COSTWAY Multipurpose Steam Cleaner

1. Arahan Keselamatan Penting

Sila baca semua arahan dengan teliti sebelum menggunakan perkakas ini. Kegagalan mematuhi arahan ini boleh mengakibatkan renjatan elektrik, kebakaran atau kecederaan serius.

• Sentiasa pastikan bekalan kuasa sepadan dengan volumtage dinyatakan pada perkakas.
• Do not leave the steam cleaner unattended while it is plugged in or operating.
• Jauhkan daripada kanak-kanak dan haiwan peliharaan.
• Jangan rendam perkakas, kord kuasa, atau palamkan ke dalam air atau cecair lain.
• Gunakan hanya lampiran dan aksesori yang disyorkan pengilang.
• Exercise caution when using steam; it can cause burns. Avoid direct contact with skin or eyes.
• Unplug the appliance before filling with water, cleaning, or performing maintenance.
• Do not open the water tank cap while the unit is pressurized or hot.
• Inspect the power cord and plug for damage before each use. Do not operate if damaged.

2. Produk Lebihview

2.1 Komponen dan Ciri

The COSTWAY Multipurpose Steam Cleaner is designed for efficient and deep cleaning across various surfaces using high-temperature steam. Key components include:

• Unit Utama: Houses the heating element and water tanks.
• Tangki Air: 1.5L capacity for extended cleaning sessions.
• Steam Hose and Gun: For directing steam to cleaning areas.
• Storan Aksesori: Detachable trolley for convenient storage of attachments.
• Roda dan Kastor: For easy maneuverability.

Figure 1: Main components of the steam cleaner, highlighting the water tank, handle, cable management, accessory lock, wheels, and casters.

2.2 Aksesori Termasuk

Your steam cleaner comes with 19 accessories for versatile cleaning tasks:

• Extension Wands (x2)
• Mop Head with High-Quality Microfiber Pads (x2)
• Nylon Brushes (x5)
• Berus Tembaga
• Cawan Pengukur
• Corong Air
• Permaidani Glider
• Squeegee
• Berus Segi Tiga
• Pad Scrub
• And other specialized nozzles and brushes.

Figure 2: All included accessories for diverse cleaning applications.

2.3 Spesifikasi

Rajah 3: Dimensi produk untuk rujukan.

3. Persediaan

Follow these steps to prepare your steam cleaner for first use:

1. Bongkar: Keluarkan semua komponen dari pembungkusan dengan berhati-hati. Simpan pembungkusan untuk penyimpanan atau pengangkutan masa hadapan.
2. Berhimpun: Attach the desired accessories (e.g., extension wands, mop head) to the steam gun. Ensure they click securely into place.
3. Isi Tangki Air: Ensure the unit is unplugged and cool. Unscrew the water tank cap. Use the provided measuring cup and funnel to fill the 1.5L water tank with clean tap water. Do not overfill. Distilled water is recommended to prevent mineral buildup. Securely replace the water tank cap.

Figure 4: Filling the water tank.

4. Sambungan Kuasa: Palamkan kord kuasa ke salur keluar elektrik yang dibumikan.

4. Arahan Operasi

Once set up, follow these steps to operate your steam cleaner:

1. Hidupkan kuasa: Turn on the main power switch. The indicator light will illuminate, signaling that the unit is heating up.
2. Masa Pemanasan: Allow approximately 8-10 minutes for the water to heat up and produce steam. The indicator light may change or turn off when ready, depending on the model.
3. Keluaran Stim: Press the steam trigger on the steam gun to release steam. Direct the steam towards the surface you wish to clean.

Figure 5: Steam output from the nozzle.

4. Teknik Pembersihan:
   • For floors and carpets, use the mop head with a microfiber pad or carpet glider. Move the mop head slowly over the surface.
   • For stubborn stains, hold the steam nozzle closer to the surface for a few seconds before wiping.
   • Use appropriate brushes for different surfaces (e.g., nylon brushes for general cleaning, brass brush for tough grime on metal surfaces, triangle brush for corners).
   • For windows and glass, use the squeegee attachment.
5. Pengisian semula: If the steam output decreases or stops, the water tank may be empty. Turn off and unplug the unit, allow it to cool for a few minutes, then carefully unscrew the cap and refill the tank as described in the Setup section.
6. Penamat: When cleaning is complete, turn off the power switch and unplug the unit. Allow it to cool completely before storing.

Figure 6: Versatile cleaning applications with different attachments.

Figure 7: Steam cleaner in operation.

5. Penyelenggaraan

Regular maintenance ensures optimal performance and extends the life of your steam cleaner.

• Tangki Air Kosong: After each use, ensure the unit is cool and depressurized. Carefully unscrew the water tank cap and empty any remaining water.
• Aksesori Bersih: Wash microfiber pads and brushes with water and mild detergent. Allow them to air dry completely before storing.
• Padam Unit: Lap bahagian luar pembersih wap dengan iklanamp kain. Jangan gunakan pembersih atau pelarut yang melelas.
• Penyahkerak (Secara Berkala): If you notice reduced steam output or mineral buildup, descale the unit. Consult the full manual for specific descaling instructions, typically involving a vinegar solution.
• Storan: Store the steam cleaner and its accessories in a cool, dry place. The detachable trolley provides convenient storage for accessories.

Figure 8: Detachable trolley for accessory storage.

6. Penyelesaian masalah

Rujuk bahagian ini untuk isu biasa dan penyelesaiannya.

Jika masalah berterusan selepas mencuba penyelesaian ini, sila hubungi sokongan pelanggan.

7. Waranti dan Sokongan

Untuk maklumat waranti, sokongan produk atau untuk membeli alat ganti, sila lawati COSTWAY rasmi webtapak atau hubungi bahagian perkhidmatan pelanggan mereka.

Sokongan dalam talian: Lawati Kedai COSTWAY di Amazon

Please have your model number (24668-CYEP) and purchase date available when contacting support.
