Betopper LPC1218 LED Stage Manual Pengguna Ringan

1. Pengenalan

This manual provides essential information for the safe and effective operation of your Betopper LPC1218 LED Stage Light. This professional-grade par light features 12x18W RGBLA+UV 6-in-1 LEDs, offering a wide color mixing range and high brightness. It supports multiple control modes including DMX512, Auto, Sound-Activated, and Master-Slave, making it suitable for various stage, party, and event lighting applications.

2. Maklumat Keselamatan

• Baca semua arahan dengan teliti sebelum pemasangan dan operasi.
• This device is for indoor use only. Do not expose to rain or moisture.
• Pastikan bekalan kuasa voltage sepadan dengan nilai voltage peranti.
• Always disconnect from the main power supply before cleaning or servicing.
• Jangan kendalikan peranti jika kord kuasa rosak.
• Elakkan pendedahan mata secara langsung kepada sumber cahaya.
• Pastikan pengudaraan yang betul untuk mengelakkan terlalu panas. Jangan sekat bukaan pengudaraan.
• Pemasangan hendaklah dilakukan oleh pegawai yang berkelayakan.
• Jauhkan daripada bahan mudah terbakar.

3. Kandungan Pakej

• 1 x Betopper LPC1218 Stage Cahaya
• 1 x Kabel Kuasa
• 2 x kurungan
• 2 x Skru
• 1 x Manual Pengguna

Image: The Betopper LPC1218 stage light, power cable, mounting brackets, screws, and user manual are shown as included items.

4. Produk Lebihview

Ciri-ciri Utama

• 6-in-1 Color Performance: Upgraded RGBLA+UV technology combines Red, Green, Blue, Lime, Amber, and UV LEDs for a 12% wider color mixing range, richer tones, and smoother transitions.
• Enhanced Lime LED: Produces naturally bright and vivid green tones with a CRI above 95, ensuring professional-grade brightness and color accuracy.
• Pembinaan Tahan Lama: Crafted with a robust cast aluminum housing and adjustable dual brackets for flexible positioning.
• Mod Kawalan Berbilang: Supports DMX512, Auto, Sound-Activated, and Master-Slave modes.
• Long Lifespan & Efficient Cooling: Equipped with a heat sink and built-in fan for extended LED lifespan up to 100,000 hours.

Komponen

Imej: Depan view of the Betopper LPC1218 LED Stage Cahaya, tunjukkanasing the 12 LED bulbs.

Imej: Dari dekat view of the 12 LED bulbs on the Betopper LPC1218, highlighting their arrangement.

Image: Rear panel of the Betopper LPC1218 LED Stage Light, showing the display screen, menu buttons, power in/out, and DMX in/out ports.

5. Persediaan

1. Membongkar: Carefully remove the light fixture and all accessories from the packaging. Inspect for any damage during transit.
2. Pemasangan: The fixture comes with adjustable dual brackets.
   • For freestanding use, position the light on a stable, flat surface.
   • For truss or ceiling mounting, use appropriate clamps (not included) and secure the brackets firmly. Ensure the mounting location can support the weight of the fixture.
3. Sambungan Kuasa: Connect the provided power cable to the "POWER IN" port on the rear of the fixture. Plug the other end into a compatible power outlet (AC100V-240V, 50-60Hz).
4. Sambungan DMX (Pilihan): If using DMX control, connect a DMX cable from your DMX controller to the "DMX IN" port. For daisy-chaining multiple lights, connect from "DMX OUT" of the first light to "DMX IN" of the next.

Image: The Betopper LPC1218 LED Stage Light is shown mounted on its adjustable bracket, demonstrating flexible positioning.

6. Mod Operasi

The Betopper LPC1218 offers several operating modes to suit different applications. Use the "MENU", "UP", "DOWN", and "ENTER" buttons on the rear display to navigate and select modes.

1. DMX512 Control Mode

This mode allows for precise control over color, dimming, and effects using an external DMX controller. The fixture supports 6 or 10 DMX channels. Refer to the DMX channel chart in the full manual for detailed assignments.

Video: This video demonstrates the various lighting effects and modes of the Betopper LPC1218 Stage Par Light, including DMX control, auto mode, sound-activated mode, pulse mode, gradient mode, jump mode, and strobe mode. It also highlights the 6-in-1 RGBLA+UV mixing color capabilities and 0-100% linear dimming.

Image: Illustration of multiple Betopper LPC1218 lights connected via DMX cables in a master-slave configuration, controlled by a single console.

2. Mod Auto

The light will cycle through pre-programmed color changes and effects automatically. Select "Auto" from the menu and press "ENTER".

3. Sound-Activated Mode

The light reacts to ambient sound or music via its built-in microphone. Select "Sound" from the menu and press "ENTER". Sensitivity can often be adjusted.

Image: The Betopper LPC1218 light is depicted in sound-activated mode, with musical notes and sound waves illustrating its response to music.

4. Master-Slave Mode

Connect multiple LPC1218 units using DMX cables. Set one unit as the "Master" and the others as "Slave". The slave units will mirror the master's operation.

7. Penyelenggaraan

• Pembersihan: Regularly clean the lens and housing with a soft, lint-free cloth to maintain optimal light output. Do not use alcohol or solvents.
• Pemeriksaan: Periodically check all screws, connections, and cables for tightness and wear.
• Storan: When not in use, store the fixture in a dry, dust-free environment.

8. Penyelesaian masalah

9. Spesifikasi

10. Waranti dan Sokongan

This Betopper LPC1218 LED Stage Light comes with a 1-year manufacturer's warranty. For technical support, troubleshooting assistance, or warranty claims, please contact Betopper customer service through the retailer where the product was purchased or visit the official Betopper webtapak. Sila simpan bukti pembelian anda untuk pengesahan waranti.
