FLEXISPOT EF1 Basic Plus Electric Height-Adjustable Desk User Manual

1. Pengenalan

Thank you for choosing the FLEXISPOT EF1 Basic Plus Electric Height-Adjustable Desk. This manual provides essential information for the safe and efficient assembly, operation, and maintenance of your new desk. Please read these instructions thoroughly before use and retain them for future reference.

Amaran Keselamatan

• Always follow the assembly instructions carefully to prevent accidents and ensure proper function.
• Do not exceed the maximum load capacity of 70 kg (154 lbs) on the desktop. Overloading can compromise stability and cause damage.
• To prevent tipping, especially when the desk is at its maximum height (121 cm), ensure the desk is anchored correctly to a stable wall.
• Keep children and pets away from the desk during operation to avoid injury from moving parts.
• Ensure there are no obstructions in the desk's path during height adjustment.
• Jangan duduk atau berdiri di atas meja.
• Putuskan sambungan kuasa sebelum membersihkan atau melakukan sebarang penyelenggaraan.

2. Persediaan dan Pemasangan

The FLEXISPOT EF1 Basic Plus desk requires assembly. Please ensure all components are present before beginning. Refer to the included assembly guide for detailed step-by-step instructions.

Membongkar dan Semakan Komponen

Carefully unpack all parts and lay them out on a soft, clean surface to prevent scratches. Verify that all components listed in the packing list are present.

Majlis Selesaiview

1. Attach the lifting columns to the desk feet.
2. Connect the crossbar to the lifting columns.
3. Pasangkan desktop pada bingkai yang telah dipasang.
4. Install the control panel and cable management tray (if included).
5. Connect all motor and control cables according to the wiring diagram.
6. Pasangkan kabel kuasa ke soket yang dibumikan.

Rajah 1: The FLEXISPOT EF1 Basic Plus Electric Height-Adjustable Desk with a black tabletop and white frame, set up in a home office environment.

Rajah 2: This image illustrates the smooth, single-piece desktop construction of the FlexiSpot desk, contrasting it with typical multi-piece desktops that may have uneven surfaces.

Rajah 3: An illustrative diagram detailing various desktop size and color options, along with key specifications for the desk frame, including adjustable height range, static and dynamic load capacities, and lifting noise levels.

3. Arahan Operasi

Panel Kawalan Terlaluview

Rajah 4: A terperinci view of the desk's Smart Control Panel, highlighting the LED display, the up and down adjustment buttons, and four numbered buttons for memory presets.

The desk is equipped with an advanced all-in-one keypad for easy height adjustment and memory functions.

• Paparan led: Menunjukkan ketinggian meja semasa dalam sentimeter.
• Up/Down Buttons (⌃ / ⌄): Press and hold to manually adjust the desk height upwards or downwards. Release the button to stop at the desired height.
• Pratetap Memori (1, 2, 3, 4): Four programmable buttons to save and recall your preferred sitting and standing heights.

Menetapkan Pratetap Memori

1. Laraskan meja pada ketinggian yang diingini menggunakan butang Atas/Bawah.
2. Press the "M" or "SET" button (if available, otherwise proceed to step 3) to activate memory mode.
3. Press one of the numbered preset buttons (1, 2, 3, or 4) within 3 seconds. The LED display will show "S-1", "S-2", etc., indicating the height has been saved to that preset.

Recalling Memory Presets

Hanya tekan butang pratetap bernombor yang dikehendaki (1, 2, 3 atau 4). Meja akan bergerak secara automatik ke ketinggian yang disimpan.

Rajah 5: This image demonstrates the height adjustment capabilities of the desk, showing a range from 72 cm (sitting height) to 117 cm (standing height). Note that the full adjustable range for this model is 71 cm to 121 cm.

4. Penyelenggaraan

Penyelenggaraan berkala memastikan ketahanan dan prestasi optimum meja FLEXISPOT anda.

• Pembersihan: Lap desktop dan bingkai dengan lembut, damp kain. Elakkan pembersih yang melelas atau bahan kimia keras yang boleh merosakkan kemasan.
• Pengurusan Kabel: Periodically check and organize cables to prevent tangles and ensure smooth operation.
• Pemeriksaan: Regularly inspect all screws and bolts to ensure they are tight. Retighten if necessary.
• Pelinciran: The lifting columns are generally maintenance-free. Do not attempt to lubricate internal components unless specifically instructed by customer support.

5. Penyelesaian masalah

If you encounter any issues with your desk, refer to the following common problems and solutions.

Tetapkan semula Prosedur

If the desk is not functioning correctly, a reset may resolve the issue.

1. Press and hold the "Down" button until the desk reaches its lowest position and slightly retracts, then releases.
2. If this does not initiate a reset, unplug the desk from the power outlet for at least 10 seconds, then plug it back in.
3. Repeat step 1. The desk should now be reset.

6. Spesifikasi

7. Waranti dan Sokongan

Maklumat Waranti

FLEXISPOT stands behind the quality of its products. Your EF1 Basic Plus desk comes with the following warranty:

• Waranti 3 Tahun: Covers controllers and motors.
• Waranti 5 Tahun: Covers the desk frame.

Please retain your proof of purchase for warranty claims. The warranty covers manufacturing defects under normal use. It does not cover damage caused by misuse, accidents, unauthorized modifications, or failure to follow the instructions in this manual.

Rajah 6: An image outlining the warranty coverage for FlexiSpot desks, specifically mentioning a 3-year warranty for controllers and motors, and a 5-year warranty for the desk frame.

Sokongan Pelanggan

For technical assistance, warranty claims, or any questions regarding your FLEXISPOT EF1 Basic Plus desk, please contact FLEXISPOT customer support.

Webtapak: www.flexispot.com (or regional equivalent)
e-mel: Refer to your purchase documentation or the official FlexiSpot webtapak untuk e-mel hubungan.
telefon: Refer to your purchase documentation or the official FlexiSpot webtapak untuk nombor telefon untuk dihubungi.
