pengenalan
This manual provides essential information for the safe and efficient operation, maintenance, and troubleshooting of your FOHERE Nugget Ice Maker. Please read it thoroughly before first use and retain it for future reference. This countertop ice maker is designed to produce soft, crunchy nugget ice, ideal for various beverages and applications, with a daily production capacity of up to 33 lbs and an ice basket holding up to 5.3 lbs.
Figure 1: FOHERE Nugget Ice Maker. This image shows the compact, stainless steel design of the ice maker, suitable for countertop placement, with a refreshing drink demonstrating its use.
Arahan Keselamatan Penting
Untuk mengurangkan risiko kebakaran, kejutan elektrik atau kecederaan, sentiasa ikuti langkah berjaga-jaga asas ini:
- Baca semua arahan sebelum menggunakan perkakas.
- Jangan sentuh penyejat atau bakul ais semasa unit beroperasi.
- Jangan rendam kord, palam atau mana-mana bahagian unit dalam air atau cecair lain.
- Pengawasan rapi diperlukan apabila sebarang perkakas digunakan oleh atau berhampiran kanak-kanak.
- Jangan kendalikan sebarang perkakas dengan kord atau palam yang rosak, atau selepas perkakas tidak berfungsi atau rosak dalam apa jua cara.
- Gunakan hanya air yang boleh diminum untuk pengeluaran ais.
- Ensure proper ventilation around the unit. Maintain at least 5 inches of space on all sides.
- Unplug the appliance from the outlet when not in use or before cleaning.
Apa yang ada dalam Kotak
Selepas membongkar, sila pastikan semua item ada dan dalam keadaan baik:
- Nugget Ice Maker Unit
- Skop Ais
- Bakul Ais
- Operation Guide (this manual)
- Panduan Penyelenggaraan
Persediaan
- Membongkar: Carefully remove the ice maker from its packaging. Remove all packing materials, tape, and any protective film.
- penempatan: Place the ice maker on a flat, stable, and level surface away from direct sunlight and other heat sources (e.g., stove, furnace, radiator). Ensure there is at least 5 inches (12.7 cm) of clear space around the top, back, and sides for proper ventilation.
- Pembersihan Awal: Before first use, clean the interior of the ice maker. Refer to the "Maintenance and Cleaning" section for detailed instructions on the self-cleaning function.
- Sambungan Kuasa: Palamkan kord kuasa ke salur keluar elektrik yang dibumikan. Pastikan voltage sepadan dengan label penilaian pada perkakas.
- Isi takungan air: Buka penutup dan isi takungan air dengan air yang boleh diminum sehingga garisan isian "MAX". Jangan penuhkan.
Figure 2: Portable and Space-saving Design. This image illustrates the compact dimensions of the ice maker (17.63" D x 9.69" W x 16.93" H) and suggests various suitable locations for its use, such as kitchens, parties, RVs, and offices.
Arahan Operasi
- Hidupkan kuasa: Press the "ON/OFF" button to start the ice making cycle. The indicator light will illuminate.
- Pengeluaran Ais: The ice maker will begin producing nugget ice within approximately 5 minutes. The first few cycles may produce smaller or irregular ice cubes. This is normal.
- Penunjuk Penuh Ais: When the ice basket is full, the "ICE FULL" indicator light will turn on, and the ice making process will automatically pause. Remove ice from the basket to resume production.
- Tambah Penunjuk Air: If the water level in the reservoir is too low, the "ADD WATER" indicator light will turn on, and the unit will stop making ice. Add water to the reservoir up to the "MAX" line, and the unit will automatically restart ice production after a few minutes.
- Ice Retention: The ice maker is not a freezer. While it has insulated construction to keep ice colder for longer (up to 70% retention for 12 hours at 80°F ambient temperature), it is recommended to use the ice promptly or transfer it to a freezer for long-term storage.
- Matikan: Press the "ON/OFF" button to turn off the unit.
