pengenalan
This manual provides essential information for the safe and efficient setup, operation, and maintenance of your Intex Inflatable Easy Set Above Ground Round Swimming Pool. Please read all instructions carefully before assembly and use. Retain this manual for future reference.
Image: The Intex Easy Set Pool shown with its included accessories: filter pump, ladder, pool cover, and ground cloth.
Maklumat Keselamatan Penting
AMARAN: Kegagalan mematuhi arahan ini boleh mengakibatkan kecederaan serius atau kematian.
- Sentiasa awasi kanak-kanak di dalam dan di sekitar kolam renang.
- Do not dive or jump into the pool. The water depth is 36 inches (91 cm).
- Ensure the pool is set up on a completely level surface to prevent collapse.
- Keep all electrical cords, pumps, and filters away from water and out of reach of children.
- Review peraturan dan sekatan HOA anda sebelum pembelianasing and setting up this product. Not all housing agencies permit private above-ground pools.
- Empty the pool completely when not in use for extended periods or during cold weather.
Kandungan Pakej
Your Intex Easy Set Pool package includes the following components:
- Inflatable Pool Liner (15 ft x 42 in)
- Krystal Clear™ Cartridge Filter Pump (Model 28637EG)
- Filter Cartridges (Type A)
- Removable Pool Ladder
- Kolam Renang
- Kain Tanah
Image: Diagram showing the dimensions of the Intex Easy Set Pool: 15 ft diameter, 42 inches height, and 36 inches water depth. Water capacity is 3,736 gallons.
Arahan Persediaan
The Intex Easy Set Pool is designed for quick and simple setup, typically ready for water in as little as 30 minutes.
1. Penyediaan Tapak
- Choose a firm, level surface free of sharp objects, debris, or loose soil. The ground must be completely level to ensure proper pool structure and prevent collapse.
- Clear the area of any grass, roots, or rocks.
- Ensure the chosen location is near a power outlet for the filter pump and a water source for filling.
Image: An Intex Easy Set Pool set up on a blue ground cloth on a grassy lawn, demonstrating proper site preparation.
2. Laying the Ground Cloth
- Unfold the ground cloth and spread it evenly over the prepared level surface. This provides added protection for the pool bottom.
3. Unfolding the Pool Liner
- Carefully unfold the pool liner on top of the ground cloth.
- Spread it out completely, ensuring the drain plug is facing the desired drainage area.
- Tiupkan gegelung atas kolam menggunakan pam udara (tidak disertakan). Pastikan ia teguh tetapi tidak terlalu kembung.
4. Mengisi Kolam
- Begin filling the pool with water. As the water level rises, the pool walls will rise and take shape.
- Smooth out any wrinkles in the bottom of the pool as it fills.
- Fill the pool to approximately 80% capacity, or to the fill line indicated on the pool liner. This pool holds up to 3,739 gallons of water when 80% full.
5. Filter Pump Installation
- Connect the Krystal Clear™ Cartridge Filter Pump (Model 28637EG) according to the pump's separate instruction manual.
- Pastikan semua sambungan selamat dan bebas bocor.
- The pump has a flow rate of 1,000 gallons per hour and comes with filter cartridges.
Image: A close-up of the Krystal Clear Cartridge Filter Pump, showing its design and hose connections.
6. Ladder Assembly and Placement
- Assemble the removable pool ladder following its specific instructions.
- Place the ladder securely against the pool wall. Always ensure the ladder is stable before use.
Image: A standalone image of the Intex pool ladder, featuring its grey frame and white steps.
Mengendalikan Kolam Anda
Operasi Pam Penapis
- Once the pool is filled and the pump is connected, plug in the filter pump.
- Run the pump daily to circulate and filter the water. The duration depends on pool usage and water quality, but typically 2-10 hours per day is recommended.
- The Krystal Clear™ system uses Hydro Aeration Technology to improve filtration, clarity, and freshness by injecting air into the water, accelerating circulation, and clumping fine particles for better filtration.
