ANDELI MCT-416P 5-in-1 Multi-function Welder Instruction Manual

1. Pengenalan

This manual provides essential information for the safe and effective operation, maintenance, and troubleshooting of your ANDELI MCT-416P 5-in-1 Multi-function Welder. Please read this manual thoroughly before using the product and keep it for future reference.

2. Maklumat Keselamatan

Always prioritize safety when operating welding and plasma cutting equipment. Failure to follow safety guidelines can result in serious injury or death.

Pakai peralatan pelindung diri (PPE) yang sesuai, termasuk topi keledar kimpalan, sarung tangan, pakaian pelindung, dan kasut keselamatan.
Ensure adequate ventilation to avoid inhaling fumes and gases.
Jangan kendalikan mesin dalam keadaan basah atau berhampiran bahan mudah terbakar.
Pastikan peralatan dibumikan dengan betul.
Putuskan sambungan kuasa sebelum melakukan sebarang penyelenggaraan atau menukar aksesori.
Jauhkan kanak-kanak dan kakitangan yang tidak dibenarkan dari kawasan kerja.
Produk ini diperakui CE, menunjukkan pematuhan dengan piawaian keselamatan Eropah.

3. Produk Lebihview

3.1 Ciri-ciri Utama

Pelbagai fungsi 5-dalam-1: Supports Plasma Cutting, Gas & Gasless Semi-automatic Welding (MIG/MAG with CO2 / MIX / FLUX), HF TIG Welding, Pulse Semi-automatic Welding (Aluminum capable), and Stick Welding (MMA).
Dwi Voltage Keserasian: Operates on both 100V and 200V power supplies, offering flexibility for various work environments.
Synergy Function: Automatically sets optimal welding parameters based on selected wire diameter and plate thickness. Allows for fine adjustment of voltage dan semasa.
Aplikasi luas: Suitable for welding aluminum, iron, stainless steel, and low carbon steel. Ideal for household use, maintenance, automotive sheet metal, construction, and DIY projects.
Paparan led: Large 5-inch LED screen for clear visibility of settings and operational status.

3.2 Komponen dan Aksesori

The ANDELI MCT-416P comes with the following standard accessories:

MCT-416P Main Unit
Semi-automatic Welding Torch
Obor Pemotong Plasma
HF TIG Welding Torch (WP-17)
Welding Gloves (2 pairs)
Welding Machine Dust Cover
Tanah Clamp
Gas Hose (3m)
Pengatur udara
Semi-automatic Torch Consumables Set
Cutting Torch Consumables Set
TIG Torch Consumables Set
Welding Holder

ANDELI MCT-416P Welder Accessories List — Figure 1: Included accessories for the MCT-416P welding machine.

ANDELI MCT-416P Control Panel Diagram — Rajah 2: Terperinci view of the MCT-416P control panel, showing input voltage, semi-automatic welding adjustments, welding method selection, wire size, welding current/voltage, arc welding adjustments, wire/gas type, and welding mode.

4. Persediaan

4.1 Sambungan Kuasa

The MCT-416P supports both 100V and 200V power inputs. Use the appropriate power cable and adapter for your local power supply. Ensure the power source meets the machine's requirements.

ANDELI MCT-416P 100V and 200V Power Compatibility — Figure 3: The MCT-416P welder is compatible with both 100V and 200V power supplies, with an included adapter for conversion.

4.2 Obor dan Tanah Clamp Sambungan

Connect the desired torch (MIG, TIG, or Plasma) to its corresponding port on the front panel. Connect the ground clamp to the appropriate terminal and securely attach it to the workpiece or metal workbench to ensure proper grounding.

For gas-shielded welding processes (Gas MIG, TIG), connect the gas hose from your gas cylinder to the machine's gas inlet and ensure the air regulator is properly installed and adjusted.

For MIG welding, install the appropriate wire spool (1kg or 5kg compatible) and thread the welding wire through the wire feeder mechanism. Ensure the wire feeder tension is correctly set to prevent slippage.

5. Arahan Operasi

The MCT-416P offers multiple welding and cutting modes. Select the desired mode using the control panel.

5.1 Pemotongan Plasma

Connect the plasma cutting torch and ensure an air compressor is connected to the machine's air inlet via the air regulator.
Select "CUT" mode on the control panel.
Adjust cutting current based on material type and thickness.
The machine uses a touch-start method for smooth cutting.
Maximum cutting thickness: 12mm (100V) / 15mm (200V).

Plasma Cutting with ANDELI MCT-416P — Gambar 4: Cthample of plasma cutting operation, showing cut thickness capabilities at 100V and 200V.

