1. Arahan Keselamatan Penting
Baca semua arahan sebelum menggunakan perkakas ini. Simpan manual ini untuk rujukan pada masa hadapan. Sentiasa patuhi langkah berjaga-jaga keselamatan asas untuk mengurangkan risiko kebakaran, kejutan elektrik atau kecederaan.
- Pastikan perkakas dibumikan dengan betul.
- Jangan rosakkan litar penyejuk.
- Jangan gunakan perkakas elektrik di dalam ruang penyimpanan makanan melainkan jenis yang disyorkan oleh pengilang.
- Cabut plag perkakas sebelum membersihkan atau melakukan penyelenggaraan.
- Pastikan bukaan pengudaraan bersih daripada halangan.
- Perkakas ini tidak dimaksudkan untuk digunakan oleh orang (termasuk kanak-kanak) yang kurang keupayaan fizikal, deria atau mental, atau kurang pengalaman dan pengetahuan, melainkan mereka telah diberi pengawasan atau arahan mengenai penggunaan perkakas oleh orang yang bertanggungjawab untuk keselamatan mereka.
2. Produk Lebihview
The Beko GNO46623MXPN is a freestanding side-by-side refrigerator-freezer designed to provide optimal food storage with advanced features and a modern stainless steel look.
Image: The Beko GNO46623MXPN Side-by-Side Refrigerator with Freezer, shown closed from an angled perspective, highlighting its stainless steel finish and sleek design.
Ciri-ciri Utama:
- 466 Liter Total Capacity: Menyediakan ample storage space for all your groceries.
- Intuitive Multifunction Display: External sensor buttons for easy temperature control and mode selection.
- NoFrost Dual Cooling: Separate cooling circuits prevent odor mixing and ensure uniform, energy-efficient, and quiet cooling for both refrigerator and freezer compartments.
- HarvestFresh Technology: A specialized vegetable drawer uses red, green, and blue light cycles to simulate natural daylight, preserving vitamin content longer.
- Mod Percutian: Saves energy by keeping only the freezer compartment operational when you are away.
- 18L Chiller-Zone: Dedicated compartment for optimal storage of meat, fish, and dairy products.
3. Persediaan
3.1 Membongkar
Carefully remove all packaging materials. Inspect the appliance for any shipping damage. Report any damage to your retailer immediately. Keep packaging materials out of reach of children.
3.2 Penempatan
Place the refrigerator on a firm, level surface away from direct sunlight and heat sources (e.g., oven, radiator). Ensure adequate ventilation around the appliance. Allow at least 10 cm of space at the back and sides for proper air circulation.
Image: A Beko refrigerator integrated into a modern kitchen, demonstrating appropriate placement and surrounding space.
3.3 Sambungan Elektrik
Sambungkan perkakas ke soket kuasa yang dibumikan dengan volum yang betultage (230V). Do not use extension cords or adapters. Ensure the power cord is not trapped or damaged.
3.4 Operasi Permulaan
After connecting to power, allow the appliance to stand for at least 4 hours before loading food. This allows the refrigerant to settle. The interior will then cool down to the set temperature.
Image: The interior of the Beko GNO46623MXPN refrigerator and freezer compartments, shown empty with shelves and drawers visible.
4. Arahan Operasi
4.1 Panel Kawalan
The multifunction display on the exterior of the door allows you to monitor and adjust settings without opening the appliance. Use the sensor buttons to navigate through options.
Imej: Dari dekat view of the external control panel with sensor buttons, used for adjusting settings.
4.2 Tetapan Suhu
Adjust the temperature for both the refrigerator and freezer compartments using the control panel. Recommended settings are typically 4°C (39°F) for the refrigerator and -18°C (0°F) for the freezer.
4.3 Teknologi HarvestFresh
The HarvestFresh drawer uses a 3-color light system (red, green, blue) to mimic the natural 24-hour sun cycle. This technology helps preserve the vitamin content of fruits and vegetables for longer periods.
Image: A close-up of the HarvestFresh drawer, showing fruits and vegetables illuminated by the special colored light system.
4.4 NoFrost Dual Cooling
This system features independent cooling circuits for the refrigerator and freezer, preventing frost buildup and eliminating the need for manual defrosting. It also stops odors from mixing between compartments.
