1. Pengenalan
Thank you for choosing the HOMSURE 8000 BTU Portable Air Conditioner. This manual provides important information regarding the safe operation, installation, maintenance, and troubleshooting of your new appliance. Please read this manual thoroughly before using the product and retain it for future reference.
This 3-in-1 unit offers cooling, dehumidifying, and fan modes, designed for rooms up to 350 square feet. It features a quiet operation, remote control, and a 24-hour timer for convenience and energy efficiency.
Rajah 1.1: The HOMSURE Portable Air Conditioner effectively cooling a living space, demonstrating its 8000 BTU capacity for areas up to 350 square feet. This image illustrates the unit's cooling reach within a typical room setting.
Rajah 1.2: The HOMSURE Portable Air Conditioner operating quietly, indicated by a noise level of 53dB, suitable for a peaceful sleeping environment. This image emphasizes the unit's low noise output, ideal for bedrooms.
2. Maklumat Keselamatan Penting
Sentiasa ikuti langkah berjaga-jaga keselamatan asas apabila menggunakan peralatan elektrik untuk mengurangkan risiko kebakaran, renjatan elektrik dan kecederaan kepada orang.
- Baca semua arahan sebelum menggunakan perkakas ini.
- Sambung ke alur keluar yang dibumikan dengan betul sahaja.
- Jangan kendalikan unit dengan kord atau palam yang rosak.
- Jangan sekat saluran masuk atau alur keluar udara.
- Pastikan unit ini berada di atas permukaan yang rata dan stabil.
- Cabut plag unit sebelum membersihkan atau menservis.
- Do not use in wet areas like bathrooms.
3. Pengenalan Bahagian
Biasakan diri anda dengan komponen penghawa dingin mudah alih anda.
Rajah 3.1: Depan view of the HOMSURE Portable Air Conditioner with a hand holding the remote control. This image shows the main unit, its air vents, and the included remote control, highlighting the compact design and ease of use.
Rajah 3.2: Terperinci view of the control panel display on top of the HOMSURE Portable Air Conditioner. This image illustrates the various buttons and indicators, including Timer, Fan Speed, Swing, Sleep, Mode, and Power buttons, along with their functions.
The unit typically consists of the main air conditioner body, an exhaust hose, a window sealing kit, and a remote control. The control panel is located on the top of the unit for easy access.
4. Persediaan dan Pemasangan
Proper installation is crucial for the efficient operation of your portable air conditioner. This unit is designed for easy setup with the included window kit.
4.1 Membongkar
- Keluarkan unit dan semua aksesori dengan berhati-hati daripada pembungkusan.
- Periksa sebarang kerosakan penghantaran. Jika rosak, jangan kendalikan dan hubungi khidmat pelanggan.
- Kekalkan pembungkusan asal untuk penyimpanan atau pengangkutan masa hadapan.
4.2 Memilih Lokasi
- Place the unit on a flat, stable surface near a window.
- Pastikan terdapat sekurang-kurangnya 20 inci (50 cm) ruang di sekeliling unit untuk aliran udara yang betul.
- The unit must be within reach of a grounded electrical outlet.
4.3 Pemasangan Kit Tingkap
The included window kit is designed for vertical or horizontal sliding windows with an opening range of 26.5 to 48.5 inches.
Rajah 4.1: Visual guide demonstrating the assembly of the exhaust hose and its connection to the window kit and the portable air conditioner unit. This image shows the process of attaching the hose to the unit and securing the window panel in place, ensuring proper ventilation.
- Assemble the exhaust hose by twisting it onto the hose adapter.
- Connect the hose adapter to the window slide kit.
- Open the window and place the window slide kit into the window opening. Extend the kit to fit the window width/height and secure it.
- Attach the other end of the exhaust hose to the exhaust port on the back of the air conditioner unit.
- Pastikan semua sambungan kukuh untuk mengelakkan kebocoran udara.
5. Arahan Operasi
Your HOMSURE portable air conditioner can be operated using the control panel on the unit or the included remote control.
5.1 Panel Kawalan Selesaiview
Rajah 5.1: An annotated image of the control panel, detailing the function of each button: Timer, Fan Speed, Swing Mode, Up/Down Arrows, Sleep Mode, Modes Button (Cool, Dry, Fan), and Power Button. This visual aid helps users understand the unit's interface.
| Butang | Fungsi |
|---|---|
| KUASA | Menghidupkan atau Mematikan unit. |
| MODE | Selects operating mode: Cool, Dehumidify (Dry), or Fan. |
| KELAJUAN KIPAS | Adjusts fan speed (Low, Medium, High) in Cool or Fan mode. |
| PEMASA | Menetapkan pemasa hidup automatik atau mati automatik (1-24 jam). |
| TIDUR | Mengaktifkan mod Tidur untuk operasi yang senyap dan cekap tenaga semasa tidur. |
| Swing | Controls the automatic oscillation of the air louvers. |
| Anak panah ATAS/BAWAH | Melaraskan tetapan suhu atau tempoh pemasa. |
5.2 Operasi Kawalan Jauh
Alat kawalan jauh menyediakan akses mudah kepada semua fungsi dari jauh.