5.2 MIG/MAG Welding (Gas & Gasless)

Select "MIG" or "PULSE MIG" mode.
Choose between Gas (CO2/MIX) or Gasless (FLUX) operation.
Utilize the synergy function by selecting wire diameter and plate thickness for automatic parameter setting. Fine-tune voltage dan semasa mengikut keperluan.
Pulse MIG mode is suitable for aluminum welding.
Weldable plate thickness: 0.8-4.5mm (100V) / 0.8-6.5mm (200V).

5.3 HF TIG Welding

Connect the HF TIG torch and gas supply (Argon).
Select "TIG" mode.
Adjust welding current and gas flow.
HF (High Frequency) start provides a clean arc initiation without touching the workpiece.
Especially effective for thin plate welding.

HF TIG Welding with ANDELI MCT-416P — Gambar 5: Cthample of HF TIG welding, demonstrating a clean weld bead.

5.4 Kimpalan Kayu (MMA)

Connect the welding holder and ground clamp.
Select "MMA" mode.
Insert the appropriate welding electrode into the holder.
Adjust welding current based on electrode type and material thickness.
Suitable for outdoor work and thick plate welding.

Stick Welding (MMA) with ANDELI MCT-416P — Figure 6: Illustration of stick welding (MMA) in progress, showing a typical weld using a 100V/2.5mm electrode.

5.5 Welding Modes (2T, 4T, Spot)

The machine offers different trigger modes for various welding applications:

Mod 2T: Press and hold the trigger to weld. Release to stop welding.
Mod 4T: Press and release the trigger to start welding. Press and release again to stop welding.
Kimpalan Titik: Press the trigger to initiate welding. Welding automatically stops after a set time.

ANDELI MCT-416P Welding Modes (2T, 4T, Spot) — Figure 7: Diagram illustrating the 2T, 4T, and Spot welding modes available on the control panel.

6. Penyelenggaraan

Penyelenggaraan tetap memastikan jangka hayat dan prestasi optimum mesin kimpalan anda.

Pembersihan: Regularly clean the machine's exterior and ventilation openings to prevent dust buildup. Use the provided dust cover when not in use.
Penyelenggaraan Obor: Inspect torches for wear and tear. Replace consumables (nozzles, contact tips, electrodes) as needed.
Pengumpan Kawat: Keep the wire feeder mechanism clean and ensure proper tension.
Kabel dan Sambungan: Check all cables and connections for damage or looseness. Repair or replace as necessary.
Air Regulator: Ensure the air regulator for plasma cutting is functioning correctly and free of moisture.

ANDELI MCT-416P Transparent Screen Protection Cover — Figure 8: The transparent screen protection cover helps protect the display from damage and dirt while maintaining clear visibility.

7. Penyelesaian masalah

Bahagian ini menyediakan penyelesaian kepada isu-isu lazim. Untuk masalah yang tidak disenaraikan di sini, hubungi khidmat pelanggan.

Masalah	Kemungkinan Punca	Penyelesaian
Tiada kuasa	Power cable disconnected, circuit breaker tripped, incorrect voltage.	Check power connections, reset breaker, ensure correct 100V/200V input.
Kualiti kimpalan yang tidak baik	Incorrect settings (current/voltage), improper wire feed speed, contaminated workpiece, worn consumables.	Adjust settings, clean workpiece, replace consumables. Use synergy function for optimal settings.
Arc unstable or difficult to start	Poor ground connection, incorrect gas flow, dirty contact tip/electrode.	Ensure solid ground, check gas supply, clean or replace torch consumables.
Plasma cutter not cutting	No air supply, low air pressure, worn plasma consumables, incorrect current.	Check air compressor and regulator, replace plasma torch consumables, adjust current.

8. Spesifikasi

Ciri	Perincian
Jenama	ANDELI
Nombor Model	MCT-416P
Dimensi Produk	46 x 17 x 29 cm
Berat Barang	18 kg
Input Voltage	100V / 200V (Dwi Voltantage)
Arus Kimpalan Maks	160 AMP
Weldable Plate Thickness (100V)	0.8 - 4.5 mm
Weldable Plate Thickness (200V)	0.8 - 6.5 mm
Cuttable Plate Thickness (100V)	Sehingga 12 mm
Cuttable Plate Thickness (200V)	Sehingga 15 mm
Mod Kimpalan	MIG (Gas/Gasless), Pulse MIG, HF TIG, MMA (Stick), Plasma Cut
Pensijilan	Diperakui CE

9. Waranti dan Sokongan

For warranty information, please refer to the warranty card included with your product or contact ANDELI customer service. ANDELI is committed to providing efficient customer service and support for its products.

For technical assistance, troubleshooting beyond this manual, or to inquire about replacement parts, please contact the ANDELI Official Store JP through the platform where you purchased the product or visit their official webtapak.

Tarikh Pertama Tersedia: 2025/06/24
