LoraTap WiFi Smart Relay Switch (Model RR400W) User Manual

1. Pengenalan

This manual provides detailed instructions for the installation, setup, and operation of your LoraTap WiFi Smart Relay Switch (Model RR400W). Please read this manual thoroughly before use to ensure proper functionality and safety.

Kandungan Pakej:

LoraTap WiFi Smart Relay Switch (RR400W)
Manual Pengguna
Mounting accessories (screws, anchors, mini screwdriver, electrical wires)

LoraTap WiFi Smart Relay Switch and smartphone displaying the control app

Image 1.1: LoraTap WiFi Smart Relay Switch (Model RR400W) and its mobile application interface.

2. Maklumat Keselamatan

AMARAN: Electrical installation should only be performed by a qualified electrician or in accordance with local electrical codes.
Sentiasa putuskan kuasa pada pemutus litar sebelum memasang atau menservis peranti.
Peranti ini direka untuk kegunaan dalaman sahaja.
Do not exceed the maximum load rating of 10A / 2500W.
Ensure the device is installed in a location with a neutral wire for correct electrical supply.
Jauhkan daripada kanak-kanak.

3. Spesifikasi Produk

Ciri	Spesifikasi
Nombor Model	RR400W
Input Voltage	100-250V AC, 50/60Hz
Beban Maks	10A / 2500W
Protokol Tanpa Wayar	Wi-Fi 2.4GHz (IEEE 802.11 b/g/n)
Dimensi (L x W x H)	4.8 x 4.2 x 2.3 cm (1.89 x 1.65 x 0.91 inci)
Kaedah Kawalan	Remote (App), Voice
Keserasian	Amazon Alexa, Google Assistant, Smart Life App, Tuya App
Pensijilan	CE, RoHS, FCC

4. Panduan Pemasangan

The LoraTap WiFi Smart Relay Switch is designed for easy integration into existing electrical systems. It requires a neutral wire for operation.

Rajah Pendawaian:

Putuskan Kuasa: Before starting, turn off the power at the main circuit breaker to avoid electrical shock.
Kenal pasti wayar: Locate the Live (L) and Neutral (N) input wires from your power source, and the Live (L) and Neutral (N) load wires going to your appliance (e.g., lamp).
Sambungkan Input: Connect the Live input wire to the 'L in' terminal and the Neutral input wire to the 'N in' terminal on the LoraTap switch.
Output Sambung: Connect the Live load wire to the 'L out' terminal and the Neutral load wire to the 'N out' terminal on the LoraTap switch.
Sambungan Selamat: Ensure all wire connections are secure. The device supports 26-16AWG wires.
Pasang Peranti: The compact size allows installation in narrow spaces, such as behind a socket or in a ceiling rose. Use the provided mounting accessories if needed.
Pulihkan Kuasa: Once all connections are secure and the device is properly mounted, restore power at the circuit breaker.

Wiring diagram for LoraTap Smart Relay Switch showing input and output connections for Live and Neutral wires to a lamp

Image 4.1: Simplified wiring diagram for the LoraTap Smart Relay Switch. Ensure a neutral wire is present for installation.

5. Persediaan dan Penggandingan Aplikasi

To control your LoraTap Smart Relay Switch, you need to download the Smart Life or Tuya app and pair the device.

Keperluan:

A smartphone (Android or iOS).
A 2.4GHz Wi-Fi network. 5GHz networks are not supported.
The Smart Life or Tuya app installed on your smartphone.

Langkah Berpasangan:

Muat turun Aplikasi: Cari untuk "Smart Life" or "Tuya Smart" in your smartphone's app store (App Store for iOS, Google Play for Android) and install it.
Daftar/Log Masuk: Buka aplikasi dan daftar akaun baharu atau log masuk dengan akaun sedia ada.
Tambah Peranti: Tap the "+" icon in the top right corner of the app to add a new device. Select "Electrical Switch" or "Switch (Wi-Fi)".
Masukkan Mod Berpasangan: Power on the LoraTap switch. If the indicator light is not blinking rapidly, press and hold the button on the switch for approximately 5 seconds until it blinks rapidly. This indicates pairing mode.
Sambung ke Wi-Fi: In the app, confirm the indicator is blinking rapidly. Enter your 2.4GHz Wi-Fi network name and password.
Berpasangan Lengkap: The app will search for and connect to the device. Once connected, you can rename the device for easier control.

Step-by-step guide for pairing the LoraTap Smart Relay Switch with the Smart Life or Tuya app, showing Wi-Fi compatibility and successful addition.

Image 5.1: Easy pairing process with the Smart Life/Tuya app. Ensure your Wi-Fi network is 2.4GHz.

6. Operasi

The LoraTap Smart Relay Switch offers multiple control options for convenience.

6.1. Kawalan Apl

Once paired, you can control your device from anywhere using the Smart Life or Tuya app on your smartphone.

