1. Pengenalan
Thank you for choosing the Feexot Retro Bluetooth AM FM SW Radio. This manual provides essential information for the safe and efficient operation of your device. Please read it thoroughly before use and retain it for future reference.
This portable radio combines vintage aesthetics with modern functionality, offering AM, FM, and Shortwave (SW) radio reception, Bluetooth connectivity, and multiple playback options including USB, TF card, and AUX input. Its compact design and rechargeable battery make it ideal for both home and outdoor use.
2. Produk Lebihview
Familiarize yourself with the components and controls of your Feexot Retro Radio.
Figure 1: Front panel controls and features of the Feexot Retro Radio.
Komponen Utama:
- Suis kuasa: Integrated into the tonearm mechanism. Moving the tonearm over the faux record turns the unit ON; returning it to its resting position turns it OFF.
- Tombol Kelantangan: Melaraskan tahap output audio.
- Mode Switch (MP3/FM/AM/SW): Selects between different audio sources (MP3 playback, FM radio, AM radio, Shortwave radio).
- Dail Penalaan: Used to precisely tune into radio stations. Features frequency-modulated LED lighting.
- Antena: Antena teleskopik boleh dipanjangkan untuk penerimaan radio yang lebih baik.
- Butang Kawalan Main Semula: Play/Pause, Previous Track, Next Track (for MP3/Bluetooth modes).
- Port USB: Untuk memainkan audio files dari pemacu denyar USB.
- Slot Kad TF: Untuk memainkan audio files daripada kad TF (MicroSD).
- Input AUX: Bicu 3.5mm untuk menyambungkan peranti audio luaran.
- Port Pengecasan Jenis-C DC 5V: Untuk mengecas semula bateri dalaman.
Figure 2: Available audio input options.
3. Persediaan
3.1 Membuka kotak
Carefully remove the radio from its packaging. Ensure all included components are present:
- Feexot Retro Bluetooth AM FM SW Radio
- Kabel Pengecas USB (Jenis-A hingga Jenis-C)
- Manual Pemilik (dokumen ini)
3.2 Mengecas Bateri
The radio is equipped with a built-in rechargeable lithium-ion battery. Before first use, it is recommended to fully charge the device.
- Connect the provided USB charging cable to the DC 5V Type-C port on the side of the radio.
- Sambungkan hujung kabel USB yang satu lagi ke penyesuai kuasa USB yang serasi (tidak disertakan) atau port USB komputer.
- Lampu penunjuk pengecasan akan menyala semasa pengecasan.
- A full charge typically takes approximately 4 hours. The indicator light may change or turn off once charging is complete.
The radio can operate for several hours on a full charge, providing extended wireless listening.
3.3 Sambungan Antena
For optimal radio reception, extend the telescopic antenna located at the back of the unit to its full length (approximately 19.29 inches).
Rajah 3: Dimensi produk untuk rujukan peletakan.
4. Arahan Operasi
4.1 Hidupkan/Mati Kuasa
To power on the radio, gently move the tonearm from its resting position to over the faux record on the top surface. The unit will emit an audible cue, and the tuning dial will illuminate. To power off, return the tonearm to its resting position.
Video 1: Demonstration of powering on the radio by moving the tonearm.
4.2 Melaraskan Kelantangan
Putar Tombol Kelantangan on the front panel clockwise to increase volume and counter-clockwise to decrease it.
4.3 Selecting Audio Mode
Gunakan Tukar Mod to cycle through available audio sources: MP3 (for USB/TF card), FM, AM, and SW (Shortwave) radio bands.
4.4 Radio Operation (AM/FM/SW)
- Panjangkan antena teleskopik untuk penerimaan terbaik.
- Tetapkan Tukar Mod to FM, AM, or SW.
- Putar Dail Penalaan to scan for radio stations. The illuminated dial will help in precise tuning.
- Adjust the antenna position and radio placement for optimal signal clarity.
Figure 4: Visual representation of radio frequency tuning.
4.5 Berpasangan Bluetooth
- Tetapkan Tukar Mod to Bluetooth mode. The radio will enter pairing mode, indicated by an audible prompt.
- Pada telefon pintar, tablet atau peranti lain yang didayakan Bluetooth anda, dayakan Bluetooth dan cari peranti yang tersedia.
- Select "BT-888" (or similar name) from the list of devices.
- Once paired, the radio will confirm with an audible sound, and you can stream audio wirelessly.
