1. Pengenalan
This manual provides essential information for the safe operation, assembly, maintenance, and troubleshooting of your Greenworks 40V 14-inch Cordless Dethatcher/Scarifier. Please read this manual thoroughly before operating the product and retain it for future reference.
The Greenworks 40V Cordless Dethatcher/Scarifier is designed for removing thatch and debris from lawns, promoting healthier grass growth. It features a powerful 40V motor, a 14-inch dethatching path, and durable stainless steel tines.
2. Maklumat Keselamatan
Amaran Keselamatan Am
- Always wear appropriate personal protective equipment (PPE), including eye protection, hearing protection, and sturdy footwear, when operating the dethatcher.
- Keep children and bystanders at a safe distance (at least 50 feet/15 meters) from the operating area.
- Inspect the work area for objects such as rocks, toys, or wires that could be thrown or entangled in the tines. Remove any such objects before operation.
- Ensure the battery is removed from the tool before performing any adjustments, cleaning, or maintenance.
- Do not operate the dethatcher in wet conditions or on slopes that are too steep to maintain stable footing.
- Familiarize yourself with the controls and how to stop the machine quickly in an emergency.
Keselamatan Bateri
- Use only Greenworks 40V batteries and chargers with this product.
- Jangan dedahkan bateri kepada air, haba atau cahaya matahari langsung.
- Store batteries in a cool, dry place away from metal objects.
- Do not attempt to open or modify the battery pack.
3. Kandungan Pakej
Carefully unpack your dethatcher and ensure all items are present and undamaged. If any parts are missing or damaged, contact Greenworks customer service.
- Greenworks 40V 14-inch Cordless Dethatcher/Scarifier Unit
- Bateri Litium-Ion 40V 4Ah
- Pengecas Bateri
- Replacement Tines (Full Set)
- Operator's Manual (This Document)
Gambar 3.1: Lebihview of the Greenworks 40V Dethatcher with key components labeled, including the push button start, tine depth controller, 4.0 Ah battery and charger, 14-inch dethatching path, 7-inch wheels, stainless steel tines, and folding handles. A full set of replacement tines is also shown.
4. Perhimpunan
The dethatcher requires minimal assembly. Follow these steps to prepare your unit for use.
4.1 Mengendalikan Pemasangan
- Buka lipatan bahagian pemegang bawah dan selamatkannya ke dalam kedudukannya.
- Attach the upper handle section to the lower handle, ensuring all cables are routed correctly and not pinched.
- Tighten any knobs or levers to secure the handle in place. The handles are designed to fold for convenient storage.
5. Persediaan
5.1 Mengecas Bateri
Before first use, fully charge the 40V 4Ah Lithium-Ion battery.
- Sambungkan pengecas ke soket elektrik standard.
- Slide the battery pack onto the charger. The indicator lights on the charger will show the charging status.
- A full recharge typically takes approximately 120 minutes.
Figure 5.1: The Greenworks 40V 4Ah Lithium-Ion battery and its quick charger, ready for charging.
5.2 Memasang Bateri
Once charged, install the battery into the dethatcher unit.
- Open the battery compartment cover on the dethatcher.
- Jajarkan bateri dengan slot bateri dan luncurkannya ke dalam sehingga ia mengklik dengan selamat ke tempatnya.
- Tutup penutup petak bateri.
Figure 5.2: A user inserting the removable 40V Lithium-Ion battery into the dethatcher's battery compartment.
5.3 Adjusting Tine Depth
The dethatcher features a 3-position tine adjustment to suit different lawn conditions.
- Locate the tine depth controller on the side of the unit.
- Adjust the lever to one of the three positions: shallow, medium, or deep.
- For initial dethatching or lighter thatch, start with a shallower setting. For heavier thatch, a deeper setting may be required.
Figure 5.3: The dethatcher operating at a 3/8-inch dethatching depth, illustrating the tines' engagement with the lawn.
6. Arahan Operasi
6.1 Starting the Dethatcher
- Pastikan bateri dicas sepenuhnya dan dipasang dengan selamat.
- Press and hold the safety cut-off switch on the handle.
- While holding the safety switch, press the push-button start to engage the motor.