Image: A visual representation of Intex's Hydro Aeration Technology, showing air bubbles being introduced into the pool water to enhance filtration and clarity.
Kimia Air
- Uji air kolam anda secara berkala untuk tahap pH, klorin dan kealkalian menggunakan kit ujian kolam (tidak disertakan).
- Add appropriate pool chemicals as needed to maintain balanced water chemistry.
Penyelenggaraan
Pembersihan dan Penggantian Kartrij Penapis
- Matikan dan cabut plag pam penapis sebelum melakukan sebarang penyelenggaraan.
- Remove the filter cartridge and rinse it with a garden hose to remove debris.
- Replace the filter cartridge every two weeks for best results, or more frequently if the water appears cloudy or the pump flow rate decreases.
Image: The Krystal Clear Cartridge Filter Pump alongside a Type A filter cartridge, indicating that one replaceable cartridge is included and replacement every two weeks is recommended.
Pembersihan Kolam
- Use a pool skimmer net to remove leaves and other floating debris from the water surface.
- Periodically vacuum the pool bottom to remove settled dirt and debris.
Pool Cover Usage
- Use the included pool cover when the pool is not in use to keep it free of dirt and debris.
- The cover is constructed of high-quality, durable vinyl with drain holes to prevent water buildups and features a 12-inch overhang for a secure fit.
Image: An Intex Easy Set Pool covered with its grey pool cover, demonstrating how it protects the pool from debris.
Musim sejuk dan Penyimpanan
- Before freezing temperatures, completely drain the pool using the drain plug.
- Clean and dry all components thoroughly before storing them in a cool, dry place.
Menyelesaikan masalah
| Masalah | Kemungkinan Punca | Penyelesaian |
|---|---|---|
| Kolam kehilangan udara dari gelanggang atas | Small puncture or leak in the inflatable ring. | Locate the leak using soapy water, then patch with the included repair kit (if applicable) or a vinyl repair kit. |
| Water not clear/cloudy | Insufficient filtration, dirty filter cartridge, unbalanced water chemistry. | Run pump longer, clean or replace filter cartridge, test and adjust water chemistry (chlorine, pH). |
| Pam tidak berjalan | Isu kuasa, pendesak tersumbat, kunci udara. | Check power connection, ensure GFCI is not tripped. Refer to pump manual for impeller cleaning and airlock removal. |
| Pool walls leaning/uneven water level | Pool not set up on a level surface. | This requires draining the pool, re-leveling the ground, and refilling. This is critical for pool stability. |
Spesifikasi
| Ciri | Perincian |
|---|---|
| Jenama | Intex |
| Nombor Model | 26165EH+28023E |
| Pool Dimensions (Diameter x Height) | 15 ft x 42 in (180"L x 180"W x 42"H) |
| Kedalaman Air | 36 inci (91 cm) |
| Kapasiti Air (80% penuh) | 3,736 gelen (14,142 L) |
| bahan | Durable 3-ply Vinyl (Puncture-resistant) |
| Filter Pump Model | Krystal Clear™ 28637EG |
| Kadar Aliran Pam | 1,000 gallons per hour (3,785 L/hr) |
| System Flow Rate | 750 gph (2,839 lph) |
| Jenis Kartrij Penapis | Jenis A |
| Kapasiti Berat Tangga | 300 lbs. (Kg 136) |
| UPC | 078257397648 |
Image: Diagram illustrating the pool size of 15' x 42" (4.57 m x 106.7 cm).
Image: Diagram illustrating the water depth of 36" (91 cm).
Image: Diagram illustrating the water capacity of 3,736 gallons (14,142 L).
Waranti dan Sokongan
For warranty information and customer support, please refer to the documentation included with your product or visit the official Intex webtapak.
Anda juga boleh melawat Kedai Intex di Amazon untuk mendapatkan lebih banyak maklumat produk dan sumber sokongan.
