pengenalan
The Master & Dynamic MW60 Wireless Bluetooth Foldable Headphones are designed to deliver a high-quality audio experience with effective sound isolation. They feature 45mm neodymium drivers for clear audio reproduction across various music genres. Equipped with Bluetooth 4.1, these headphones offer wireless connectivity and up to 16 hours of battery life. Constructed with lightweight stainless steel and aluminum, and featuring leather ear pads, the MW60 headphones are designed for comfort and durability, with a foldable design for portability.
Apa yang ada dalam Kotak
- Master & Dynamic MW60 Wireless Headphones
- Kabel Audio (3.5mm)
- Penyesuai Audio
- Kabel Pengecasan USB Mikro ke USB
- Carry Case for Headphones
- Carry Pouch for Accessories
Produk Selesaiview
Rajah 1: Depan view of the Master & Dynamic MW60 Wireless Headphones. This image displays the over-ear design with silver metal accents and brown leather earcups and headband.
Rajah 2: Close-up of the right earcup showing the control buttons and ports. Visible controls include volume up/down, a multi-function button, and the power/pairing switch. A 3.5mm audio jack and micro USB charging port are also present.
Kawalan dan Pelabuhan
- Power/Pairing Switch: Located on the earcup, used to turn the headphones on/off and initiate Bluetooth pairing.
- Butang pelbagai fungsi: Controls playback (play/pause), call management, and voice assistant activation.
- Butang Kelantangan / Turun Kelantangan: Adjusts audio volume. Can also be used for track skipping (hold for next/previous track).
- Bicu Audio 3.5mm: Untuk sambungan berwayar menggunakan kabel audio yang disertakan.
- Port USB Mikro: Untuk mengecas bateri dalaman.
- mikrofon: Bersepadu untuk panggilan bebas tangan.
Persediaan
Mengecas Fon Kepala
- Connect the Micro USB end of the charging cable to the Micro USB port on the headphone earcup.
- Connect the USB-A end of the charging cable to a powered USB port (e.g., computer, wall adapter).
- Lampu penunjuk akan menunjukkan status pengecasan. Pengecasan penuh biasanya mengambil masa lebih kurang 2 jam.
Berpasangan Bluetooth
- Pastikan fon kepala dicas sepenuhnya.
- Slide the Power/Pairing switch to the ON position.
- To enter pairing mode, slide and hold the Power/Pairing switch to the far right (pairing icon) until the indicator light begins to flash.
- Pada peranti anda (telefon pintar, tablet, komputer), dayakan Bluetooth dan cari peranti yang tersedia.
- Select "MW60" from the list of detected devices.
- Once paired, the indicator light will turn solid blue or white, depending on the model.
Arahan Operasi
Fungsi Asas
- Hidupkan/Mati Kuasa: Slide the Power/Pairing switch to the ON or OFF position.
- Main/Jeda: Tekan butang Pelbagai fungsi sekali.
- Kawalan Kelantangan: Press the Volume Up (+) or Volume Down (-) buttons.
- Lagu Seterusnya: Tekan dan tahan butang Naik Kelantangan (+).
- Trek Sebelumnya: Tekan dan tahan butang Turun Kelantangan (-).
Pengurusan Panggilan
- Jawab/Tamatkan Panggilan: Tekan butang Pelbagai fungsi sekali.
- Tolak Panggilan: Tekan dan tahan butang Berbilang fungsi.
- Aktifkan Pembantu Suara: Tekan dua kali butang Berbilang fungsi.
Sambungan Berwayar
To use the headphones with a wired connection, plug the included 3.5mm audio cable into the audio jack on the earcup and the other end into your audio source. The headphones will automatically switch to wired mode, conserving battery life.
Penyelenggaraan
Pembersihan
- Lap fon kepala dengan kain lembut dan kering.
- Jangan gunakan bahan kimia yang keras atau bahan yang melelas.
- For leather parts, use a specialized leather cleaner if necessary, following product instructions.
Penyimpanan
Rajah 3: The MW60 headphones folded into a compact form, demonstrating their portability and ease of storage in the included carry case.
- When not in use, fold the headphones and store them in the provided carry case to protect them from dust and damage.
- Elakkan menyimpan dalam suhu yang melampau atau kelembapan yang tinggi.
Menyelesaikan masalah
| Masalah | Penyelesaian yang Mungkin |
|---|---|
| Fon kepala tidak dihidupkan | Ensure the headphones are fully charged. Connect to a power source using the Micro USB cable. |
| Tidak boleh berpasangan melalui Bluetooth | Ensure headphones are in pairing mode (flashing indicator light). Turn off and on Bluetooth on your device. Try forgetting the device on your phone and re-pairing. Ensure no other devices are actively connected. |
| Audio atau sambungan terputus sekejap-sekejap | Ensure your device is within the Bluetooth range. Avoid physical obstructions between the headphones and your device. Minimize interference from other wireless devices. |
| Tiada bunyi dalam mod berwayar | Ensure the 3.5mm audio cable is securely connected to both the headphones and the audio source. Check the volume levels on both the headphones and the audio source. |
| Earcups detach easily | Ensure earcups are properly aligned and securely attached to the magnetic mounts. |
Spesifikasi
| Ciri | Perincian |
|---|---|
| Nama Model | MW60S2 |
| Teknologi Ketersambungan | Wayarles (Bluetooth 4.1) |
| Jenis Pemacu Audio | Pemacu Dinamik Neodymium 45mm |
| Hayat Bateri | Sehingga 16 jam |
| Bahan | Aluminum, Stainless Steel, Leather |
| Berat Barang | 3 paun (kira-kira 1.36 kg) |
| Dimensi Produk | 10 x 3.75 x 8 inci (25.4 x 9.5 x 20.3 cm) |
| Impedans | 32 ohm |
| Kawalan Bunyi | Pengasingan Bunyi (Pasif) |
| Jack Fon Kepala | Jack 3.5 mm |
Waranti dan Sokongan
Warranty information for your Master & Dynamic MW60 Wireless Headphones is typically provided with your purchase. Please refer to the documentation included in your product packaging for specific warranty terms and conditions.
For technical support, service, or further inquiries, please contact Master & Dynamic customer service directly. Contact details can usually be found on the manufacturer's official webtapak atau dalam dokumentasi produk anda.
