pengenalan
This manual provides detailed instructions for the safe operation and maintenance of your 4DRC 4D-M3 Mini Drone with Camera. Please read this manual thoroughly before operating the drone to ensure proper function and to avoid damage or injury. Keep this manual for future reference.
Langkah-langkah Keselamatan
- Sentiasa kendalikan dron di kawasan terbuka, jauh dari manusia, haiwan dan halangan.
- Jangan terbang berhampiran dengan kelantangan tinggitage lines, airports, or restricted airspace.
- Ensure all propellers are securely attached and undamaged before each flight.
- Keep hands and face away from rotating propellers.
- Do not operate the drone in strong winds or adverse weather conditions.
- Supervise children during drone operation. This product is intended for children.
- Charge batteries using only the provided charger and follow all charging instructions.
- In case of emergency, use the one-key emergency stop function.
Kandungan Pakej
Sahkan bahawa semua item terdapat dalam pakej anda:
- 4DRC 4D-M3 Mini Drone
- Alat Kawalan Jauh
- Module Batteries (x2)
- Kabel Pengecas USB
- Baling-baling ganti
- Propeller Guards (x4)
- Pemutar skru
- Manual Pengguna
- Sarung Penyimpanan
Produk Selesaiview
Familiarize yourself with the drone's components.
Image: The 4DRC 4D-M3 Mini Drone, showcasing its compact design and propeller guards.
Imej: Terperinci view of the 4DRC 4D-M3 drone, highlighting its camera lens and overall structure.
Persediaan
1. Pemasangan dan Pengecasan Bateri
The drone uses module batteries for extended flight time. Ensure batteries are fully charged before use.
- Insert the module battery into the drone's battery compartment.
- Connect the USB charging cable to the battery and a USB power source.
- The charging indicator will show the charging status. Disconnect once fully charged.
Video: Demonstrates the drone's features including battery installation and flight capabilities.
2. Remote Controller Pairing
Follow these steps to pair the remote controller with the drone:
- Hidupkan dron.
- Hidupkan alat kawalan jauh.
- Move the left joystick up and then down. The drone's lights will stop flashing, indicating successful pairing.
Arahan Operasi
Operasi Asas Penerbangan
- Berlepas/Mendarat Satu Kunci: Press the one-key takeoff/landing button to automatically launch or land the drone.
- Mod Tahan Ketinggian: Dron ini mengekalkan ketinggian yang stabil, menjadikannya lebih mudah dikawal.
- Mod Tanpa Kepala: In headless mode, the drone's orientation is relative to the pilot, simplifying flight control regardless of the drone's front direction.
- 3 Mod Kelajuan: Adjust the flight speed according to your skill level and environment.
Image: Illustrates one-key takeoff/landing, headless mode, and altitude hold features for easy flight.
Ciri Lanjutan
- HD Camera & FPV Function: The 120° wide-angle 1080P HD camera captures high-quality videos and clear aerial photos. Enjoy live FPV (First Person View) transmission up to 60m directly to your smartphone.
- Kawalan Gerak Isyarat: Perform specific hand gestures (e.g., raising a hand, V-gesture) in front of the drone's camera to trigger photo or video recording.
- Track Flight Mode: Draw a flight path on your smartphone screen, and the drone will automatically follow the designated route.
- Balik 3D: Execute exciting 3D flips with a single button press for dynamic flight maneuvers.
- Gravity Induction Mode: Control the drone's flight direction by tilting your smartphone.
- Hentian kecemasan: In critical situations, press the emergency stop button to immediately halt the drone's motors.
Image: Demonstrates gesture control for photos and the track flight mode feature.
Image: The drone performing a 3D flip, illustrating its acrobatic capabilities.
Image: Shows FPV real-time transmission to a smartphone, allowing instant sharing of photos and videos.
Image: Depicts voice control commands for basic flight maneuvers like "Fly" and "Left".
Penyelenggaraan
- Regularly inspect propellers for damage. Replace any bent or broken propellers immediately using the provided spare parts.
- Clean the drone body with a soft, dry cloth. Avoid using water or harsh chemicals.
- Simpan dron dan bateri di tempat yang sejuk dan kering, jauh daripada cahaya matahari langsung dan suhu yang melampau.
- Pastikan bateri dicas sebahagian (sekitar 50%) sebelum penyimpanan jangka panjang untuk memanjangkan jangka hayatnya.
Menyelesaikan masalah
| Masalah | Kemungkinan Punca | Penyelesaian |
|---|---|---|
| Drone tidak bertindak balas kepada pengawal. | Tidak berpasangan, bateri lemah, di luar julat. | Re-pair the controller, charge batteries, ensure drone is within operating range. |
| Drone hanyut semasa penerbangan. | Calibration needed, uneven surface at takeoff, wind interference. | Perform gyroscope calibration, take off from a flat surface, avoid flying in windy conditions. |
| Camera not recording/transmitting. | App not connected, insufficient storage, camera malfunction. | Ensure the app is correctly connected via Wi-Fi, check SD card (if applicable) or phone storage, contact customer support if issue persists. |
| Masa penerbangan yang singkat. | Bateri tidak dicas sepenuhnya, bateri lama, penerbangan agresif. | Fully charge batteries, consider replacing old batteries, fly more conservatively. |
Spesifikasi
- Jenama: 4DRC
- model: 4D-M3
- Resolusi Tangkapan Video: 1080P HD
- Komunikasi Tanpa Wayar: Wi-Fi, 2.4 GHz
- Jenis Kawalan: Remote Control, Gesture Control, Gravity Induction, Voice Control
- Jenis Bateri: Lithium Ion Module Battery (x2 included)
- Masa Penerbangan Maks: Approximately 20 minutes (with 2 batteries)
- Julat FPV: Sehingga 60 meter
- Umur Sasaran: Kanak-kanak
- warna: merah
- UPC: 781858651988
- ASIN: B08ZNQJSDQ
Sokongan Pelanggan
If you have any questions regarding the functions, maintenance, or repair of your drone, please do not hesitate to contact our dedicated customer service team. We are available to assist you with any flight-related issues in a timely manner.
For support, please refer to the contact information provided with your product packaging or visit the official 4DRC webtapak.
