1. Pengenalan
This manual provides essential information for the safe and effective operation of your Vangoa 65W Electric Drum Amplifier. Designed for electronic percussion products, this amplifier delivers 65 watts of power, suitable for various performance and practice environments. It features an 8-inch woofer and a 2-inch tweeter for balanced sound reproduction, along with multiple connectivity options including dual microphone inputs, instrument inputs, headphone output, USB, and wireless input.
2. Ciri-ciri Utama
- Output Kuasa Tinggi 65W: Provides sufficient amplification for electronic drum practice, studio rehearsals, street performances, karaoke, and live stage penggunaan.
- Rich and Dynamic Tone: Equipped with an 8-inch woofer and a 2-inch tweeter for expressive classic tones and responsive audio. Features 3-band EQ (High, Mid, Low) for sound shaping.
- Kesambungan Pelbagai: Includes dual independent microphone channels, headphone output, USB interface, and wireless input for devices like phones and audio players.
- Multiple Instrument Inputs: Two independent drum input interfaces for connecting electronic drums, electric guitars, keyboards, and other instruments.
- Panel Kawalan Intuitif: Simple and practical operating area on the top for easy adjustment of equalizer settings and volume.
3. Produk Lebihview
Rajah 1: Depan view of the Vangoa 65W Electric Drum Amplifier highlighting key features.
Rajah 2: Amplifier dimensions (16.14 x 14.17 x 13.39 inches).
Figure 3: Top panel showing diverse connection options and controls.
Figure 4: Illustration of the 8-inch woofer and 2-inch tweeter for professional sound.
Figure 5: USB and Bluetooth connectivity for wide compatibility.
Figure 6: Detailed diagram of inputs for microphones, drums, line-in, and USB/Bluetooth.
Video Produk
Video 1: Produk ringkas berakhirview demonstrating the amplifier's features and design.
Video 2: Short demonstration of the Vangoa 65W Electric Drum Amp in action, showcasing its powerful sound.
4. Panduan Persediaan
- Membongkar: Buang dengan berhati-hati amppemekat daripada pembungkusannya. Simpan semua bahan pembungkusan untuk pengangkutan atau penyimpanan pada masa hadapan.
- penempatan: Letakkan amplifier on a stable, flat surface. Ensure adequate ventilation around the unit. The amplifier is designed with an elevation angle for optimal sound projection towards the user.
- Sambungan Kuasa: Connect the provided power cord to the amplifier's power input and then to a suitable electrical outlet. Ensure the power switch is in the 'OFF' position before connecting.
- Kuasa Awal Hidup: Flip the power switch to the 'ON' position. The power indicator light should illuminate.
- Pelarasan Kelantangan: Before connecting any instruments, ensure all volume knobs (Master, Drum, Line, Mic) are set to their minimum positions to prevent sudden loud sounds.
5. Arahan Operasi
5.1 Menyambungkan Instrumen dan Mikrofon
- Electronic Drums: Connect your electronic drum module's output to the 'DRUM IN' input using a standard instrument cable. Adjust the 'DRUM' volume knob to control the drum sound level.
- Other Instruments (Keyboard, Guitar): Use the 'LINE IN' inputs for connecting other instruments. Adjust the 'LINE' volume knob.
- Mikrofon: Connect microphones to the 'MIC 1' or 'MIC 2' inputs. Each microphone input has an independent volume control ('MIC VOL').
- Fon kepala: For private practice, connect headphones to the 'PHONES' output. This will mute the main speaker output.
5.2 Equalizer (EQ) Adjustment
The amplifier features a 3-band equalizer to shape your sound:
- ASAS: Adjusts the low-frequency response. Turn clockwise to boost bass, counter-clockwise to cut.
- PERTENGAHAN: Adjusts the mid-range frequency response. Turn clockwise to boost mids, counter-clockwise to cut.
- Treble: Adjusts the high-frequency response. Turn clockwise to boost treble, counter-clockwise to cut.
Experiment with these controls to achieve your desired tone for different instruments and musical styles.
5.3 Wireless and USB Playback
- Tanpa Wayar (Bluetooth): Activate Bluetooth on your external device (e.g., smartphone, tablet). Select the amplifier from the list of available devices to pair. Once connected, you can play audio through the amplifier. Use the 'BT/MP3' volume control on the amplifier and your device's volume control.
- Main balik USB: Masukkan pemacu USB yang mengandungi audio files into the 'USB' port. The amplifier will automatically detect and begin playing the files. Use the playback controls (play/pause, next/previous track) and the 'BT/MP3' volume control.
5.4 Isipadu Induk
The 'MASTER' volume knob controls the overall output level of the amplifier. Adjust this after setting individual input volumes to achieve the desired total loudness.
6. Spesifikasi
| Ciri | Spesifikasi |
|---|---|
| Output Wattage | 65 Watt |
| Konfigurasi Pembesar Suara | 8-inch Woofer, 2-inch Tweeter |
| Respons Kekerapan | 45 Hz hingga 20 kHz |
| Input | 2x Drum/Line Inputs (6.35mm Jack), 2x Mic Inputs, Aux Input, USB |
| Keluaran | Output Fon Kepala |
| Kesambungan Wayarles | Bluetooth |
| Penyamaan | 3-Jalur (Bes, Pertengahan, Treble) |
| Dimensi (L x W x H) | 16.14 x 14.17 x 13.39 inci |
| Berat Barang | 17.06 paun |
| bahan | Logam, Plastik |
| warna | Hitam |
7. Penyelenggaraan
- Pembersihan: Gunakan kain lembut dan kering untuk membersihkan bahagian luar amplifier. Do not use liquid cleaners or solvents, as they may damage the finish or internal components.
- Storan: Apabila tidak digunakan untuk tempoh yang lama, simpan ampliifier di tempat yang sejuk dan kering, jauh dari cahaya matahari langsung dan suhu yang melampau.
- Pengudaraan: Memastikan bahawa amplifier's ventilation openings are not blocked to prevent overheating.
- Penjagaan Kabel: Regularly inspect all cables for signs of wear or damage. Replace any damaged cables immediately to ensure safe operation.
8. Penyelesaian masalah
- Tiada Kuasa:
- Check if the power cord is securely connected to both the amplifier and the electrical outlet.
- Sahkan bahawa salur keluar kuasa berfungsi.
- Pastikan suis kuasa dihidupkan amplifier is in the 'ON' position.
- Tiada Keluaran Bunyi:
- Confirm that all volume knobs (Master, Drum, Line, Mic, BT/MP3) are turned up to an audible level.
- Check all instrument and microphone cables for secure connections and proper functionality.
- If using headphones, ensure they are properly connected and that the main speaker output is not muted unexpectedly.
- If using wireless or USB input, ensure the device is properly paired/connected and playing audio.
- Bunyi Herot:
- Reduce the volume levels of the input source, individual channels, and the Master volume.
- Adjust the EQ settings (Bass, Mid, Treble) to reduce excessive boosting of certain frequencies.
- Ensure instrument cables are not damaged or faulty.
- Isu Sambungan Tanpa Wayar:
- Memastikan amplifier's wireless function is active.
- Move the external device closer to the amppenguat untuk meningkatkan kekuatan isyarat.
- Disconnect and re-pair the Bluetooth device.
9. Waranti dan Sokongan
Vangoa products are designed and manufactured to high-quality standards. For warranty information, please refer to the warranty card included with your product or visit the official Vangoa website. For technical support, troubleshooting assistance, or service inquiries, please contact Vangoa customer support through their official channels.
Sila simpan bukti pembelian anda untuk sebarang tuntutan waranti.
