pengenalan
The Woowind Kona Air Electric Air Pump is a versatile and portable device designed for effortless inflation and deflation of various inflatable items. Its compact size, powerful airflow, and integrated lighting make it an ideal companion for outdoor adventures, camping trips, and everyday household needs.
Apa yang ada dalam Kotak
Sahkan bahawa semua item disertakan dalam pakej anda:
- 1 x Woowind Kona Air Electric Air Pump
- 5 x Versatile Nozzle Adapters (Silicone soft, Funnel long, Long, Medium, Short)
- 1 x Kabel Pengecas USB (Jenis-C)
- 1 x Beg Penyimpanan
- 1 x Manual Pengguna (dokumen ini)
Figure 1: Woowind Kona Air pump with included accessories.
Spesifikasi
| Ciri | Perincian |
|---|---|
| Jenama | Woowind |
| Nama Model | Kona Air |
| bahan | plastik |
| Berat Barang | 140 Grams (0.304lb) |
| Dimensi Produk | 2.36"L x 2.17"W x 2.68"H |
| Sumber Kuasa | Dikuasakan Bateri (Boleh dicas semula 2000mAh) |
| Kapasiti Aliran Udara | 200 LPM |
| Mod Operasi | Automatik |
| Mod Lampu LED | 3 Modes (up to 10 hours illumination) |
Figure 2: Compact dimensions of the Woowind Kona Air pump.
Persediaan
Mengecas Pam
Before first use, fully charge your Woowind Kona Air pump. Connect the provided USB Type-C charging cable to the pump's charging port and plug the other end into a compatible USB power source (e.g., wall adapter, power bank, computer USB port). The indicator light will show charging status and turn off when fully charged.
Memasang Nozel
Select the appropriate nozzle adapter for your inflatable item. The pump comes with five versatile nozzles to fit various valve sizes. Firmly insert the chosen nozzle into the inflation or deflation port of the pump.
Figure 3: Woowind Kona Air pump with included accessories for setup.
Arahan Operasi
Fungsi Inflasi
- Attach the correct nozzle to the pelabuhan inflasi (typically located on the side or top, as indicated by an arrow pointing outwards).
- Insert the nozzle firmly into the valve of your inflatable item.
- Press the power button twice quickly to turn on the pump. The pump will begin inflating.
- Monitor the inflation process. Once the item is firm, press the power button twice quickly again to turn off the pump.
- Remove the nozzle and securely close the inflatable item's valve.
Fungsi Deflasi
- Attach the correct nozzle to the pelabuhan deflasi (typically located on the opposite side or bottom, as indicated by an arrow pointing inwards).
- Insert the nozzle firmly into the valve of your inflatable item.
- Press the power button twice quickly to turn on the pump. The pump will begin deflating by sucking air out.
- Once the item is deflated to your satisfaction, press the power button twice quickly again to turn off the pump.
- Remove the nozzle and securely close the inflatable item's valve.
Figure 4: Inflation and Deflation functionality.
LED Campdalam Fungsi Tanglung
The integrated LED light offers three modes for various lighting needs:
- Akhbar Pertama: Low brightness mode for ambient lighting.
- Akhbar Kedua: Medium brightness mode for general illumination.
- Akhbar Ketiga: High brightness mode for maximum visibility.
- Akhbar Keempat: SOS flashing mode for emergencies.
- Akhbar Kelima: Mematikan lampu LED.
Figure 5: Integrated LED Camping Lantern with multiple modes.
Penyelenggaraan
- Pembersihan: Wipe the pump's exterior with a soft, dry cloth. Do not use harsh chemicals or abrasive cleaners.
- Storan: Store the pump and its accessories in the provided storage bag in a cool, dry place away from direct sunlight and extreme temperatures.
- Penjagaan Bateri: To prolong battery life, avoid fully discharging the pump frequently. Recharge it regularly, even if not in use for extended periods.
Menyelesaikan masalah
| Masalah | Kemungkinan Punca & Penyelesaian |
|---|---|
| Pam tidak dihidupkan. | Bateri hampir habis atau habis. Penyelesaian: Recharge the pump fully. Ensure the power button is pressed twice quickly. |
| Inflasi/deflasi perlahan. | Incorrect nozzle size or partially blocked port. Penyelesaian: Ensure the correct nozzle is securely attached and the port is clear of debris. Check battery level. |
| Nozzle does not fit valve. | Using the wrong nozzle adapter. Penyelesaian: Try a different size nozzle from the included set to find the best fit for your item's valve. |
Waranti & Sokongan
The Woowind Kona Air Electric Air Pump comes with a Waranti 24 bulan dari tarikh pembelian, meliputi kecacatan pembuatan.
For technical support, warranty claims, or any inquiries, please contact Woowind customer service through the retailer's platform or visit the official Woowind webtapak untuk maklumat hubungan.
Lawati Woowind Store on Amazon untuk maklumat lanjut.
