Baetaey WiFi Signal Amplifier and Repeater User Manual

1. Pengenalan

Thank you for choosing the Baetaey WiFi Signal Amplifier and Repeater. This device is designed to extend the coverage of your existing wireless network, eliminating dead zones and providing a stronger, more reliable internet connection throughout your home or office. It supports both Repeater and Access Point (AP) modes and features an Ethernet port for wired connections.

2. Produk Lebihview

The Baetaey WiFi Signal Amplifier is a compact device that plugs directly into a wall outlet. It features external antennas for enhanced signal transmission and reception, and an Ethernet port for connecting wired devices or for use in AP mode.

Imej 1: Depan view of the Baetaey WiFi Signal Amplifier, showing its compact design, two adjustable antennas, and an indicator light. The device is designed to plug directly into a power outlet.

3. Arahan Persediaan

Follow these steps to set up your Baetaey WiFi Signal Amplebih hidup:

1. Buka bungkusan Peranti: Carefully remove the WiFi amppengalir daripada pembungkusannya.
2. Hidupkan kuasa: Plug the WiFi amplifier into an electrical outlet in a central location, ideally halfway between your router and the area with poor WiFi signal. Wait for the power indicator light to turn on and stabilize.
3. Connect to the Repeater's Network: On your computer or smartphone, search for available WiFi networks. Connect to the network named something like "WiFi-Repeater" or "Baetaey_EXT". This network will not have internet access initially.
4. Akses Halaman Persediaan: Buka a web browser (e.g., Chrome, Firefox) and enter the default IP address or domain name into the address bar. Common addresses include 192.168.1.1, 192.168.0.1, atau repeater.net. Refer to the label on your device for the exact address.
5. Log Masuk: Enter the default username and password, usually pentadbir/pentadbir or specified on the device label.
6. Pilih Mod Pengendalian: pilih Mod Pengulang to extend your existing WiFi network, or Mod AP to create a new WiFi network from a wired Ethernet connection. For most users, Repeater Mode is appropriate.
7. Select Host Network (Repeater Mode): The device will scan for available WiFi networks. Select your home or office WiFi network from the list.
8. Enter Host Network Password: Input the password for your selected host WiFi network.
9. Configure Repeater Network: You can choose to keep the same network name (SSID) as your main router (e.g., "YourWiFi_EXT") or create a new one. Set a password for the extended network. It is recommended to use a strong, unique password.
10. Apply Settings and Reboot: Save your settings. The device will reboot. Once it restarts, the indicator lights should show a successful connection to your main router.
11. Sambungkan Peranti Anda: Connect your WiFi-enabled devices to the newly configured extended network.

4. Arahan Operasi

Once set up, the Baetaey WiFi Signal Amplifier operates automatically. It will continuously extend your chosen WiFi network. For optimal performance, ensure the device is placed in a location where it receives a good signal from your main router and can effectively broadcast to the desired areas.

• Ethernet Port Usage: The integrated Ethernet port can be used to connect a wired device (e.g., a desktop computer, gaming console, smart TV) to the extended network, providing a stable wired connection.
• Lampu Penunjuk: Pay attention to the device's indicator lights. They typically show power status, WiFi signal strength, and connection status to the main router. Refer to your device's specific light patterns for detailed information.

5. Penyelenggaraan

To ensure the longevity and optimal performance of your WiFi amplebih hidup:

• Pastikan peranti bersih dan bebas daripada habuk. Gunakan kain lembut dan kering untuk pembersihan.
• Ensure adequate ventilation around the device to prevent overheating. Do not cover it or place it in enclosed spaces.
• Avoid placing the device near strong electromagnetic interference sources (e.g., microwave ovens, cordless phones).
• Periksa secara berkala kemas kini perisian tegar pada peranti pengeluar webtapak untuk memastikan prestasi dan keselamatan terbaik.

6. Penyelesaian masalah

If you encounter issues with your Baetaey WiFi Signal Amplifier, rujuk kepada masalah dan penyelesaian biasa berikut:

• Tiada Sambungan Internet Selepas Persediaan:
  • Ensure the repeater is within range of your main router and receiving a strong signal.
  • Verify that you entered the correct password for your main WiFi network during setup.
  • Reboot both your main router and the WiFi amplebih hidup.
  • Try resetting the amplifier to factory defaults (usually via a small reset button) and repeat the setup process.
• Kelajuan Internet Perlahan:
  • The repeater might be too far from your main router, resulting in a weak signal to extend. Try moving it closer.
  • Interference from other electronic devices can degrade performance.
  • Ensure your main internet connection is stable and fast. The repeater cannot improve the speed of a slow primary connection.
  • Check if too many devices are connected to the extended network.
• Cannot Access Setup Page (192.168.1.1, etc.):
  • Ensure your device (computer/smartphone) is connected to the repeater's default WiFi network (e.g., "WiFi-Repeater") and not your main router's network.
  • Kosongkan cache dan kuki penyemak imbas anda atau cuba penyemak imbas lain.
  • Verify the correct IP address or domain name for the setup page from the device label.
• Signal Drops Frequently:
  • Pindahkan semula amplifier to a position with fewer physical obstructions (walls, large furniture) between it and your main router.
  • Check for potential sources of interference.
  • Memastikan amplifier's firmware is up to date.

7. Spesifikasi

8. Waranti dan Sokongan

Specific warranty details for the Baetaey WiFi Signal Amplifier (Model: B0FG2257WS) are not provided in this manual. For warranty information, technical support, or further assistance, please refer to the documentation included with your product or contact the manufacturer directly through their official webtapak atau saluran perkhidmatan pelanggan.