4.5 Mod Percutian
Activate Vacation Mode via the control panel when you are away for an extended period. In this mode, the refrigerator compartment operates at a higher, energy-saving temperature, while the freezer maintains its set temperature to keep frozen food preserved.
4.6 Chiller-Zone
The 18-liter Chiller-Zone drawer maintains a temperature just above freezing, ideal for storing fresh meat, fish, and dairy products to extend their shelf life.
Image: The interior of the Beko GNO46623MXPN refrigerator and freezer compartments, shown organized with various food items.
5. Penjagaan dan Penyelenggaraan
5.1 Membersihkan Bahagian Dalaman
Unplug the appliance before cleaning. Use a soft cloth and a solution of mild soap and warm water to clean the interior surfaces. Rinse with clean water and dry thoroughly. Do not use abrasive cleaners or harsh chemicals.
5.2 Membersihkan Bahagian Luar
Lap bahagian luar dengan lembut, damp kain. Untuk permukaan keluli tahan karat, gunakan pembersih keluli tahan karat khusus. Elakkan air daripada memasuki komponen elektrik.
5.3 Penyelenggaraan Kedap Pintu
Regularly check and clean the door seals to ensure a tight seal. A damaged or dirty seal can lead to inefficient cooling and increased energy consumption.
5.4 Kuasa Outage Maklumat
Sekiranya berlaku kuasa outage, keep the doors closed to maintain the internal temperature for as long as possible. Avoid opening the doors unnecessarily. Food in the freezer can remain frozen for several hours depending on the duration of the outage and how full the freezer is.
6. Penyelesaian masalah
Sebelum menghubungi perkhidmatan pelanggan, rujuk jadual berikut untuk isu biasa dan penyelesaiannya.
| Masalah | Kemungkinan Punca | Penyelesaian |
|---|---|---|
| Perkakas tidak beroperasi. | Tiada bekalan kuasa; palam tidak dimasukkan dengan betul; fius ditiup. | Check power connection; ensure plug is fully inserted; check household fuse box. |
| Refrigerator/Freezer is not cooling sufficiently. | Door not closed properly; excessive door opening; high ambient temperature; too much food loaded; temperature setting too high. | Ensure door is fully closed; reduce frequency of door openings; adjust temperature setting lower; allow space for air circulation around food. |
| Bunyi yang tidak biasa. | Appliance not level; items inside rattling; compressor noise (normal). | Adjust leveling feet; rearrange items inside; compressor noise is normal during operation. |
| Air di bahagian bawah petak peti sejuk. | Lubang longkang untuk air cair tersumbat. | Clear the drain hole with a small, soft tool (e.g., pipe cleaner). |
7. Spesifikasi Teknikal
| Spesifikasi | Nilai |
|---|---|
| Jenama | Beko |
| Nombor Model | GNO46623MXPN |
| Dimensi Produk (D x W x H) | 74 x 79.5 x 180 cm |
| Berat badan | 87 kg |
| Jumlah Kapasiti | 466 Liter |
| Kapasiti Peti Sejuk | 291 Liter |
| Kapasiti Penyejuk beku | 175 Liter |
| Konfigurasi | French Door Side-by-Side |
| warna | Pandangan Keluli Tahan Karat |
| Ciri Khas | HarvestFresh, Vacation Mode, Chiller-Zone |
| Jenis Pemasangan | Freestanding |
| Sistem Pencairan | NoFrost Dual Cooling |
| Voltage | 230 Volt |
8. Waranti dan Sokongan Pelanggan
Your Beko GNO46623MXPN refrigerator is covered by a manufacturer's warranty. Please refer to the warranty card included with your purchase for specific terms and conditions, including the warranty period and coverage details.
Untuk bantuan teknikal, alat ganti atau untuk menjadualkan temu janji servis, sila hubungi khidmat pelanggan Beko. Anda boleh mendapatkan maklumat hubungan di laman web rasmi Beko. webtapak atau dalam dokumentasi produk anda.
When contacting support, please have your model number (GNO46623MXPN) and serial number ready to ensure efficient service.
