pengenalan
The Daylight Lamp Tube D13622 is designed to provide optimal lighting for tasks requiring accurate color perception and reduced eye strain. Its daylight-balanced spectrum ensures true color matching, making it ideal for crafts, reading, and detailed work. This energy-saving fluorescent bulb offers brightness equivalent to conventional incandescent bulbs while consuming significantly less power.
This manual provides essential information for the safe and effective use of your Daylight Lamp Tube D13622. Please read it thoroughly before installation and operation.
Brightness Equivalency Note:
- An 11W Daylight energy-saving bulb is equivalent to a 60W conventional bulb.
- An 18W Daylight energy-saving bulb is equivalent to a 100W conventional bulb.
- A 20W Daylight energy-saving bulb is equivalent to a 100W conventional bulb.
- A 28W Daylight energy-saving bulb is equivalent to a 120W conventional bulb.
Persediaan dan Pemasangan
l iniamp tube is designed for use with compatible clip lamps or fixtures. Always ensure the power supply is disconnected before attempting installation or replacement.
- Keselamatan Diutamakan: Pastikan lamp fixture is unplugged from the power outlet before handling the bulb.
- Keluarkan Mentol Lama (jika berkenaan): Carefully twist or pull the old fluorescent tube from its socket, following the instructions for your specific lamp lekapan.
- Masukkan Mentol Baharu: Align the pins at the base of the Daylight Lamp Tube D13622 with the slots in the lamp fixture's socket. Gently push and/or twist the tube into place until it is securely seated. Do not force the bulb.
- Sambung semula Kuasa: Once the bulb is securely installed, plug the lamp fixture back into the power outlet.
Arahan Operasi
The Daylight Lamp Tube D13622 operates like any standard fluorescent bulb. Once installed in a compatible fixture and connected to power, simply use the lamp's switch to turn it on or off.
The primary benefit of this lamp tube is its daylight-balanced light, which provides a clear and accurate representation of colors, reducing eye strain during extended periods of detailed work.
Penyelenggaraan
The Daylight Lamp Tube D13622 requires minimal maintenance.
- Pembersihan: Pastikan lamp is unplugged and cool before cleaning. Wipe the tube gently with a dry, soft cloth to remove dust. Do not use liquid cleaners or abrasive materials.
- Penggantian: Gantikan lamp tube when it reaches the end of its lifespan, typically indicated by flickering, dimming, or failure to illuminate. Always ensure the power is disconnected before replacing.
- Pelupusan: Fluorescent tubes contain small amounts of mercury and should be disposed of according to local environmental regulations. Do not discard with regular household waste. Contact your local waste management facility for proper disposal instructions.
Menyelesaikan masalah
If you encounter issues with your Daylight Lamp Tube D13622, refer to the following common problems and solutions:
| Masalah | Kemungkinan Punca | Penyelesaian |
|---|---|---|
| Lamp tidak menyala | No power supply; Bulb not properly installed; Faulty lamp fixture; Bulb has reached end of life. | Semak sama ada lamp is plugged in and the power outlet is working. Ensure the bulb is securely seated in the socket. Test with another bulb if possible. Replace the bulb if it is old. |
| Lamp kelipan | Bulb nearing end of life; Loose connection; Incompatible fixture. | Replace the bulb. Ensure the bulb is securely installed. Consult the lamp fixture's manual for compatibility. |
| Keluaran cahaya malap | Bulb nearing end of life; Dust accumulation on tube. | Replace the bulb. Clean the lamp tube with a dry, soft cloth. |
Spesifikasi
| Ciri | Perincian |
|---|---|
| Jenama | siang hari |
| Pengeluar | Daylight Company |
| Nombor Model | D13622 |
| Dimensi (L x W x H) | 24.1 x 3.8 x 2 cm |
| Berat Barang | 40 gram |
| bentuk | Tiub (T) |
| Ciri Khas | Kecekapan Tenaga |
| kuasa | 11 Watt |
| Indeks Paparan Warna (CRI) | 95 |
| Pangkalan Mentol | E27 |
| Sumber Kuasa | Kabel Elektrik |
| Kuantiti setiap Pakej | 1 |
Waranti dan Sokongan
For warranty information and customer support, please refer to the documentation provided with your lamp fixture or contact the retailer where the Daylight Lamp Tube D13622 was purchased. Specific details regarding spare parts availability are not provided for this component.
