EMOOR Slatted Bed OSMOS Single - Instruction Manual

pengenalan

Terima kasih kerana membeliasing the EMOOR OSMOS Single Slatted Bed Frame. This manual provides essential information for the safe assembly, proper use, and effective maintenance of your new bed frame. Please read these instructions carefully before assembly and retain them for future reference.

Ciri-ciri Produk

Natural Pine Wood Construction

Constructed from natural pine wood, known for its ability to absorb heat and impact, and blend harmoniously with any space. Its natural form complements both Western and Japanese style rooms, suitable for use with futons or mattresses.

Exceptional Ventilation

Mattresses and futons accumulate significant sweat and moisture. A slatted bed is essential in humid climates. It prevents mold and odors by allowing fresh air circulation, reducing moisture buildup.

3-Stage Height Adjustment

The bed can be adjusted to approximately 5cm, 18cm, and 31cm, making it a versatile bed suitable for both futons and mattresses. It accommodates various lifestyles, from high-type for easy standing to floor-level use, recommended for all ages.

Load Capacity of Approximately 200kg

The wide backboard and six legs distribute body weight across the bed frame, ensuring safe use for two or more people. The wider backboard, compared to typical slatted beds, offers a modern aesthetic and enhanced safety.

Maklumat Keselamatan

• Sentiasa pasang rangka katil di atas permukaan yang lembut dan bersih untuk mengelakkan kerosakan pada produk atau lantai anda.
• Pastikan semua skru dan pengikat diketatkan dengan selamat sebelum digunakan. Periksa dan ketatkan semula secara berkala jika perlu.
• Do not stand on the bed frame. Distribute weight evenly across the frame.
• When moving the bed, always lift it by the long sides. Do not drag the bed, as this may damage the frame or floor.
• Jauhkan bahagian kecil daripada kanak-kanak semasa pemasangan untuk mengelakkan bahaya tercekik.
• Do not exceed the maximum load capacity of approximately 200 kg.
• Avoid exposing the bed frame to direct sunlight or extreme temperature changes, which can cause wood warping or cracking.

Kandungan Pakej

Sila sahkan bahawa semua komponen hadir sebelum memulakan pemasangan. Jika mana-mana bahagian yang hilang atau rosak, sila hubungi sokongan pelanggan.

• Bed frame slats (multiple pieces)
• Kaki (6 keping)
• Connecting plates/reinforcement parts
• Perkakasan pemasangan (skru, sepana Allen)
• Manual arahan

Arahan Persediaan dan Pemasangan

Assembly typically takes 15-30 minutes with one person, but two people are recommended for easier handling and stability during assembly.

1. Buka Pembungkusan Komponen: Carefully remove all parts from the packaging and lay them out on a soft, clean surface. Check against the package contents list.
2. Pasang Kaki: Securely attach the six legs to the designated points on the bed frame using the provided screws and Allen wrench. Ensure the legs are firmly attached and perpendicular to the frame.
3. Connect Frame Sections (if applicable): If your frame comes in multiple sections, align them and use the connecting plates and screws to join them securely.
4. Install Reinforcement Parts: Attach any reinforcement parts as indicated in the diagram to enhance stability. Ensure correct positioning to avoid stress on the frame.
5. Laraskan Ketinggian: The bed frame offers three height settings (approx. 5cm, 18cm, 31cm). To adjust, remove the legs, re-insert them into the desired height holes, and re-tighten. Ensure all legs are set to the same height for stability.
6. Semakan Akhir: Once assembled, gently shake the frame to ensure stability. Re-tighten any loose screws.

Arahan Operasi

Using the Bed Frame

This bed frame is designed for use with either a futon or a mattress. Its slatted design promotes air circulation, which is beneficial in humid environments.

Pelarasan Ketinggian

The bed frame offers three height settings to suit your preference and needs:

• Approximately 5 cm (low profile)
• Approximately 18 cm (medium height)
• Approximately 31 cm (high profile)

To change the height, carefully lift the bed frame, remove the legs, and re-insert them into the desired height positions. Ensure all legs are uniformly set to maintain stability.

Penyelenggaraan

Pembersihan

Wipe the bed frame with a dry cloth to remove dust and dirt. Avoid using abrasive cleaners or harsh chemicals, as these can damage the lacquer finish and natural wood.

Pengudaraan

The slatted design provides excellent ventilation, crucial for preventing mold and odors, especially in humid environments. Ensure adequate airflow around and under the bed by not blocking the space beneath it.

Pemeriksaan Berkala

Regularly inspect all screws and connections to ensure they remain tight. Re-tighten any loose fasteners to maintain the bed frame's stability and safety.

Menyelesaikan masalah

Spesifikasi

Maklumat Waranti

EMOOR products are manufactured with quality and durability in mind. For specific warranty details, please refer to the warranty card included with your purchase or visit the official EMOOR webtapak. Simpan bukti pembelian anda untuk tuntutan waranti.

Sokongan Pelanggan

If you have any questions regarding the assembly, operation, or maintenance of your EMOOR Slatted Bed OSMOS Single, please contact EMOOR customer support.

For contact information, please visit the official EMOOR website or refer to the contact details provided on your purchase receipt.

EMOOR Official Webtapak: EMOOR Store on Amazon.co.jp
