1. Pengenalan
This manual provides essential information for the safe and efficient installation, operation, and maintenance of your Lutec Trumpet 5626101125 LED Outdoor Wall Light. Please read these instructions thoroughly before installation and retain them for future reference.

Figure 1.1: Lutec Trumpet 5626101125 LED Outdoor Wall Light, front view.
2. Maklumat Keselamatan
- Keselamatan Elektrik: Installation must be performed by a qualified electrician in accordance with local wiring regulations. Ensure the main power supply is switched off before commencing any work.
- Penggunaan Luaran: This product is designed for outdoor installations and has an IP54 rating, indicating protection against dust ingress and splashing water.
- Pengendalian: Handle the luminaire with care to avoid damage to the LED components or housing.
- Sumber Kuasa: The light operates on a wired electrical connection (230 Volts).
3. Kandungan Pakej
Sahkan bahawa semua komponen hadir sebelum memulakan pemasangan:
- 1x Lutec Trumpet 5626101125 LED Outdoor Wall Light (Luminaire)
Note: Mounting hardware (screws, wall plugs) may not be included and should be sourced separately if required.
4. Persediaan dan Pemasangan
The Lutec Trumpet 5626101125 is designed for wall mounting (flush mount installation).
- Penyediaan: Ensure the power supply to the installation area is completely disconnected at the main circuit breaker.
- Lokasi Pemasangan: Choose a suitable outdoor wall location. Consider the desired light distribution and ensure the surface is stable and can support the luminaire's weight (400g).
- Penandaan: Use the luminaire's mounting plate as a template to mark the drilling points on the wall.
- Penggerudian: Tebuk lubang pada titik yang ditanda. Masukkan palam dinding yang sesuai jika perlu.
- Pendawaian: Connect the electrical wires from the wall to the luminaire's terminal block. Ensure correct polarity (Live, Neutral, Earth) according to local electrical codes. Secure all connections.
- Mounting the Luminaire: Attach the luminaire securely to the wall using appropriate screws. Ensure a tight seal to maintain the IP54 rating.
- Semakan Akhir: Once installed, restore power to the circuit.

Gambar 4.1: Cthample of the Lutec Trumpet wall light installed on an exterior wall.
5. Arahan Operasi
The Lutec Trumpet 5626101125 LED Outdoor Wall Light operates via a standard external wall switch connected to its electrical supply. There is no integrated tactile switch for direct control on the unit itself for typical outdoor installations.
- Menghidupkan/Mematikan: Gunakan suis dinding yang disambungkan untuk menghidupkan atau mematikan lampu.
- Output Cahaya: The integrated LED provides 600 lumens of warm white light at 4000 Kelvin.
6. Penyelenggaraan
The Lutec Trumpet wall light is designed for durability and requires minimal maintenance.
- Pembersihan: To clean the luminaire, ensure the power is off. Wipe the surface with a soft, damp cloth. Do not use abrasive cleaners or solvents, as these can damage the anthracite powder coating and LED diffuser.
- Pemeriksaan: Periodically inspect the luminaire for any signs of damage, loose connections, or wear. If any issues are found, disconnect power and consult a qualified electrician.
- Modul LED: The LED module is integrated and not user-replaceable.
7. Penyelesaian masalah
If you encounter issues with your Lutec Trumpet wall light, refer to the following common problems and solutions:
| Masalah | Kemungkinan Punca | Penyelesaian |
|---|---|---|
| Cahaya tidak menyala. | No power supply, faulty wiring, or damaged LED. | Check circuit breaker. Verify wiring connections (consult electrician). If LED is damaged, the unit may need replacement. |
| Cahaya berkelip-kelip. | Unstable power supply or loose connection. | Ensure stable power. Check wiring connections (consult electrician). |
| Water ingress inside the luminaire. | Pemasangan yang tidak betul atau meterai yang rosak. | Immediately disconnect power. Re-check installation for proper sealing. If seal is damaged, the unit may need replacement. |
If the problem persists after attempting these solutions, contact a qualified electrician or Lutec customer support.
8. Spesifikasi
Technical details for the Lutec Trumpet 5626101125 LED Outdoor Wall Light:
| Ciri | Spesifikasi |
|---|---|
| Jenama | LITEC |
| Nombor Model | 5626101125 |
| Dimensi (L x W x H) | 15 x 13 x 18 cm |
| Berat badan | 400 gram |
| bahan | Aluminium die-cast |
| Selesai | Powder coating (Anthracite) |
| Peringkat Perlindungan Ingress (IP). | IP54 |
| Penggunaan Kuasa | 8 Watt (Maks), 6 Watt (Nominal) |
| Voltage | 230 Volt |
| Fluks Bercahaya | 600 lm |
| Suhu Warna | 4000 Kelvin (Putih Hangat) |
| Jenis Sumber Cahaya | LED bersepadu |
| Kelas Kecekapan Tenaga | D |
| Nombor Pendaftaran EPREL | 819436 (View EPREL Data) |

Figure 8.1: Energy label for Lutec Trumpet 5626101125, showing energy efficiency class D.
9. Waranti dan Sokongan
Information regarding spare parts availability for this product is not available. For warranty claims or technical support, please contact Lutec customer service.
- Pengeluar: Lutec
- Alamat: Lutec Europe NV, Herentalsebaan 425, 2160 Wommelgem, Belgium
- Webtapak: www.lutec.com
- e-mel: info@lutec-europe.com
- telefon: +3232845162
