1. Pengenalan
The Joyoung DJ13U-P10 is an automatic home kitchen appliance designed for making various beverages, including soy milk, nut milk, rice paste, and porridge. It features superfine grinding technology and a 4D induction heating system for efficient and quiet operation.
Ciri-ciri utama termasuk:
- Pelbagai Fungsi: Dry/Soaked beans, Classic soy, Grains, Rice paste, Nut, Porridge, Corn juice, Juice, Date soy, Goji soy, Rose soy.
- Operasi senyap: Creative grinder design and 4D induction heating system reduce noise effectively.
- Time & Temperature Presets: Automatically maintains the set temperature after preparation and allows for delayed start.
- Wider Capacity: Adjustable capacity from 500ml to 1300ml, suitable for 2 to 5 persons.
- Teknologi Tanpa Penapis: Designed for systematic grinding and better nutrient release, eliminating the need for straining in many preparations.
2. Persediaan
2.1 Menyahkotak dan Komponen
Carefully remove all components from the packaging. Ensure all parts are present before initial use.
Pakej biasanya termasuk:
- Soy Milk Maker Main Unit
- Small Measuring Cup
- Berus Pembersih
- Large Measuring Cups
- Kord Kuasa
- Manual Arahan
2.2 Pembersihan Awal
Before first use, it is recommended to perform a deep cleaning cycle. Fill the water tank to the 'Cleaning Level' (approximately 300ml) and select the 'Clean' function. This cycle typically takes 8 minutes and uses steam cleaning to ensure thorough sanitation of the grinding pot and internal components.
3. Arahan Operasi
3.1 Menyediakan Bahan
Measure your desired ingredients (e.g., soybeans, nuts, grains) using the provided measuring cups. For best results, ensure ingredients are clean and free from debris.
3.2 Menambah Air
Pour water into the main pot up to the desired measurement line (500ml, 800ml, 1000ml, or 1300ml) indicated on the interior of the pot. Ensure the water level is between the minimum and maximum marks.
3.3 Memilih Fungsi
Close the lid securely. The control panel offers various preset functions:
- Bijirin: For mixed grain beverages.
- Dry/Soaked Beans: For soy milk from dry or pre-soaked soybeans.
- Pes Beras: For making smooth rice paste.
- Aromatic Soymilk: For a richer soy milk flavor.
- Bubur: Untuk memasak bubur.
- Susu Kacang: For various nut-based milks.
- Jus: For blending fresh juices.
- Basuh Mudah: A quick cleaning cycle.
- Rapid Soymilk: For faster soy milk preparation.
- Pemanasan: To keep beverages warm.
Press the 'Select' button repeatedly until the desired function light illuminates. Then, press 'Start' to begin the process.
3.4 Using Preset Time and Temperature
The machine allows you to preset the time for a delayed start. It will also automatically maintain the set temperature of the beverage after preparation. Refer to the specific instructions in the full manual for detailed programming steps.
3.5 Straining (Optional)
While the DJ13U-P10 features filterless technology for fine grinding, some users may prefer an even smoother texture. If desired, pour the prepared beverage through the provided filter or a fine-mesh sieve into the large measuring cup. Use a spoon to gently press the solids to extract additional liquid.
4. Penyelenggaraan
4.1 Pembersihan Automatik
After each use, it is recommended to run the 'Easy Wash' cycle. Fill the water tank to the 'Cleaning Level' and select the 'Easy Wash' function. This will help remove residue and keep the machine clean.
4.2 Pembersihan Manual
For thorough cleaning, especially after preparing thick beverages, unplug the machine and allow it to cool. Carefully detach the grinding head and rinse it under running water. Use the provided cleaning brush to remove any stubborn residue from the blades and interior of the pot. Wipe the exterior of the machine with a damp kain. Jangan rendam unit utama dalam air.
5. Penyelesaian masalah
If the machine encounters an issue, it may display an error code. Refer to the table below for common error codes and their solutions:
| Kod Ralat | Penerangan | Penyelesaian |
|---|---|---|
| E01 | Glass jar not in place or incorrectly positioned. | Ensure the glass jar is correctly placed on the base. |
| E02 | Tangki air kosong atau paras air terlalu rendah. | Isikan tangki air ke paras yang sesuai. |
| E03 | Grinding compartment lid is not closed securely. | Close the grinding compartment lid firmly until it clicks into place. |
| E04 | Excess ingredients or too thick mixture causing overflow. | Reduce the amount of ingredients or adjust the water-to-ingredient ratio. Scoop out excess if needed. |
| E05 | Motor overheating or malfunction. | Unplug the machine, allow it to cool down, then restart. If the issue persists, contact customer support. |
| E06 | Other system malfunction. | Unplug the machine and restart. If the issue persists, contact customer support. |
6. Spesifikasi
- Model Produk: DJ13U-P10
- kapasiti: 500-1300ml
- Input Voltage: 120 V-60 Hz
- Kuasa Dinilai: 1200 W
- Kuasa Motor: 300 W
- Kelajuan Motor: 20000 r/min
- Sesuai Untuk: 2-4 orang
- Dimensi Produk: 230x180x310mm (7.09"D x 9.06"W x 12.2"H)
- Berat Bersih: 2.6 KG (5.73 paun)
- Jenis kawalan: Sentuh
- Bahan Bilah: Keluli Aloi
- Bahan Bekas: plastik
- warna: Hitam
- Ciri Khas: Pemanasan Induksi
- UPC: 745780736731, 791281864138, 791281864145
- Tahun Pengilangan: 2019
- Tarikh Mula-mula Tersedia: 3 Januari 2019
7. Waranti dan Sokongan
7.1 Maklumat Waranti
The Joyoung DJ13U-P10 Soy Milk Maker comes with a Waranti 12 bulan dari tarikh pembelian. Sila simpan bukti pembelian anda untuk tuntutan waranti.
7.2 Sokongan Pelanggan
For technical assistance, troubleshooting beyond the provided guide, or warranty service, please contact Joyoung customer support. Refer to the contact information provided in your product packaging or visit the official Joyoung webtapak.
