COMISO X26L Waterproof Bluetooth Speaker Instruction Manual

1. Produk Lebihview

The COMISO X26L is a portable, waterproof Bluetooth speaker designed for high-quality audio playback in various environments. It features a robust design, long battery life, and advanced connectivity options.

Figure 1: COMISO X26L speaker demonstrating its waterproof design.

Ciri-ciri Utama:

• Bunyi Jelas: Equipped with two precision acoustic drivers for distinct mids and highs, and a proprietary passive bass radiator for enhanced bass.
• Penilaian Kalis Air IPX7: Can be fully submerged up to 1 meter for 30 minutes, suitable for outdoor and indoor activities including showers, pool parties, hiking, and camping.
• Fungsi True Wireless Stereo (TWS): Pair two COMISO X26L speakers for a true wireless stereo experience with double enhanced sound.
• Masa Main Dilanjutkan: Built-in 6000mAh rechargeable battery provides up to 36 hours of continuous playtime.
• Kesambungan Bluetooth 5.0: Ensures quick, low-latency, and stable connections within a 10-meter (33-foot) range.
• Mikrofon terbina dalam: Allows for hands-free calls.

2. Persediaan

2.1 Apa yang ada di dalam Kotak

• COMISO X26L Bluetooth Speaker
• Kabel Pengecas USB-C
• Kabel Audio 3.5mm
• Manual Pengguna

2.2 Mengecas Speaker

Before first use, fully charge the speaker. The charging port is located at the base of the unit, protected by a rubber flap.

1. Open the rubber flap at the base of the speaker.
2. Sambungkan kabel pengecas USB-C yang disediakan ke port pengecasan pembesar suara.
3. Sambungkan hujung kabel USB-C yang satu lagi kepada penyesuai kuasa USB yang serasi (tidak disertakan).
4. A blue LED indicator ring around the top control panel will illuminate during charging.
5. Charging typically takes approximately 3 hours. The LED indicator will change or turn off once fully charged.

2.3 Menghidupkan/Mematikan

The power button is located in the center of the top control panel.

• Untuk Menghidupkan: Press and hold the power button for a few seconds until you hear an audio prompt and the blue LED indicator ring illuminates.
• Untuk Mematikan: Press and hold the power button for a few seconds until you hear an audio prompt and the blue LED indicator ring turns off.

2.4 Berpasangan Bluetooth

The speaker uses Bluetooth 5.0 for stable wireless connections.

1. Ensure the speaker is powered on and the blue LED indicator ring is flashing, indicating it's in pairing mode.
2. Pada peranti anda (telefon pintar, tablet, dll.), dayakan Bluetooth dan cari peranti yang tersedia.
3. Select 'COMISO X26L' from the list of devices.
4. Once connected, you will hear an audio confirmation, and the blue LED indicator will stop flashing and remain solid.
5. The speaker will automatically reconnect to the last paired device when powered on, if within range.

Figure 2: Bluetooth connectivity and True Wireless Stereo setup.

2.5 Penggandingan Stereo Tanpa Wayar Sebenar (TWS)

To achieve a stereo sound experience, you can pair two COMISO X26L speakers together.

1. Ensure both COMISO X26L speakers are powered on and not connected to any other Bluetooth device.
2. On one speaker (this will be your master speaker), press the middle power button twice quickly. You will hear a prompt indicating TWS pairing mode.
3. The two speakers will automatically search for and connect to each other. Once connected, you will hear an audio confirmation.
4. Now, connect your device to the master speaker via Bluetooth as described in section 2.4. The audio will play in sync on both speakers, providing a stereo sound.
5. To disconnect TWS, simply power off either speaker.

3. Mengendalikan Speaker

3.1 Fungsi Panel Kawalan

The top control panel features intuitive buttons for managing playback and volume.

• Butang Kuasa (Pusat): Press and hold to power on/off. Press once to play/pause music. Double-press for TWS pairing.
• Naikkan Kelantangan (+) / Trek Seterusnya: Press once to increase volume. Press and hold to skip to the next track.
• Kelantangan Kurang (-) / Trek Sebelumnya: Press once to decrease volume. Press and hold to go to the previous track.
• Play/Pause Button (Triangle): Tekan sekali untuk memainkan atau menjeda muzik.

3.2 Kesambungan Berwayar

For devices without Bluetooth or to conserve battery, use the 3.5mm audio jack.

1. Open the rubber flap at the base of the speaker.
2. Connect the provided 3.5mm audio cable to the AUX port on the speaker.
3. Connect the other end of the audio cable to your audio source.
4. Pembesar suara secara automatik akan bertukar kepada mod AUX.

3.3 Rintangan Air (IPX7)

The COMISO X26L is IPX7 rated, meaning it can be submerged in water up to 1 meter (3 feet) for 30 minutes. This makes it ideal for use in wet environments.

• Ensure the rubber flap covering the charging and AUX ports is securely closed before exposing the speaker to water.
• Elakkan penenggelaman berpanjangan melebihi kedalaman dan masa yang ditetapkan.
• Do not expose the speaker to saltwater or other chemicals, as this may damage the device.

Figure 3: The COMISO X26L is IPX7 waterproof.

4. Penyelenggaraan

4.1 Pembersihan

• Lap pembesar suara dengan lembut, damp kain.
• Jangan gunakan pembersih atau pelarut yang melelas.
• Ensure all ports are dry before charging or connecting cables after exposure to water.

4.2 Penyimpanan

• Simpan pembesar suara di tempat yang sejuk dan kering jauh dari cahaya matahari langsung dan suhu yang melampau.
• Jika menyimpan untuk tempoh yang lama, cas bateri sehingga kira-kira 50% untuk memanjangkan jangka hayatnya.

5. Penyelesaian masalah

5.1 Speaker Does Not Power On

• Pastikan bateri dicas. Sambungkan pembesar suara ke sumber kuasa menggunakan kabel USB-C.
• Tekan dan tahan butang kuasa selama beberapa saat.

5.2 Unable to Pair via Bluetooth

• Pastikan pembesar suara berada dalam mod berpasangan (LED biru berkelip).
• Make sure the speaker is within the 10-meter (33-foot) Bluetooth range of your device.
• Matikan dan hidupkan Bluetooth pada peranti anda, kemudian cuba cari sekali lagi.
• If previously paired, try 'forgetting' the device on your phone's Bluetooth settings and re-pairing.
• Pastikan tiada peranti lain disambungkan ke pembesar suara pada masa ini.

5.3 Tiada Bunyi atau Kelantangan Rendah

• Tingkatkan kelantangan pada kedua-dua pembesar suara dan peranti anda yang disambungkan.
• Ensure the speaker is properly paired via Bluetooth or connected via the 3.5mm audio cable.
• Check if the audio source is playing correctly.

5.4 TWS Pairing Fails

• Ensure both speakers are COMISO X26L models.
• Make sure neither speaker is connected to any other Bluetooth device before attempting TWS pairing.
• Power off both speakers, then power them on and try the TWS pairing process again.

6. Spesifikasi

7. Waranti dan Sokongan

7.1 Maklumat Waranti

Produk ini disertakan dengan a Waranti Terhad. Please refer to the warranty card included in your product packaging for specific terms and conditions. Keep your purchase receipt as proof of purchase.

7.2 Sokongan Pelanggan

For any questions, technical assistance, or warranty claims, please contact COMISO customer support through the retailer where you purchased the product or visit the official COMISO webtapak untuk maklumat hubungan.
