a flat surface; Check for obstructions; Reinstall filters correctly |
| AI Monitor displays an error code | Specific internal error | Rujuk senarai kod ralat terperinci dalam manual penuh atau hubungi khidmat pelanggan. |
If the problem persists after attempting these solutions, please contact SHARP customer support.
6. Spesifikasi
Detailed technical specifications for the SHARP KI-TX100-H Humidifying Air Purifier:
| Ciri | Spesifikasi |
|---|---|
| Nombor Model | KI-TX100-H |
| Jenama | TAJAM |
| Recommended Room Size (Plasmacluster) | ~23 tatami (~38 m²) |
| Air Purification Application Area | ~46 tatami (~76 m²) |
| Maximum Humidification Capacity | 1,100 mL/j |
| Air Purification Time (8 tatami) | 6 minit |
| Tahap Bunyi Operasi | 21~53 dB |
| Noise Level (Rated) | 49 dB |
| Dimensi Produk (D x W x H) | 30.5 cm x 42.7 cm x 70 cm |
| Berat Barang | 14 kg |
| Sumber Kuasa | Elektrik Bertali |
| warna | Kelabu |
7. Waranti dan Sokongan
Maklumat Waranti:
SHARP products are manufactured to the highest quality standards. This product comes with a standard manufacturer's warranty. Please refer to the warranty card included in the original packaging for specific terms, conditions, and duration of coverage. Keep your proof of purchase for warranty claims.
Sokongan Pelanggan:
For technical assistance, troubleshooting, or inquiries regarding your SHARP KI-TX100-H Humidifying Air Purifier, please contact SHARP customer support.
- Sokongan dalam talian: Visit the official SHARP Japan support website for FAQs, manuals, and service information.
- Sokongan Telefon: Contact numbers can be found on the SHARP Japan webtapak atau kad jaminan anda.
- Pusat Perkhidmatan: Locate authorized service centers for repairs or maintenance.
When contacting support, please have your model number (KI-TX100-H) and purchase date available.
