BEE Electric Scooter User Manual

1. Pengenalan

Welcome to the user manual for your new Tomofree BEE Electric Scooter. This manual provides essential information for the safe operation, assembly, maintenance, and troubleshooting of your scooter. Please read this manual thoroughly before using the scooter to ensure optimal performance and safety.

Figure 1: Tomofree BEE Electric Scooter. This image displays the main view of the scooter, highlighting its robust design and the internal components of the motor.

2. Maklumat Keselamatan

Your safety is paramount. Adhere to all local laws and regulations regarding electric scooter usage. Always wear a helmet and appropriate safety gear. Familiarize yourself with the scooter's controls before riding.

• Brek: The dual mechanical disc brakes provide instant stopping power. Practice braking in a safe, open area to understand the scooter's stopping distance.
• Tayar: The 11-inch tubeless off-road tires are designed for superior grip on various terrains. Regularly inspect tires for wear and proper inflation.
• Ketinggian Penunggang: Designed for riders between 5' to 6'3" to ensure proper posture and safe control.
• Had Berat: Jangan melebihi kapasiti beban maksimum 267 lbs (121 kg).
• Keadaan Persekitaran: Avoid riding in heavy rain, snow, or extreme temperatures. The scooter is designed for all-terrain suitability but extreme conditions can affect performance and safety.
• Pencahayaan: Utilize the bright headlight and integrated taillight for visibility, especially during low-light conditions.

Figure 2: Rider demonstrating the scooter's use, with an overlay of key specifications such as battery, motor, max speed, tire size, max load, and slope capability.

3. Kandungan Pakej

Setelah membuka bungkusan, pastikan semua barang yang disenaraikan di bawah ada dan tidak rosak:

• BEE Escooter (main unit)
• Pemegang Telefon x1
• Pengecas x1
• Toolkit Box x1
• Manual Pengguna (dokumen ini)

4. Persediaan dan Pemasangan

Follow these steps to assemble your Tomofree BEE Electric Scooter. It is recommended to watch the assembly video for visual guidance.

4.1. Unboxing dan Pemeriksaan Awal

Carefully remove the scooter and all accessories from the packaging. Inspect for any visible damage during transit. Keep the original packaging for 30 days in case of return.

4.2. Membuka Skuter

1. Place the folded scooter on a flat surface.
2. Cari mekanisme lipatan berhampiran pangkal batang hendal.
3. Release the locking pin/lever and carefully raise the handlebar stem until it locks into the upright position. Ensure it is securely latched.

4.3. Attaching Front Lights

1. Identify the two front lights and their mounting brackets.
2. Align each light with the pre-drilled holes on the front of the scooter's stem.
3. Secure the lights using the provided screws and tools from the toolkit. Ensure they are firmly attached and facing forward.

Figure 3: Installation of the front lights on the scooter's stem, showing the secure attachment process.

4.4. Installing Handlebars

1. Locate the handlebar clamp on the top of the stem.
2. Remove the top plate of the clamp menggunakan sepana Allen yang disediakan.
3. Position the handlebar into the clamp, ensuring it is centered and the brake levers/controls are easily accessible.
4. Replace the top plate and tighten the screws evenly to secure the handlebar.

Figure 4: The process of attaching the handlebars to the scooter's stem, showing the clamp and screw points.

4.5. Attaching Phone Holder (Optional)

1. Assemble the phone holder components, including the clamp and the holder itself.
2. Lampirkan clamp to a suitable position on the handlebar, ensuring it does not obstruct other controls or the display.
3. Secure the phone holder to the clamp.

4.6. Installing Optional Seat

If your model includes an optional seat, follow these steps:

1. Locate the seat mounting point on the rear of the scooter's deck.
2. Insert the seat post into the mounting hole.
3. Adjust the seat height to a comfortable position and secure it using the quick-release lever or tightening mechanism.

Figure 5: The scooter's dual-arm, three-link mechanical suspension system, designed to absorb road vibrations for a comfortable ride.

5. Arahan Operasi

This section covers the basic operation of your BEE Electric Scooter.

5.1. Menghidupkan/Mematikan

Press and hold the power button on the display to turn the scooter on or off. The large mid-mounted display will illuminate, showing battery level, speed, and other indicators.

5.2. Mod Kelajuan

The scooter features 3-speed modes, allowing you to adjust your riding experience:

• Tahap 1: Approximately 13 MPH
• Tahap 2: Approximately 21 MPH
• Tahap 3: Approximately 31 MPH (Max Speed)

Switch between modes using the designated button on the handlebar controls.

5.3. Acceleration and Braking

Use the throttle on the right handlebar to accelerate. Apply the brake levers on both handlebars for controlled stopping. The dual mechanical disc brakes ensure reliable stopping power.

5.4. Sistem Pencahayaan

Activate the front headlight and rear taillight using the light control button on the handlebar. The taillight also functions as a brake indicator, enhancing visibility and safety.

Figure 6: The scooter's lighting system, showing the bright front headlights and the integrated rear taillight with brake indicator function.

6. Penyelenggaraan

Penyelenggaraan tetap memastikan umur panjang dan operasi selamat skuter anda.

• Penjagaan Bateri: The 48V 20Ah battery provides an extended range. Charge the battery fully after each use. Avoid completely draining the battery. Charging time is approximately 7-8 hours.
• Tekanan Tayar: Check tire pressure regularly. Proper inflation is crucial for ride quality and tire lifespan.
• Pemeriksaan Brek: Periodically inspect brake pads and cables for wear. Adjust or replace as needed to maintain effective braking.
• Pembersihan: Bersihkan skuter dengan iklanamp kain. Elakkan menggunakan pancutan air tekanan tinggi secara langsung pada komponen elektrik.
• Pengawal: The controller is mounted on the front side for improved heat dissipation, extending the scooter's lifespan. Keep this area clear of debris.

Figure 7: An illustration showing the internal structure of the 48V 20Ah high-capacity battery, which provides a range of 28-40 miles on a single charge.

7. Penyelesaian masalah

Bahagian ini menangani isu biasa yang mungkin anda hadapi dengan skuter anda.

8. Spesifikasi Teknikal

9. Waranti dan Sokongan

9.1. Maklumat Waranti

The Tomofree BEE Electric Scooter comes with a Waranti Terhad 1 Tahun Pengeluar. This warranty covers defects in materials and workmanship under normal use. Please refer to the warranty card included in your package for full terms and conditions.

Keep your box and foam for 30 days in case of return.

9.2. Sokongan Pelanggan

For technical assistance, troubleshooting, or warranty claims, please contact Tomofree Customer Support. You can find contact information on the official Tomofree webtapak atau melalui platform pembelian anda.

Lawati Tomofree Official Store untuk mendapatkan maklumat lanjut dan sumber sokongan.
