1. Pengenalan
This manual provides detailed instructions for the Fanvace 5-inch 80GB Android MP3 Player (Model US-M33). Please read this manual thoroughly before use to ensure proper operation and to maximize your device's potential. Keep this manual for future reference.
Image: Fanvace 5.0 inch MP3 Music Player highlighting key features.
2. Kandungan Pakej
Sahkan bahawa semua item yang disenaraikan di bawah disertakan dalam pakej anda:
- 1 x Fanvace 5-inch 80GB Android MP3 Player
- 1 x Kad Micro SD 64GB
- 1 x Kabel Pengecasan USB-C
- 1 x Fon Telinga Berwayar
- 1 x Pelindung Skrin
- 1 x Sarung Pelindung
- 1 x Manual Pengguna (dokumen ini)
Image: All items included in the Fanvace MP3 Player package.
Video: Unboxing the Fanvace 5-inch MP3 player and its included accessories.
3. Peranti Lebihview
The Fanvace MP3 Player features a sleek design with a 5-inch IPS full-touchscreen. Familiarize yourself with the device's physical components:
- Depan: Skrin Sentuh IPS 5-inci
- Sebelah Kanan: Volume Up/Down buttons, Reset button, Power On/Off button
- Bawah: USB-C port, 3.5mm headphone jack, Speaker, Micro SD card slot
Imej: Depan view of the Fanvace MP3 Player.
Image: Product details showing button and port locations.
4. Persediaan
4.1 Mengecas Peranti
Before first use, fully charge the device using the provided USB-C cable and a compatible power adapter (not included). Connect the USB-C cable to the player's port and the other end to a power source. The battery indicator on the screen will show charging status.
4.2 Hidupkan/Mati Kuasa
- Untuk Menghidupkan: Press and hold the Power On/Off button on the right side of the device until the screen illuminates.
- Untuk Mematikan: Press and hold the Power On/Off button, then select 'Power Off' from the on-screen options.
4.3 Memasukkan Kad SD Mikro
Locate the Micro SD card slot on the bottom of the device. Gently insert the provided 64GB Micro SD card into the slot until it clicks into place. Ensure the card is formatted to FAT32 for optimal compatibility. The device supports external storage up to 1TB.
Image: Inserting the Micro SD card for expanded storage.
4.4 Persediaan Awal
Setelah dihidupkan buat kali pertama, ikuti arahan pada skrin untuk menyelesaikan persediaan awal:
- Pilih bahasa pilihan anda.
- Connect to a Wi-Fi network (see section 5.4 for details).
- Sign in with your Google account to access the Play Store and other Google services.
- Tetapkan tarikh dan masa.
Video: Selesaiview of the Fanvace 5-inch MP3 Player's features and initial setup process.
5. Arahan Operasi
5.1 Navigation (Touchscreen)
The device operates using a responsive 5-inch full-touchscreen. Swipe, tap, and pinch gestures are used for navigation and interaction with applications.
Video: Demonstration of the user interface and navigation on the Fanvace 5-inch MP3 Player.
5.2 Main balik Muzik
The player supports HiFi lossless sound quality and is compatible with MP3, WAV, FLAC, APE, OGG, M4A, AAC, and WMA formats. Use the pre-installed music player app or download your preferred streaming service from the Play Store.
Image: Enjoying HiFi music on the device.
5.3 Main balik Video
The 5-inch IPS screen provides clear video playback. The device supports RM, RMVB, FLV, MP4, DAT, MKV, MPG, MOV, and TS video formats directly, without conversion.
Image: Visual impact of the 5-inch HD screen for videos.
5.4 Sambungan Bluetooth
The player features stable and fast two-way Bluetooth connection technology (Bluetooth 4.1). To connect to Bluetooth headphones or speakers:
- Go to Settings > Connected devices > Bluetooth.
- Ensure Bluetooth is enabled on both the player and your external device.
- Pilih 'Gandingkan peranti baharu' dan pilih peranti anda daripada senarai.
Image: Bluetooth 4.1 connectivity for headphones and speakers.
5.5 Wi-Fi Connection & App Usage
The device supports wireless network connection (Wi-Fi 2.4G & 5G). Connect to Wi-Fi to download apps, stream music and videos online, and browse the web.
