COSTWAY Foldable Magnetic Bicycle Trainer - User Manual

1. Pengenalan

Thank you for choosing the COSTWAY Foldable Magnetic Bicycle Trainer. This manual provides essential information for the safe and efficient assembly, operation, and maintenance of your new bicycle trainer. Please read these instructions thoroughly before first use and retain them for future reference.

This magnetic bicycle trainer is designed to convert your road or mountain bike into a stationary indoor exercise bike, allowing you to train regardless of weather conditions. It features adjustable resistance levels and a stable, foldable design for convenient storage.

2. Arahan Keselamatan Penting

• Baca semua arahan: Before assembling and using the trainer, read all instructions in this manual.
• Pengawasan orang dewasa: This product is intended for adult use. Keep children and pets away from the trainer during operation.
• Permukaan stabil: Always place the trainer on a flat, stable, and non-slip surface. Ensure adequate space around the trainer.
• Check bicycle compatibility: Ensure your bicycle (26-28 inch or 700c wheels, rear wheel width 9-21.5 cm) is compatible and securely mounted before use.
• Periksa sebelum digunakan: Before each use, check all bolts, nuts, and connections to ensure they are tight and secure.
• Kapasiti berat maksimum: Jangan melebihi berat pengguna maksimum 150 kg (330 lbs).
• Proper attire: Wear appropriate athletic clothing and footwear. Avoid loose clothing that could get caught in moving parts.
• Stay hydrated: Minum banyak air sebelum, semasa, dan selepas senaman anda.
• Listen to your body: Stop exercising immediately if you feel pain, dizziness, or shortness of breath. Consult a physician before starting any new exercise program.
• Bahagian bergerak: Keep hands, feet, and hair clear of all moving parts.
• haba: The resistance unit can become hot during prolonged use. Avoid touching it immediately after a workout.

3. Persediaan dan Pemasangan

Follow these steps to assemble and set up your COSTWAY Magnetic Bicycle Trainer.

3.1 Membongkar dan Semakan Komponen

Carefully unpack all components from the box. Verify that all parts are present according to the packing list. If any parts are missing or damaged, do not proceed with assembly and contact customer support.

Rajah 3.1: All included components for the bicycle trainer.

3.2 Assembling the Trainer Frame

1. Unfold the main frame of the trainer. Ensure the locking mechanisms are securely engaged to form a stable base.
2. Attach the resistance unit to the frame if it is not pre-assembled. Secure it with the provided bolts and nuts.
3. Adjust the foot caps at the base of the trainer. These can be finely adjusted in 5 steps to compensate for uneven floor surfaces, ensuring maximum stability.

Rajah 3.2: Adjustable foot caps for leveling the trainer.

Rajah 3.3: Key components of the trainer.

3.3 Mounting Your Bicycle

1. Replace your bike's rear quick release skewer with the one provided with the trainer. This ensures a secure fit.
2. Position your bicycle's rear wheel into the trainer's clamping mechanism. The trainer is compatible with road and mountain bikes with 26-28 inch or 700c wheels.
3. Laraskan clamping width to fit your bike's rear wheel axle, typically between 9 and 21.5 cm. Tighten the clamps securely using the double locking system.
4. Ensure the rear tire makes firm contact with the resistance roller. Adjust the pressure regulator to achieve optimal contact without excessive pressure.
5. Place the front wheel support block under your bike's front wheel to level the bike and prevent steering movement during your workout.

Rajah 3.4: Trainer compatibility and adjustable width.

4. Arahan Operasi

Once your bicycle is securely mounted, you can begin your indoor cycling workout.

4.1 Melaraskan Rintangan

The COSTWAY Magnetic Bicycle Trainer features an 8-level adjustable resistance mechanism. Use the remote resistance controller, typically mounted on your handlebars, to select your desired resistance level. Higher numbers indicate greater resistance, simulating uphill climbs or more intense training.

Rajah 4.1: User engaging in an indoor cycling workout.

4.2 Starting Your Workout

• Ensure your bike's gears are in a comfortable starting position.
• Begin pedaling slowly to warm up.
• Gradually increase your speed and adjust the resistance level as needed to match your training goals.
• The trainer can also serve as a repair stand or a stable bike stand when not in use for training.

Rajah 4.2: Trainer in use for a casual cycling session.

5. Penyelenggaraan

Regular maintenance will ensure the longevity and optimal performance of your bicycle trainer.

• Pembersihan: Lap kasut latihan dengan iklanamp kain selepas setiap penggunaan untuk mengeluarkan peluh dan habuk. Elakkan pembersih yang kasar.
• Pelinciran: Periodically check and lubricate any moving parts or pivot points as recommended by bicycle maintenance guidelines.
• Tighten fasteners: Regularly check and tighten all bolts, nuts, and connections to ensure the trainer remains stable and safe.
• Storan: When not in use, the trainer can be folded for compact storage. Store it in a dry place away from direct sunlight and extreme temperatures.

Rajah 5.1: Foldable design for easy storage and transport.

6. Penyelesaian masalah

If you encounter issues with your bicycle trainer, refer to the following common problems and solutions:

7. Spesifikasi

Rajah 7.1: Product dimensions (unfolded and folded).

8. Waranti dan Sokongan

COSTWAY products are manufactured to high-quality standards. For warranty information, technical support, or to report any issues with your product, please refer to the warranty card included with your purchase or visit the official COSTWAY weblaman web untuk maklumat hubungan.

Please have your model number (SP24736DE) and purchase date ready when contacting support.
