1. Pengenalan
This manual provides essential information for the safe installation, operation, and maintenance of your ZMH LED Ceiling Light. Please read these instructions carefully before installation and retain them for future reference.
2. Arahan Keselamatan
- Pastikan bekalan kuasa diputuskan sebelum pemasangan atau penyelenggaraan.
- Pemasangan hendaklah dilakukan oleh juruelektrik bertauliah jika anda tidak pasti.
- Jangan ubah suai produk dalam apa jua cara.
- Produk ini direka untuk kegunaan dalaman sahaja (penarafan IP20).
- Jauhkan daripada air dan kelembapan yang tinggi.
3. Kandungan Pakej
Sahkan bahawa semua komponen hadir sebelum memulakan pemasangan:
- ZMH LED Ceiling Light fixture
- Alat Kawalan Jauh
- Perkakasan pemasangan (skru, sauh)
- Manual Arahan (dokumen ini)
Note: The included terminal block may be small. It is recommended to use a suitable terminal block for secure wiring if necessary.
4. Panduan Pemasangan
- Penyediaan: Disconnect power at the main circuit breaker. Ensure the mounting surface is clean and stable.
- Pemasangan Braket Pemasangan:
Attach the mounting bracket to the ceiling using the provided screws and anchors. Ensure it is securely fastened.
Imej: Jarak dekat view of the light fixture's mounting bracket, showing the attachment points for ceiling installation.
- Pendawaian:
Connect the household electrical wires to the light fixture's terminal block. Ensure correct polarity (Live, Neutral, Earth). Double-check all connections for security.
Rujuk juruelektrik yang berkelayakan jika anda tidak biasa dengan pendawaian elektrik.
- Lampiran Lekapan:
Carefully attach the LED ceiling light fixture to the installed mounting bracket. Secure it in place according to the design (e.g., sliding and locking mechanisms, or screws).
Image: Dimensional diagram of the ZMH LED Ceiling Light, illustrating its 60cm length and mounting structure.
- Pemulihan Kuasa: Once the installation is complete and secure, restore power at the main circuit breaker.
5. Arahan Operasi
The ZMH LED Ceiling Light is operated using the included remote control.
5.1 Fungsi Kawalan Jauh
- Hidupkan/Mati Kuasa: Tekan butang kuasa untuk menghidupkan atau mematikan lampu.
- Pelarasan Kecerahan: Use the brightness buttons (usually '+' and '-') to increase or decrease the light intensity continuously.
- Pelarasan Suhu Warna: Use the color temperature buttons (often represented by sun/moon icons or 'C'/'W') to adjust the light from warm white (3000K) to neutral white (4500K) to cool white (6000K).
- Fungsi Memori: The light features an integrated memory function that saves the last brightness and color temperature setting for future use.
Image: The ZMH LED Ceiling Light demonstrating its ability to switch between cold, neutral, and warm light settings, with the remote control visible.
Imej: Terperinci view of the ZMH LED Ceiling Light, highlighting the difference between warm white and cool white illumination.
6. Penyelenggaraan
- Pembersihan: Putuskan kuasa sebelum membersihkan. Lap lekapan dengan kain lembut dan kering. Jangan gunakan pembersih atau pelarut yang kasar.
- LED: The LEDs are permanently installed and do not require replacement.
7. Penyelesaian masalah
| Masalah | Kemungkinan Punca | Penyelesaian |
|---|---|---|
| Cahaya tidak menyala. | Tiada bekalan kuasa; pendawaian longgar; bateri alat kawalan jauh kehabisan kuasa. | Check circuit breaker; verify wiring connections; replace remote control battery. |
| Alat kawalan jauh tidak bertindak balas. | Remote control battery depleted; remote not paired (if applicable); obstruction. | Replace remote control battery; ensure direct line of sight to the light. |
| Memory function not working consistently. | Light turned off too quickly after adjustment. | Allow the light to remain on for a few seconds after adjusting settings before turning it off to ensure the memory function saves the state. |
| Inconsistent light output or flickering. | Loose wiring; incompatible dimmer switch (if not using remote). | Check wiring connections; ensure only the provided remote control is used for dimming. |
Note: Due to potential remote control upgrades, both old and new versions may be in circulation. If you experience issues or have questions, please contact customer service.
8. Spesifikasi
| Jenama | ZMH |
| Model | LED Panel Light 60cm (B08HS3H81W) |
| Dimensi (L x W x H) | lebih kurang 60 cm x 15 cm x 4.5 cm |
| Berat badan | 2.18 kg |
| bahan | Metal and Acrylic |
| Penggunaan Kuasa | 23 Watt |
| Voltage | 230 Volt (AC) |
| Fluks Bercahaya | 3280 Lumen |
| Suhu Warna | 3000K (Putih Hangat) hingga 6000K (Putih Sejuk) |
| Indeks Paparan Warna (CRI) | >80 |
| Jangka hayat | lebih kurang 30,000 jam |
| Penarafan IP | IP20 (Penggunaan dalaman sahaja) |
| Ciri Khas | Dimmable, Remote Control, Memory Function |
8.1 Kecekapan Tenaga
Image: EU Energy Label for the ZMH LED Ceiling Light, indicating its energy efficiency class.
Untuk maklumat tenaga terperinci, sila rujuk pangkalan data EPREL: https://eprel.ec.europa.eu/qr/1114582
9. Waranti dan Sokongan
For any questions, issues, or warranty claims regarding your ZMH LED Ceiling Light, please contact our customer service. Refer to your purchase documentation for specific warranty terms and contact details.
We are committed to providing support and solutions for your product.
