AIRPLUS 70 Pints Dehumidifier Instruction Manual

pengenalan

This manual provides detailed instructions for the operation and maintenance of your AIRPLUS 70 Pints Dehumidifier (Model AP1902). Please read this manual thoroughly before use to ensure proper function and safety. This dehumidifier is designed to efficiently remove excess moisture from the air, creating a more comfortable and healthier indoor environment.

Rajah 1: Depan view of the AIRPLUS 70 Pints Dehumidifier.

Arahan Keselamatan Penting

Untuk mengurangkan risiko kebakaran, kejutan elektrik atau kecederaan semasa menggunakan penyahlembap anda, ikuti langkah berjaga-jaga asas ini:

• Sentiasa pasangkan unit ke soket elektrik yang dibumikan.
• Jangan kendalikan penyahlembap dengan kord atau palam yang rosak.
• Do not block air vents or exhaust openings. Ensure adequate clearance around the unit.
• Keep the unit away from water sources and wet areas.
• Cabut plag penyahlembap sebelum membersihkan atau melakukan sebarang penyelenggaraan.
• Jangan biarkan kanak-kanak mengendalikan atau bermain dengan penyahlembap.
• Gunakan hanya seperti yang diterangkan dalam manual ini.

Ciri-ciri Produk

• Significant Dehumidification Effect: Removes up to 70 pints of water per day (under 90% RH @ 86°F condition). Designed for medium to large rooms, basements, and other damp kawasan.


Figure 2: Automatic humidity detection for intelligent constant humidity.

• Multifunctional Modes & Intelligent Operation: Features STANDARD, RAINING, DRYING, and SLEEP modes. Intelligent constant humidity automatically adjusts to maintain desired levels. Includes a two-way timing function for scheduled operation.


Figure 3: Control panel displaying various operating modes.



Figure 4: Intelligent two-way timing feature for scheduled operation.



Figure 5: Low noise design for quiet operation.

• Convenient Drainage & Auto Shut Off: Offers continuous drainage with an included hose or manual drainage using the large-capacity 4.1 L water tank. The unit automatically shuts off when the tank is full.


Figure 6: Large 4.1L water tank for less frequent emptying.



Figure 7: Options for manual or continuous drainage.



Figure 8: Automatic shutdown feature prevents overflow when the tank is full.

• Widespread Application & Flexible Movements: Compact design suitable for various spaces including living rooms, kitchens, RVs, closets, and bathrooms. Equipped with universal wheels for easy portability.

Video Produk Rasmi

Video 1: Selesaiview of the AIRPLUS 70 Pints Dehumidifier's features and benefits.

Panduan Persediaan

1. Membongkar: Carefully remove the dehumidifier and all packaging materials from the box. Retain packaging for future storage or transport.
2. penempatan: Place the dehumidifier on a firm, level surface in the area where humidity control is desired. Ensure there is at least 8 inches (20 cm) of clear space around all sides of the unit for proper air circulation. Avoid placing near heat sources or in direct sunlight.
3. Sambungan Kuasa: Plug the power cord into a properly grounded 115V/60Hz electrical outlet. The unit will beep once, and the display will light up briefly.

Arahan Operasi

Panel Kawalan Terlaluview

The control panel features touch-sensitive buttons and a digital display for easy operation.

• Butang Hidup/Mati: Menghidupkan atau mematikan unit.
• Butang Mod: Cycles through Standard, Raining, Drying, and Sleep modes.
• Butang Kelembapan: Melaraskan tahap kelembapan yang diingini.
• Butang Pemasa: Menetapkan pemasa auto hidup atau mati automatik.
• Butang Anion: Activates or deactivates the Anion function (air purification).
• Penunjuk Penuh: Lights up when the water tank is full.
• Penunjuk nyahbeku: Lights up when the unit is in defrost mode.

Mod Pengendalian

• Mod Standard: Default mode for general dehumidification.
• Raining Mode: Optimized for high humidity conditions, providing powerful moisture removal.
• Mod Pengeringan: Ideal for drying clothes or quickly reducing humidity in very damp kawasan.
• Mod tidur: Operates at a lower fan speed and dims the display for quiet, undisturbed operation during sleep.

Menetapkan Kelembapan yang Diingini

Press the 'Humidity' button to cycle through desired humidity levels (e.g., 40%, 45%, 50%, etc.). The unit will automatically maintain the set humidity level.

Fungsi Pemasa

Press the 'Timer' button to set an auto-on or auto-off time (from 1 to 24 hours). The unit will turn on or off automatically after the set time has elapsed.

Penyelenggaraan

Mengosongkan Tangki Air

When the water tank is full, the 'Full' indicator will light up, and the unit will automatically shut off. Carefully pull out the water tank from the front of the unit. Empty the collected water and slide the tank back into place until it clicks securely.

Persediaan Saliran Berterusan

For continuous operation without manual emptying, attach a standard garden hose (not included) to the continuous drainage outlet at the back of the unit. Ensure the hose is sloped downwards to allow gravity drainage to a floor drain or suitable container.

Membersihkan Penapis Udara

The air filter should be cleaned every two weeks or more frequently depending on usage and air quality. A clogged filter reduces efficiency and can cause the unit to malfunction.

1. Matikan penyahlembap dan cabut plagnya dari salur keluar kuasa.
2. Keluarkan penapis dari bahagian belakang unit.
3. Wash the filter with clean water (no hotter than 104°F / 40°C) and a mild detergent.
4. Bilas dengan teliti dan biarkan penuras kering sepenuhnya sebelum dimasukkan semula.
5. Reinstall the filter and plug in the dehumidifier.

Panduan Penyelesaian Masalah

Sebelum menghubungi perkhidmatan pelanggan, sila rujuk jadual berikut untuk isu biasa dan penyelesaiannya:

Spesifikasi Produk

• Jenama: AIRPLUS
• Nama Model: AP1902
• kapasiti: 70 Pint sehari
• Liputan Kawasan Lantai: 4500 Kaki Persegi
• Jumlah tangki: 4.1 Liter
• Mod Operasi: Berterusan
• Ciri Khas: Portable, Automatic Shutoff
• Bahan: plastik
• Berat Barang: 34.3 paun
• Dimensi Pakej: 25.7 x 17.2 x 12.6 inci

Waranti dan Sokongan

AIRPLUS products come with a standard manufacturer's warranty. For detailed warranty information, technical support, or service inquiries, please visit the official AIRPLUS webtapak atau hubungi perkhidmatan pelanggan.