Figure 6.1: A user's hands on the dethatcher handle, demonstrating the easy push-button start mechanism.
6.2 Dethatching Your Lawn
Walk at a steady pace, overlapping each pass slightly to ensure even coverage. The 14-inch dethatching path allows for efficient coverage.
Figure 6.2: A person operating the dethatcher on a lawn, illustrating the 14-inch dethatching path for efficient coverage.
The dethatcher is equipped with 7-inch wheels for easy maneuverability across various terrains.
Rajah 6.3: Gambar jarak dekat view of the dethatcher's 7-inch wheels, designed for easy maneuverability over varied terrain.
The 4Ah battery provides up to 30 minutes of runtime, allowing you to cover significant areas.
Figure 6.4: A user operating the dethatcher, demonstrating its cordless convenience and highlighting the 30-minute runtime with a 4.0 Ah battery.
6.3 Stopping the Dethatcher
Release the push-button start and the safety cut-off switch to stop the motor. Always remove the battery when not in use or before any maintenance.
7. Penyelenggaraan
Regular maintenance ensures optimal performance and extends the life of your dethatcher.
7.1 Pembersihan
- Sentiasa keluarkan bateri sebelum membersihkan.
- Use a stiff brush or compressed air to remove grass clippings and debris from the tines, housing, and vents.
- Lap bahagian luar dengan iklanamp kain. Jangan gunakan bahan kimia yang keras atau pembersih yang kasar.
7.2 Penggantian Tine
The dethatcher uses durable stainless steel tines. Replace them when they become worn or damaged.
Rajah 7.1: Gambar jarak dekat view of the stainless steel tines, designed for durability and effective dethatching.
- Pastikan bateri ditanggalkan.
- Carefully turn the dethatcher over to access the tine assembly.
- Using the appropriate tool, remove the fasteners securing the worn tines.
- Install new replacement tines, ensuring they are correctly oriented and securely fastened.
8. Penyelesaian masalah
This section addresses common issues you might encounter with your dethatcher.
| Masalah | Kemungkinan Punca | Penyelesaian |
|---|---|---|
| Dethatcher does not start | Bateri tidak dipasang dengan betul Bateri tidak dicas Suis keselamatan tidak dihidupkan | Pastikan bateri terpasang sepenuhnya Cas bateri Press and hold safety switch before pressing start button |
| Poor dethatching performance | Tines are worn or damaged Tine depth setting is too shallow Excessive thatch buildup | Replace tines Adjust to a deeper setting Make multiple passes or consider a deeper setting |
| Motor berhenti semasa operasi | Cas bateri rendah Overload due to dense thatch/debris | Isi semula bateri Clear any obstructions; reduce working speed |
9. Spesifikasi
| Ciri | Perincian |
|---|---|
| Nombor Model | DT40L00 (DHF301) |
| Jenama | Greenworks |
| Sumber Kuasa | Bateri Lithium-Ion 40V |
| Kapasiti Bateri | 4Ah (Included) |
| Pengecas Termasuk | ya |
| Masa Mengecas | lebih kurang 120 minit |
| Runtime (with 4Ah battery) | Sehingga 30 minit |
| Laluan Menyahcantum | 14 inci |
| Kedalaman Menyahcair | 3/8 inch (adjustable) |
| Bahan Tine | Keluli Tahan Karat |
| Berat Barang | 16.54 paun |
| Dimensi Produk | 23.62"D x 16.54"W x 12.6"H |
| Perhimpunan Diperlukan | ya |
| UPC | 841821054755, 841821025106 |
10. Waranti dan Sokongan
Maklumat Waranti
This Greenworks dethatcher comes with a Waranti alat dan bateri selama 3 tahun, providing peace of mind against manufacturing defects and material flaws under normal use. Please refer to the warranty card included with your product for full terms and conditions, or visit the official Greenworks webtapak untuk maklumat polisi jaminan terperinci.
Figure 10.1: The Greenworks 3-year tool and battery warranty emblem, signifying product reliability.
Sokongan Pelanggan
Untuk bantuan teknikal, alat ganti atau tuntutan waranti, sila hubungi sokongan pelanggan Greenworks. Maklumat hubungan biasanya boleh didapati di Greenworks webtapak atau pada pembungkusan produk.
