PHI VILLA 9 PCS (60" Square Table)

PHI VILLA 9-Piece Outdoor Dining Set (60" Square Table) Instruction Manual

Model: 9 PCS (60" Square Table)

pengenalan

This manual provides instructions for the assembly, operation, and maintenance of your PHI VILLA 9-Piece Outdoor Dining Set. Please read all instructions carefully before assembly and use to ensure safe and proper functioning of the product.

PHI VILLA 9-Piece Outdoor Dining Set with 60-inch square table and 8 chairs arranged around a pool

Figure 1: PHI VILLA 9-Piece Outdoor Dining Set

Maklumat Keselamatan

  • Do not exceed 350 lbs weight limit per chair.
  • Be cautious of sharp edges and heavy parts during assembly.
  • Pastikan semua bolt dan skru diketatkan dengan kukuh sebelum digunakan.
  • Periksa bahagian yang longgar secara berkala dan ketatkan jika perlu.
  • Jauhkan kanak-kanak dari kawasan perhimpunan.

Persediaan dan Perhimpunan

Basic assembly instructions are included with your product. Please follow these guidelines for a smooth setup process.

Membongkar

The dining set is delivered in 5 separate packages. Ensure all packages are received before beginning assembly. Carefully unpack all components and verify against the parts list provided in your package. Place all parts on a soft, clean surface to prevent scratches.

Majlis Kerusi

Each chair requires basic assembly. Attach the seat to the backrest and then secure the legs. Ensure all connections are firm. The chairs feature ergonomically designed curved backrests and spacious seats for comfort.

Close-up of a PHI VILLA dining chair showing the intricate backrest design and armrests

Figure 2: Chair backrest detail

Pemasangan Meja

Assemble the table frame and then attach the tabletop sections. The 60-inch square table includes a central umbrella hole for convenience. Ensure all table legs are stable and level.

Atas ke bawah view of the 60-inch square PHI VILLA dining table with slatted surface and umbrella hole

Figure 3: Dining table surface

Cushion Placement

Place the thick seat cushions and lumbar pillows on each chair. The cushions are designed for comfort and support. Secure the cushions using the integrated straps to prevent them from shifting.

Close-up of a PHI VILLA chair cushion and lumbar pillow, highlighting their thickness and support

Figure 4: Chair cushion and lumbar pillow

Majlis Selesaiview Video

Video 1: Video ini menyediakan visual overview of the PHI VILLA patio dining set, showcasing its design and components, which can assist in understanding the assembly process.

Video 2: This video demonstrates the PHI VILLA 9-piece patio dining set in an outdoor setting, offering a closer look at the chairs and table features relevant to setup.

Video 3: This video highlights how the PHI VILLA patio set can transform a backyard space, providing context for its use and aesthetic appeal.

Video 4: This video offers another perspective on the PHI VILLA patio dining set for 8, detailing its features and suitability for outdoor gatherings.

Operasi

Using the Dining Set

The PHI VILLA 9-Piece Outdoor Dining Set is designed for comfortable outdoor dining and relaxation. The chairs are fixed, providing stable seating. The table's central hole is suitable for most standard patio umbrellas (umbrella not included) to provide shade.

Ciri-ciri Keselesaan

The chairs are equipped with thick, soft cushions and lumbar pillows for enhanced comfort during extended use. The ergonomic design supports a pleasant dining experience.

Sebuah udara view of the PHI VILLA 9-piece outdoor dining set by a pool, showing the arrangement of the table and chairs with cushions

Figure 5: Set in use by a pool

Penyelenggaraan

Arahan Penjagaan Produk

  • Bingkai: Wipe for dry cleaning or wipe with a damp cloth. The metal framework features a unique e-coating technology for enhanced rust resistance and durability against environmental changes.
  • Kusyen: All sitting cushion covers are zippered for easy disassembly and cleaning. The cushions feature CUSHIONPRO™ TECHNOLOGY, making them water-proof, oil-resistant, and stain-resistant. For best results, spot clean with a mild soap and water solution. Allow to air dry completely before reattaching.
Diagram illustrating CushionPro Technology with water, oil, and stain resistance properties

Figure 6: CushionPro Technology features

Diagram showing the three layers of the Powder E-coating Frame: Steel Process, Electrophoretic Coating, and Powder Coating

Figure 7: Powder E-coating Frame layers

Menyelesaikan masalah

Isu dan Penyelesaian Biasa

  • Meja/Kerusi Goyang: Ensure all bolts and screws are fully tightened. Check that the furniture is placed on a level surface.
  • Pengaratan: While the e-coating provides rust resistance, prolonged exposure to harsh weather conditions can affect the finish. Regularly clean and inspect the frame. Apply a rust-inhibiting paint if minor rust appears.
  • Cushion Discoloration/Wear: Although cushions are weather-resistant, store them indoors during extreme weather or prolonged periods of non-use to extend their lifespan.

Spesifikasi

CiriPerincian
Nama ProdukPHI VILLA 9 Pieces Outdoor Dining Set for 8
Model9 PCS (60" Square Table)
Dimensi MejaW 60" x L 60" x H 29"
Ketinggian Tempat Duduk Kerusi15.5"
Chair Armrest Height25.5"
Kapasiti Berat Kerusi350 lbs setiap kerusi
bahanKeluli Aloi (Kerangka)
warnaBlack Metal Table, Beige Fixed Chairs
Ciri KhasE-coating Technology (Rust-proof, Stable, Durable), Thick Soft Cushions (Zippered, Water-proof, Oil-resistant, Stain-resistant), Umbrella Hole
Perhimpunan Diperlukanya
Diagram showing the dimensions of the 60-inch square table and a dining chair, including height, width, and depth measurements

Rajah 8: Dimensi Produk

Waranti & Sokongan

Maklumat Waranti

PHI VILLA provides a 1-year service warranty for this product. Please retain your proof of purchase for warranty claims.

Sokongan Pelanggan

If you have any questions, concerns, or require assistance with your PHI VILLA dining set, please contact our customer service team. We are committed to assisting you and providing better service.

Untuk sokongan, sila layari PHI VILLA Store on Amazon atau rujuk maklumat hubungan yang diberikan dalam pembungkusan produk anda.