Figure 3: Rapid Ice Release. This visual highlights the speed at which the FOHERE ice maker produces ice, with the first batch ready in approximately 5 minutes.
Figure 4: Higher Daily Production. This image emphasizes the ice maker's capability to produce up to 33 pounds of ice per day, sufficient for various needs.
Video 1: FOHERE Pebble Ice Makers Countertop. This short video demonstrates the ice maker in operation, showcasing the production of pebble ice and its texture.
Penyelenggaraan dan Pembersihan
Regular cleaning and maintenance will ensure the longevity and optimal performance of your ice maker.
- Fungsi Pembersihan Diri:
The ice maker features an auto self-cleaning function. To activate:
- Pastikan unit kosong daripada ais dan air.
- Isi takungan air dengan air bersih sehingga garisan MAX.
- Press and hold the "CLEAN" button for 3 seconds. The cleaning cycle will begin and typically lasts for 20 minutes.
- Once the cycle is complete, drain the water through the drainage valve located at the bottom of the unit.
Figure 5: Auto Self-cleaning. This image visually represents the internal self-cleaning process, ensuring hygiene and efficient operation.
- Mengurangkan:
It is recommended to descale your ice maker twice a month, especially in areas with hard water. Use a citric acid solution for descaling. Follow the instructions provided with your descaling agent, or mix a solution of water and citric acid (e.g., 1 tablespoon citric acid per liter of water) and run the self-cleaning cycle with this solution.
- Pembersihan tetap:
- Lap bahagian luar dengan lembut, damp kain.
- Clean the ice basket and ice scoop with mild detergent and rinse thoroughly.
- Periodically drain any remaining water from the reservoir using the drainage valve.
- Storan: If the ice maker will not be used for an extended period, drain all water, clean the unit thoroughly, and allow it to air dry completely before storing in a cool, dry place.
Menyelesaikan masalah
| Masalah | Kemungkinan Punca | Penyelesaian |
|---|---|---|
| Pembuat ais tidak berfungsi. | Tiada kuasa; penunjuk "TAMBAH AIR" hidup; penunjuk "AIS PENUH" hidup. | Periksa sambungan kuasa; Tambah air ke takungan; Keluarkan ais dari bakul. |
| Ice production is slow or ice is small. | Ambient temperature too high; Water temperature too high; Poor ventilation; First few cycles. | Ensure room temperature is suitable (below 90°F); Use cold water; Ensure proper ventilation around the unit; This is normal for initial cycles. |
| Air bocor dari unit. | Drain plug not properly sealed; Unit not level; Internal component issue. | Ensure drain plug is securely closed; Place unit on a level surface; Contact customer service if problem persists. |
| Bunyi luar biasa semasa operasi. | Normal compressor noise; Unit not level; Internal obstruction. | Some noise is normal; Ensure unit is on a level surface; If noise is excessive or new, contact customer service. |
Spesifikasi
- Jenama: FOHERE
- Nama Model: Pembuat Ais Nugget
- Dimensi Produk: 17.63"D x 9.69"W x 16.93"H
- kapasiti: 5.3 Pounds (ice basket)
- Wattage: 170 watt
- Daily Ice Production: Sehingga 33 lbs
- First Ice Batch: Lebih kurang 5 minit
- Bahan: Stainless Steel finish, Food-grade materials
Figure 6: Upgraded Compressor & Infrared Detection. This diagram illustrates the advanced internal components, including the compressor and infrared sensors, which contribute to the ice maker's fast cooling, stable performance, and energy efficiency.
Waranti dan Sokongan
Your FOHERE Nugget Ice Maker comes with a 12-month after-sale service warranty from the date of purchase. For any questions, concerns, or technical support, please contact our customer service team. We offer 7*24-hour customer service to assist you.
Please refer to the contact information provided on the product packaging or the official FOHERE webtapak untuk saluran sokongan yang paling terkini.
