FITCAMX Front 4K+Rear 1080P Dash Cam Instruction Manual

Produk Selesaiview

The FITCAMX Dash Cam (Model HD2-06090) is designed for seamless integration into Toyota Camry 2025-2026 models, providing a discreet, OEM-style appearance. This dual-channel system records front video in 4K (2160P) and rear video in 1080P, capturing high-clarity footage. Key features include built-in WiFi for app connectivity, loop recording, and G-sensor collision detection.

Image: FITCAMX Dual Dash Camera system showing front 4K and rear 1080P recording capabilities for Toyota Camry 2025-2026.

Kandungan Pakej

Sahkan bahawa semua komponen terdapat dalam pakej:

• Front Camera Unit
• Kamera Belakang
• Kabel Kamera Belakang
• Y-Cable (Power Adapter)
• Kad SD 128GB
• Pembaca Kad
• Alat Pry
• Manual Pengguna

Image: All components included in the FITCAMX Dash Cam package.

Panduan Pemasangan

This section provides step-by-step instructions for installing your FITCAMX Dash Cam. Ensure the vehicle is turned off before beginning installation.

Pemasangan Kamera Depan

1. Tanggalkan Penutup Belakang: Gently remove the existing back cover from the rearview pemasangan cermin.
2. Remove the Big Cover: Push forward to detach the larger cover from the rearview pemasangan cermin.
3. Unplug the Connector: Locate and unplug the A.C.C. connector from the vehicle's existing wiring.
4. Connect the Y-Cable: Connect the provided Y-cable to the vehicle's wiring and then to the dash cam unit.
5. Transfer Clips: Carefully transfer the two red clips from the original cover to the new dash cam unit.
6. Remove Blue Sticker: Peel off the blue protective sticker from the dash cam lens.
7. Install Dash Cam: Push the dash cam unit back into place, ensuring it clicks securely.
8. Install Back Cover: Reinstall the back cover onto the assembly.

Image: Visual guide for installing the front dash camera unit.

Pemasangan Kamera Belakang

The rear camera can be mounted on the rear windshield or facing the cabin. Before permanent installation, test the rear camera connection to ensure it functions correctly.

• Sambungkan kabel kamera belakang ke unit kamera papan pemuka utama.
• Route the cable neatly along the vehicle's interior trim to the desired mounting location for the rear camera.
• Secure the rear camera in place. The rear camera is bukan kalis air and should be installed inside the vehicle.

Image: Diagram showing rear camera wiring and examples of mounting on the rear windshield or facing the cabin.

Arahan Operasi

Rakaman Automatik

The dash cam automatically powers on and begins recording when the vehicle starts. It will automatically power off when the vehicle is turned off.

Kesambungan WiFi dan Penggunaan Aplikasi

The FITCAMX dash cam features built-in WiFi for connecting to the dedicated FITCAMX mobile application. This allows you to:

• Praview video langsung footage.
• Manage recorded videos.
• Wirelessly transfer important footage ke telefon pintar anda.
• Laraskan tetapan kamera.

Download the FITCAMX app from the App Store (iOS) or Google Play Store (Android). Note that the camera will continue to record automatically even if WiFi is not connected, and it does not affect the normal use of CarPlay or Android Auto.

Image: Smartphone displaying the FITCAMX app interface, connected via WiFi to the dash cam.

Rakaman Gelung

The dash cam utilizes loop recording, which automatically overwrites the oldest footage with new content when the memory card is full. This ensures continuous recording without manual intervention. Recording intervals can be set to 1, 3, or 5 minutes via the FITCAMX app.

Image: Illustration of loop recording, showing older files being overwritten as new footage is recorded.

Sensor-G (Rakaman Kecemasan)

The built-in G-sensor detects sudden collisions or impacts. When an event is detected, the dash cam automatically saves the relevant video footage to a protected folder, preventing it from being overwritten by loop recording. This ensures critical evidence is preserved.

Image: Visual representation of the G-Sensor detecting a collision and locking video footage.

Penyelenggaraan

Penyelenggaraan yang betul memastikan ketahanan dan prestasi optimum kamera papan pemuka anda.

• Pengurusan Kad SD: The dash cam includes a 128GB memory card and supports up to 256GB. Regularly back up important footage and format the SD card periodically (e.g., once a month) to maintain optimal recording performance and prevent data corruption.
• Suhu Operasi: The dash cam is designed to operate within a temperature range of -20°C to 85°C (-4°F to 185°F). Avoid exposing the device to extreme temperatures outside this range for extended periods.
• Pembersihan: Use a soft, dry cloth to clean the camera lenses and the exterior of the unit. Do not use harsh chemicals or abrasive materials.

Menyelesaikan masalah

This section addresses common issues you might encounter with your dash cam.

• Kamera Tidak Dihidupkan:
  • Ensure the Y-cable is securely connected to both the vehicle's power source and the dash cam.
  • Verify that the vehicle's ignition is on, as the camera is designed to activate with the vehicle.
• Isu Sambungan WiFi:
  • Ensure the FITCAMX app is installed and updated to the latest version.
  • Restart your smartphone and the dash cam (by turning the vehicle off and on).
  • Confirm that your phone's WiFi is enabled and connected to the dash cam's network.
• Video Quality Concerns:
  • Pastikan kanta kamera bersih dan bebas daripada kesan kotoran atau cela.
  • Verify that the protective blue sticker has been removed from the lens.
  • Check app settings to confirm recording resolution is set to the highest available (4K front, 1080P rear).
• "SRS AIRBAG LIGHT IS ON" After Installation:
  • If an SRS Airbag warning light appears on your dashboard after installation, it indicates a potential issue with the vehicle's airbag system. This is a critical safety concern.
  • Immediately consult a qualified automotive technician or your vehicle dealership for diagnosis and repair. Do not attempt to drive the vehicle with an active SRS warning light.
• No Parking Mode:
  • This model does not include a parking mode feature by default.
  • For parking monitoring functionality, an additional fuse box cable accessory is required. Cari untuk ASIN: B09PQ9KDYX to order the compatible accessory.

Spesifikasi

Waranti dan Sokongan

FITCAMX is committed to providing reliable products and customer support.

• Sokongan Teknikal: For any questions or technical assistance, please contact FITCAMX customer support for a prompt response.
• Polisi Pemulangan: This product is eligible for a refund or replacement within 30 days of purchase. Refer to your retailer's specific return policy for details.
• Pelan Perlindungan Pilihan: Extended protection plans may be available for purchase to cover your device beyond the standard warranty. Check with your retailer for options such as 2-Year or 3-Year Protection Plans.