Figure 5: Bluetooth connection with a mobile device.
4.6 Main Semula Kad USB/TF
- Insert a USB flash drive into the USB port or a TF (MicroSD) card into the TF card slot on the side of the radio.
- Tetapkan Tukar Mod to MP3 mode. The radio will automatically detect and begin playing audio files daripada peranti storan yang dimasukkan.
- Gunakan butang Main/Jeda, Trek Sebelumnya dan Trek Berikutnya untuk mengawal main balik.
4.7 Input AUX
- Connect an external audio device (e.g., MP3 player, laptop) to the AUX input jack on the side of the radio using a 3.5mm audio cable (not included).
- Tetapkan Tukar Mod kepada mod AUX.
- Kawal main balik dan kelantangan daripada peranti luaran anda yang disambungkan.
5. Penyelenggaraan
5.1 Pembersihan
Wipe the radio with a soft, dry cloth. Do not use abrasive cleaners, waxes, or solvents as they may damage the finish. Avoid spraying liquids directly onto the unit.
5.2 Penjagaan Bateri
- Untuk memanjangkan hayat bateri, elakkan daripada menyahcas sepenuhnya bateri dengan kerap.
- If the radio will not be used for an extended period, charge it to approximately 50% and store it in a cool, dry place. Recharge every 3-6 months to prevent deep discharge.
- Jangan dedahkan bateri kepada suhu yang melampau atau cahaya matahari langsung.
5.3 Penyimpanan
Store the radio in a dry environment, away from direct sunlight and extreme temperatures. Retract the antenna when not in use to prevent damage.
6. Penyelesaian masalah
If you encounter issues with your Feexot Retro Radio, please refer to the following common problems and solutions:
| Masalah | Kemungkinan Punca | Penyelesaian |
|---|---|---|
| Tiada kuasa | Battery is discharged; Tonearm not in ON position. | Charge the battery; Move the tonearm over the faux record to power on. |
| Tiada bunyi | Volume too low; Incorrect mode selected; Device not connected properly. | Increase volume; Select correct mode (e.g., FM, Bluetooth); Ensure Bluetooth is paired or AUX cable is fully inserted. |
| Penerimaan radio yang lemah | Antena tidak dilanjutkan; Kawasan isyarat lemah; Gangguan. | Fully extend the telescopic antenna; Reposition the radio; Try tuning slowly to find a clearer signal. |
| Bluetooth tidak bersambung | Radio tiada dalam mod Bluetooth; Peranti terlalu jauh; Telah disambungkan ke peranti lain. | Ensure radio is in Bluetooth mode; Move device closer to radio; Disconnect from other devices and try pairing again. |
| Kad USB/TF tidak dimainkan | Mod salah; Tidak serasi file format; Corrupted card/drive. | Ensure radio is in MP3 mode; Check file formats (e.g., MP3); Try a different USB drive or TF card. |
7. Spesifikasi
| Ciri | Perincian |
|---|---|
| Jenama | Feexot |
| Nombor Model | F-1317BT |
| warna | coklat |
| Dimensi Produk (L x W x H) | 5.9" x 3.3" x 6.3" (150mm x 85mm x 160mm) |
| Teknologi Ketersambungan | Bluetooth, USB, AUX |
| Teknologi Penala | AM/FM/SW (3-Band) |
| Sumber Kuasa | Dikuasakan Bateri (termasuk 1 bateri Lithium Ion) |
| Ciri Khas | Built-In AM Antenna, Portable, Rechargeable |
| Jenis Paparan | LED (for tuning dial illumination) |
| Komponen yang Disertakan | Owner's Manual, USB Cable |
| Tahap Ketahanan Air | Bukan Tahan Air |
8. Maklumat Waranti
This Feexot product is covered by a Waranti 1 tahun dari tarikh pembelian. Waranti ini meliputi kecacatan pembuatan dan mutu kerja di bawah penggunaan biasa. Ia tidak melindungi kerosakan yang disebabkan oleh penyalahgunaan, kemalangan, pengubahsuaian yang tidak dibenarkan atau haus dan lusuh biasa.
Sila simpan bukti pembelian anda untuk tuntutan waranti.
9. Sokongan Pelanggan
For any questions, technical assistance, or warranty inquiries, please contact Feexot customer support through the retailer's platform or refer to the contact information provided with your purchase documentation.
We are committed to providing excellent service and support for your Feexot product.
