pengenalan
Thank you for choosing FAMOO Wireless Earbuds. These Bluetooth 5.1 headphones are designed to provide a high-fidelity stereo audio experience with extended playtime, robust waterproofing, and intuitive touch controls. This manual will guide you through the setup, operation, and maintenance of your new earbuds.
Apa yang ada dalam Kotak
- FAMOO Wireless Earbuds (Left and Right)
- Kes Pengecasan
- Kabel Pengecasan USB Jenis-C
- Pelbagai Saiz Petua Telinga (S, M, L)
- Replacement Earhooks
Image: The FAMOO Wireless Earbuds securely placed within their charging case, showcasing the compact design and the LED battery display on the front of the case.
Produk Selesaiview
Bunyi Stereo Kesetiaan Tinggi
Equipped with a built-in 10mm graphene audio driver and pure copper coil, these earbuds deliver powerful bass with a 43% boost, ensuring HiFi sound quality and enhanced music details.
Imej: Meletup view diagram illustrating the 10mm graphene audio driver and pure copper coil components responsible for the high-fidelity sound.
Extended Playtime & LED Power Display
Enjoy up to 6 hours of usage time on a single charge, extended to a total of 48 hours with the 800mAh charging case. The case features a Type-C interface for fast charging. A unique LED power display on the charging case indicates the battery levels of both the case and the earbuds.
Image: A visual representation of the earbud's 6-hour single charge battery life and the charging case extending it to 48 hours, highlighting the Type-C fast charging port.
Image: A close-up of the charging case's LED display, clearly showing the battery percentage for the case and individual battery indicators for each earbud.
Persediaan
1. Mengecas Fon Telinga dan Sarung
Before first use, fully charge the earbuds and the charging case. Place the earbuds into the charging case. Connect the provided USB Type-C cable to the charging port on the case and plug the other end into a compatible USB power source. The LED display will show the charging progress.
2. One-step Auto Pairing
The earbuds feature one-step auto pairing for convenience. Simply open the charging case, and the wireless headphones will automatically connect to the last paired device within a few seconds. For initial pairing or connecting to a new device:
- Pastikan fon telinga berada dalam bekas pengecasan dan bekasnya terbuka.
- Pada peranti anda (telefon pintar, tablet, dll.), dayakan Bluetooth.
- Look for "S17" in the list of available Bluetooth devices and select it to pair.
- Once paired, the earbuds will automatically connect to this device when removed from the case.
Image: A smartphone screen displaying the Bluetooth settings, with "S17" listed as a connected device, illustrating the one-step auto pairing process.
Image: A diagram illustrating the flexibility of using the earbuds in either single (mono) or dual (binaural) mode, allowing for individual or shared listening experiences.
Arahan Operasi
Kawalan Sentuhan Pintar
The earbuds feature intelligent touch controls for various functions. There are no physical buttons; simply tap the surface of the earbud to perform actions.
- Main/Jeda: Ketik sekali
- Lagu Seterusnya: Double tap (Right earbud)
- Lagu Sebelumnya: Double tap (Left earbud)
- Jawab/Tamatkan Panggilan: Ketik sekali
- Tolak Panggilan: Tekan lama (2 saat)
- Kelantangan: Triple tap (Right earbud)
- Perlahankan suara: Triple tap (Left earbud)
- Aktifkan Pembantu Suara (Siri): Tekan lama (2 saat)
Image: A visual guide detailing the various touch control gestures on the earbuds for functions like playing music, managing calls, and adjusting volume.
Gaya Memakai
The earbuds are ergonomically designed for comfort and stability, especially during sports. They come with detachable earhooks and multiple ear tip sizes to ensure a secure fit.
Image: A demonstration of the detachable earhook feature, showing how the earbuds can be worn with or without the earhooks for different activities and preferences.
Image: A comprehensive visual showing various wearing styles and included accessories like replacement ear tips and earhooks, emphasizing comfort and adaptability.
Video Demonstrasi Produk
Watch this video for a detailed demonstration of the FAMOO Wireless Earbuds, including setup, features, and usage tips.
Video: An official product video from the seller demonstrating the features and functionality of the FAMOO Wireless Earbuds, including pairing, charging, and touch controls.
Penyelenggaraan
Penilaian Kalis Air IPX7
The earbuds are equipped with an IPX7 waterproof rating, meaning they can resist daily splashes of water, sweat, and rain. This makes them ideal for sports and travel. However, they are not designed for swimming or prolonged submersion. Ensure the earbuds are dry before placing them back into the charging case to prevent damage.
Image: A woman running, illustrating the earbuds' suitability for sports and their IPX7 waterproof rating, which protects against sweat and rain.
Menyelesaikan masalah
- Fon telinga tidak berpasangan: Ensure both earbuds are charged. Place them back in the case, close it, then open it again. Check your device's Bluetooth settings and try re-pairing.
- Hanya satu fon telinga berfungsi: Place both earbuds back in the charging case. Ensure they are properly seated and charging. Take them out simultaneously to allow them to connect to each other before connecting to your device.
- Kelantangan rendah atau kualiti bunyi yang lemah: Ensure the earbuds are fully charged. Adjust the volume on both your device and using the earbud touch controls. Try different sizes of ear tips to ensure a snug fit for optimal sound isolation.
- Sarung pengecas tidak dicas: Ensure the USB Type-C cable is securely connected to both the case and the power source. Try a different charging cable or power adapter.
Spesifikasi
| Ciri | Perincian |
|---|---|
| Nama Model | S17 |
| Teknologi Ketersambungan | Wayarles (Bluetooth 5.1) |
| Pemacu Audio | Pemacu Audio Graphene 10mm |
| Masa Main (Earbud) | Sehingga 6 jam (caj tunggal) |
| Jumlah Masa Main (dengan Kes) | Sehingga 48 jam |
| Antara Muka Pengecasan | USB Jenis-C (Pengecasan Pantas) |
| Tahan Air | IPX7 Kalis Air |
| Kaedah Kawalan | Kawalan Sentuh |
| Kawalan Bunyi | Sound Isolation, CVC 8.0 |
| Penempatan Telinga | Di Telinga |
| Faktor Bentuk | Di Telinga |
Waranti dan Sokongan
FAMOO products are manufactured to the highest quality standards. For warranty information, technical support, or any inquiries regarding your FAMOO Wireless Earbuds, please refer to the contact information provided on the product packaging or visit the official FAMOO webtapak. Sila simpan bukti pembelian anda untuk tuntutan waranti.