Kawalan Hidup/Mati: Tap the switch icon in the app to turn your connected appliance on or off.
Status Masa Nyata: The app displays the current status of your appliance, allowing you to verify if it's on or off remotely.
Kawalan Kumpulan: You can group multiple LoraTap switches together in the app to control them simultaneously.
Perkongsian Peranti: Kongsi kawalan peranti dengan ahli keluarga melalui aplikasi.

Woman controlling a smart lamp via the Smart Life app on her smartphone, demonstrating remote control functionality.

Image 6.1: Remote control via the Smart Life app.

Person checking the real-time status of a smart light on their phone while in a car, indicating remote monitoring.

Image 6.2: Real-time status monitoring from anywhere.

Family on a sofa, with a smartphone displaying the device sharing feature in the Smart Life app, allowing multiple users to control the smart switch.

Image 6.3: Device sharing feature for family members.

6.2. Kawalan Suara

The LoraTap Smart Relay Switch is compatible with Amazon Alexa and Google Assistant for convenient voice control.

Pautkan Akaun: Dalam apl Alexa atau Google Home, pautkan akaun Smart Life/Tuya anda.
Cari Peranti: Minta Alexa atau Google Assistant untuk menemui peranti baharu.
Perintah Suara: Use commands like "Alexa, turn on [device name]" or "Hey Google, turn off [device name]".

Woman in a kitchen using voice command 'Alexa, turn on kitchen light' to control a smart light, with Amazon Echo and Google Home devices shown.

Imej 6.4: Integrasi kawalan suara dengan Amazon Alexa dan Google Assistant.

Woman and child in a living room using voice commands to control smart devices, with smart speakers visible.

Image 6.5: Family using voice commands for smart home control.

6.3. Penjadualan dan Pemasa

Automate your appliances by setting schedules and timers within the Smart Life/Tuya app.

Fungsi Pemasa: Set a countdown timer for the switch to turn on or off automatically after a specified duration.
Penjadualan: Create daily or weekly schedules for your appliance to turn on or off at specific times (e.g., turn on lights at sunset, turn off at bedtime).
Fungsi Ulang: Configure schedules to repeat on selected days of the week.

Child sleeping in bed with a smart light above, and a smartphone displaying a countdown timer for the light to turn off.

Image 6.6: Automate lighting with countdown timers.

Woman sleeping in bed, with a smartphone displaying a schedule for smart lights to turn on and off at specific times.

Image 6.7: Program your lights with custom schedules.

6.4. Restart Status Settings

Configure the power-on state of your smart switch after a power outage.

MATI: The device will remain off after power is restored.
ON: The device will turn on automatically after power is restored.
Ingat Status Terakhir: The device will return to its last known state (on or off) before the power outage.

Man in an airport setting, looking at a smartphone displaying restart status options (OFF, ON, Remember last status) for a smart device.

Image 6.8: Configure the device's restart status after a power interruption.

7. Penyelenggaraan

Bersihkan peranti dengan kain lembut dan kering. Jangan gunakan bahan kimia yang keras atau pembersih yang kasar.
Ensure the device is kept in a dry environment and away from direct sunlight or extreme temperatures.
Semak kemas kini perisian tegar dalam aplikasi Smart Life/Tuya secara berkala untuk memastikan prestasi dan keselamatan yang optimum.

8. Penyelesaian masalah

Masalah	Kemungkinan Punca / Penyelesaian
Device not pairing / Indicator not blinking rapidly.	Pastikan peranti dihidupkan. Press and hold the button on the switch for 5 seconds to enter pairing mode. Verify your Wi-Fi network is 2.4GHz. Ensure your phone is connected to the 2.4GHz Wi-Fi network during pairing. Alihkan peranti lebih dekat dengan penghala Wi-Fi anda.
Peranti luar talian dalam apl.	Periksa sama ada penghala Wi-Fi anda berfungsi dengan betul. Ensure the device has stable power. Mulakan semula peranti dengan mematikan dan menghidupkan kuasa pada pemutus litar. Jika masalah berterusan, cuba pasangkan semula peranti tersebut.
Kawalan suara tidak berfungsi.	Ensure your Smart Life/Tuya account is correctly linked to Alexa/Google Assistant. Check the device name in the Alexa/Google Home app and use that name in your commands. Verify your smart speaker is connected to the internet.
Device not responding to manual switch.	Ensure the manual switch is wired correctly to the LoraTap module (if applicable, for external switch integration). Some installations might bypass the physical switch for direct smart control.

9. Waranti dan Sokongan

LoraTap offers a 3-year warranty for this product. For technical support or warranty claims, please contact LoraTap customer service through their official webtapak atau peruncit tempat anda membeli produk tersebut.

Maklumat Hubungan: Please refer to the packaging or LoraTap's official weblaman web untuk mendapatkan butiran hubungan sokongan terkini.