Rajah 5.2: An image showing a person comfortably operating the HOMSURE Portable Air Conditioner with its remote control from a sofa. This highlights the convenience of remote operation in a typical home environment.
Ensure the remote control has working batteries. Point the remote control directly at the receiver on the unit. The buttons on the remote control correspond to the functions described for the control panel.
5.3 Mod Pengendalian
- Mod Sejuk: Provides cooling. Set desired temperature using the Up/Down arrows.
- Mod Penyahlembapan (Kering): Removes moisture from the air. Fan speed is automatically controlled.
- Mod Kipas: Mengedarkan udara tanpa penyejukan. Laraskan kelajuan kipas mengikut kehendak.
6. Penyelenggaraan
Penyelenggaraan tetap memastikan prestasi optimum dan memanjangkan jangka hayat penghawa dingin anda.
6.1 Membersihkan Penapis Udara
Penapis udara hendaklah dibersihkan setiap dua minggu atau lebih kerap bergantung pada penggunaan dan kualiti udara.
- Cabut palam unit daripada salur keluar kuasa.
- Cari dan keluarkan penapis udara dari bahagian belakang atau sisi unit.
- Basuh penapis dengan air suam dan sabun. Bilas sebersih-bersihnya.
- Allow the filter to air dry completely before reinserting it. Do not use hot water or harsh chemicals.
6.2 Menyalirkan Air
The unit has an internal water collection tank. When the tank is full, the unit will stop operating and display an indicator. Drain the water as follows:
- Cabut palam unit.
- Letakkan kuali atau dulang cetek di bawah port longkang di bahagian bawah belakang unit.
- Tanggalkan palam longkang untuk membolehkan air mengalir keluar.
- Setelah disalirkan, pasangkan palam saliran dengan selamat.
For continuous drainage in high humidity environments, you can connect a drain hose (not included) to the continuous drain port.
6.3 Membersihkan Bahagian Luar Unit
- Lap bahagian luar dengan lembut, damp kain.
- Jangan gunakan pembersih atau pelarut yang melelas.
6.4 Penyimpanan Bermusim
- Drain all water from the unit.
- Bersihkan penapis udara.
- Run the unit in Fan mode for a few hours to dry the interior.
- Cabut palam kord kuasa dan gulungkannya dengan kemas.
- Simpan unit di tempat yang sejuk dan kering, sebaik-baiknya dalam pembungkusan asalnya.
7. Panduan Penyelesaian Masalah
Sebelum menghubungi perkhidmatan pelanggan, sila rujuk jadual berikut untuk isu biasa dan penyelesaiannya.
| Masalah | Kemungkinan Punca | Penyelesaian |
|---|---|---|
| Unit tidak dihidupkan. | No power; Power cord not plugged in; Circuit breaker tripped; Full water tank. | Check power supply; Plug in cord; Reset breaker; Drain water tank. |
| Unit tidak sejuk. | Air filter dirty; Exhaust hose blocked or disconnected; Room too large; Doors/windows open. | Clean filter; Check hose connections; Ensure room size is within capacity; Close doors/windows. |
| Unit bising. | Unit tidak berada di atas permukaan yang rata; Penapis udara kotor; Halangan pada kipas. | Place on flat surface; Clean filter; Check for obstructions. |
| Kebocoran air. | Palam longkang longgar; Unit condong; Hos longkang berterusan tidak disambungkan dengan betul. | Secure drain plug; Ensure unit is level; Check continuous drain hose connection. |
| Alat kawalan jauh tidak berfungsi. | Batteries dead; Obstruction between remote and unit; Remote not pointed correctly. | Replace batteries; Remove obstructions; Point remote directly at unit. |
8. Spesifikasi Produk
Detailed technical specifications for your HOMSURE Portable Air Conditioner.
| Ciri | Spesifikasi |
|---|---|
| Nombor Model | ChaxianLY-AirConditioner80002Q |
| Kapasiti Penyejukan | 8000 BTU |
| Kawasan Liputan | Sehingga 350 kaki persegi. |
| Dimensi Produk (D x W x H) | 11.3 x 11.8 x 27.4 inci |
| Berat Barang | 50.7 paun |
| Tahap Kebisingan | ≤54 dB |
| Voltage | 115V |
| Wattage | 699W |
| Jenis Pemasangan | Tingkap (Mudah alih) |
| Window Kit Compatibility | 26.5" - 48.5" |
| Komponen yang Disertakan | Air Conditioner, Remote Control, Window Kit, Exhaust Hose |
Rajah 8.1: A visual representation of the product dimensions, indicating the height (27.4 inches), width (11.8 inches), and depth (11.3 inches) of the HOMSURE Portable Air Conditioner. This helps users understand the physical size of the unit.
9. Waranti dan Sokongan Pelanggan
For warranty information or technical assistance, please contact HOMSURE customer support. Details regarding specific warranty periods and terms are typically provided with your purchase documentation or can be found on the official HOMSURE webtapak.
If you encounter issues not covered in the troubleshooting guide, or require further assistance, please have your model number (ChaxianLY-AirConditioner80002Q) and purchase date ready when contacting support.
Maklumat Hubungan: Please refer to the contact details provided in your product packaging or visit the official HOMSURE webtapak untuk mendapatkan maklumat sokongan yang paling terkini.