- Pergi ke Tetapan > Rangkaian & internet > Wi-Fi.
- Pilih rangkaian Wi-Fi yang anda inginkan dan masukkan kata laluan jika digesa.
The player comes pre-installed with popular online music apps like Spotify, Deezer, and Amazon Music. You can download additional apps from the Google Play Store.
Image: Accessing the Google Play Store for app downloads.
5.6 File Pengurusan
Gunakan yang telah dipasang terlebih dahulu file manager to organize your music, videos, and other files on the internal 16GB ROM or the 64GB Micro SD card. You can transfer files via USB-C connection to a computer.
5.7 Fungsi Lain
The device includes several other useful functions:
- Radio FM: Tune into local radio stations.
- Perakam Suara: Record audio notes or lectures.
- E-buku: Read e-books using the Kindle app or other e-reader apps.
- Calculators & Browsers: Standard utility apps for daily needs.
6. Penyelenggaraan
6.1 Penjagaan Bateri
The 2500mAh lithium battery provides approximately 50 hours of music playback or 8 hours of video playback. To prolong battery life:
- Elakkan suhu yang melampau.
- Jangan nyahcas sepenuhnya bateri dengan kerap.
- Charge the device using the provided cable.
Image: Battery capacity and usage times.
6.2 Pengurusan Storan
Regularly manage your 80GB storage (16GB internal + 64GB SD card) to ensure optimal performance. Delete unnecessary files or transfer them to another device. The storage is expandable up to 1TB with a compatible Micro SD card (FAT32 format only).
6.3 Pembersihan
Gunakan kain lembut dan kering untuk membersihkan peranti. Elakkan menggunakan bahan kimia yang keras atau bahan kasar yang boleh merosakkan skrin atauasing.
7. Penyelesaian masalah
If you encounter issues with your Fanvace MP3 Player, refer to the following common solutions:
| Masalah | Penyelesaian yang Mungkin |
|---|---|
| Peranti tidak dihidupkan | Ensure the battery is charged. Press and hold the power button for 10-15 seconds. If unresponsive, use a pin to press the reset button. |
| Isu sambungan Wi-Fi | Check if Wi-Fi is enabled in settings. Ensure you are within range of a strong signal. Restart the device and your Wi-Fi router. |
| Kad mikro SD tidak dikenali | Ensure the SD card is properly inserted. Verify the card is formatted to FAT32. Try reinserting the card or using a different card. |
| Peranti perlahan atau tidak responsif | Close unused applications. Clear cache from apps. Restart the device. Ensure sufficient storage space is available. |
| Tiada bunyi daripada pembesar suara/fon kepala | Check volume levels. Ensure headphones are properly connected or Bluetooth device is paired correctly. Test with different audio files. |
8. Spesifikasi
| Ciri | Perincian |
|---|---|
| Nombor Model | US-M33 |
| Saiz Skrin | 5 Inches (IPS Full-Touchscreen) |
| Pemproses | Cip MTK 8-teras |
| RAM | 3GB |
| Storan Dalaman (ROM) | 16GB |
| Termasuk Kad SD | Kad TF 64GB |
| Storan Boleh Dikembangkan | Up to 1TB (Micro SD, FAT32 format only) |
| Kapasiti Bateri | 2500mAh Litium Ion |
| Masa Main semula Muzik | Sehingga 50 jam |
| Masa Main Balik Video | Sehingga 8 jam |
| Ketersambungan | Bluetooth 4.1, Wi-Fi (2.4G & 5G), USB-C |
| Format Audio | MP3, WAV, FLAC, APE, OGG, M4A, AAC, WMA |
| Format Video | RM, RMVB, FLV, MP4, DAT, MKV, MPG, MOV, TS |
| Dimensi | 6.69 x 5.75 x 0.87 inci |
| Berat badan | 14 auns |
Image: High performance configuration details.
9. Waranti dan Sokongan
Fanvace provides 12 hours of customer service. If you encounter any problems during use, please contact us. We are committed to resolving your issues within 12 hours.
For support, please refer to the contact information provided in your purchase documentation or visit the official Fanvace webtapak.
