The Plugable USB 3.0 to HDMI Video Graphics Adapter (Model: UGA-2KHDMI) allows you to connect an additional HDMI display to your computer via a USB 3.0 port. This adapter utilizes DisplayLink technology to provide high-resolution video output, supporting resolutions up to 2560x1440. It is designed to enhance productivity by enabling multi-monitor setups for various tasks, from professional work to educational use. Its compact and portable design ensures convenience for users on the go.
Figure 1: The Plugable USB 3.0 to HDMI Video Graphics Adapter, showing its HDMI output and USB 3.0 input. It is a compact black device.
Apa yang ada dalam Kotak
- 1x Plugable USB 3.0 to HDMI Video Graphics Adapter (UGA-2KHDMI)
- Panduan Mula Pantas (tidak termasuk dalam manual digital ini)
Figure 2: The Plugable UGA-2KHDMI adapter shown within its retail packaging, indicating the product and its basic information.
Arahan Persediaan
- Pemasangan Pemandu: Before connecting the adapter, ensure the necessary DisplayLink drivers are installed on your computer. For Windows and macOS 10.14+, drivers can typically be downloaded from the official DisplayLink website or Plugable support page.
- Sambung ke Komputer: Plug the USB 3.0 connector of the UGA-2KHDMI adapter into an available USB 3.0 port on your laptop, desktop, or tablet.
- Sambung ke Paparan: Connect an HDMI cable from your external monitor to the HDMI port on the UGA-2KHDMI adapter.
- Hidupkan kuasa: Power on your external monitor. Your computer should detect the new display.
- Konfigurasikan Tetapan Paparan: Access your operating system's display settings to configure the new monitor (e.g., extend display, duplicate display, resolution).
Figure 3: Illustrates the connection process of the adapter, showing the USB end plugged into a laptop and the HDMI end connected to an external monitor.
Video 1: Official Plugable video demonstrating the setup and functionality of the USB 3.0 to 2K HDMI Video Graphics Adapter, showing how to connect it and expand your screen space.
Arahan Operasi
Once the adapter is connected and drivers are installed, your operating system will recognize the new display. You can then configure it to suit your needs:
- Extend Display: This mode allows you to have a larger desktop area, spreading your applications across multiple screens. This is ideal for multitasking and increasing produktiviti.
- Duplicate Display (Mirror): This mode shows the same content on both your primary and external displays. Useful for presentations or sharing content.
- Paparan Utama: You can set the external monitor as your primary display, with your laptop screen acting as an extended or secondary display.
The adapter supports resolutions up to 2560x1440. For optimal performance, ensure your monitor and computer graphics card support the desired resolution.
Figure 4: An illustration demonstrating how multiple adapters can be used to create an extensive multi-monitor setup on Windows and ChromeOS, and up to 4 displays on macOS.
Keserasian
The UGA-2KHDMI adapter offers broad compatibility:
- Sistem Operasi:
- Windows: Compatible with modern Windows laptops, desktops, or tablets, including Windows 11, 10, 7, and XP.
- macOS: Supports M1/M2/M3/M4 Macs on macOS 10.14+ with driver installation.
- Linux: Compatible with Linux (driver installation may be required).
- Jenis Sambungan: USB 3.0 (USB-A) to HDMI.
Figure 5: Visual representation of the adapter's compatibility with macOS, Windows, and ChromeOS, and various laptop models.
Spesifikasi
| Ciri | Perincian |
|---|---|
| Jenama | Boleh pasang |
| Nombor Model | UGA-2KHDMI |
| Jenis Penyambung | USB 3.0 (USB-A) to HDMI |
| Resolusi Maks | 2560x1440 |
| Keserasian Sistem Pengendalian | Windows (11, 10, 7, XP), macOS (10.14+), Linux |
| Berat Barang | 3.53 auns |
| Dimensi Produk (LxWxH) | 8.74 x 5.12 x 1.42 inci |
| warna | Hitam |
Menyelesaikan masalah
- Tiada Paparan/Skrin Hitam:
- Ensure the DisplayLink drivers are correctly installed and updated.
- Verify all cables (USB and HDMI) are securely connected.
- Cuba port USB lain pada komputer anda.
- Test with a different HDMI cable or monitor if available.
- Restart your computer after driver installation or connection changes.
- Incorrect Resolution/Display Mode:
- Adjust display settings in your operating system (e.g., Windows Display Settings, macOS System Preferences > Displays).
- Ensure your monitor supports the selected resolution.
- Performance Issues (Lag/Choppy Video):
- Ensure the adapter is connected to a USB 3.0 port for optimal bandwidth.
- Close unnecessary applications to free up system resources.
- Kemas kini pemacu grafik komputer anda.
Penyelenggaraan
To ensure the longevity and optimal performance of your Plugable USB 3.0 to HDMI Video Graphics Adapter, follow these maintenance guidelines:
- Pembersihan: Gunakan kain lembut dan kering untuk membersihkan penyesuai. Elakkan pembersih cecair atau bahan kasar.
- Storan: Simpan penyesuai di tempat yang sejuk dan kering jauh dari cahaya matahari langsung dan suhu yang melampau apabila tidak digunakan.
- Pengendalian: Avoid dropping the adapter or subjecting it to strong impacts. Do not bend or twist the attached USB cable excessively.
- Pengudaraan: Ensure the adapter is not covered or placed in an enclosed space that could restrict airflow, as proper ventilation helps prevent overheating.
Waranti dan Sokongan
Plugable products are backed by a 2-year coverage. For technical assistance or warranty claims, please contact Plugable support. North American Lifetime Support is available from the engineers who built the product.
For more information and support resources, visit the official Plugable webtapak.
