LcFun B0F9NFD8TR

LcFun Electric Candle Lighter Instruction Manual

Model: B0F9NFD8TR | Brand: LcFun

Maklumat Keselamatan Penting

AMARAN: Failure to follow these instructions may result in fire, electric shock, or injury.

  • Jauhkan daripada kanak-kanak.
  • Do not touch the arc electrodes.
  • Do not immerse the lighter in water or other liquids.
  • Jangan dedahkan kepada suhu melebihi 50°C (122°F).
  • Jangan cuba membuka atau mengubah suai pemetik api.
  • Use only with a compatible USB charging cable.
  • Ensure the safety lock is engaged when not in use.
  • Do not use if the lighter is damaged.
  • Elakkan pendedahan berpanjangan kepada cahaya matahari langsung.

Kandungan Pakej

  • 1 x LcFun Electric Candle Lighter
  • 1 x Kabel Pengecas USB

Produk Selesaiview

The LcFun Electric Candle Lighter is a USB rechargeable plasma arc lighter designed for safe and efficient ignition of candles, grills, gas stoves, and more. It features a safety lock and an LED battery indicator.

LcFun Electric Candle Lighter with labeled parts
Figure 1: LcFun Electric Candle Lighter components. Shows the electric arc, ignition button, safety switch, LED battery indicator, and Type-C charging port.
  • Electric Arc: Generates a flameless, windproof plasma arc for ignition.
  • Butang Pencucuhan: Activates the electric arc when pressed.
  • Suis keselamatan: Prevents accidental activation. Must be slid up to enable ignition.
  • Penunjuk Bateri LED: Memaparkan baki kuasa bateri.
  • Port Pengecasan Jenis-C: Untuk mengecas semula bateri dalaman.

Setup: Charging the Lighter

Before first use, fully charge the lighter. The lighter features a real-time LED battery display to indicate remaining power.

  1. Locate the Type-C charging port on the lighter.
  2. Connect the provided USB charging cable to the lighter's charging port.
  3. Connect the other end of the USB cable to a compatible USB power source (e.g., computer, wall adapter).
  4. During charging, the LED battery indicators will flash.
  5. When fully charged (approximately 40 minutes), all four LED lights will remain steadily lit.
  6. Putuskan sambungan kabel pengecas setelah pengecasan selesai.
LcFun Electric Candle Lighter being charged via USB-C
Figure 2: Charging the LcFun Electric Candle Lighter. Shows the lighter connected to a USB-C cable, with LED lights indicating charging status.

Arahan Operasi

The LcFun Electric Candle Lighter is designed for ease of use with enhanced safety features.

  1. Unlock the Lighter: Slide the safety lock switch upwards to unlock the device. The LED indicators will illuminate.
  2. Activate the Arc: Press and hold the ignition button. A plasma arc will generate between the electrodes.
  3. Nyalakan: Position the plasma arc near the wick of a candle, grill, or gas stove to ignite.
  4. Matikan automatik: The arc will automatically power off after 7 seconds of continuous use for safety.
  5. Re-ignite: If the arc shuts off automatically, release the ignition button, slide the safety lock down and then up again to reset, and then press the ignition button to reactivate.
  6. Lock the Lighter: After use, slide the safety lock switch downwards to prevent accidental activation.
Operating the LcFun Electric Candle Lighter with safety lock and ignition button
Figure 3: Operating the LcFun Electric Candle Lighter. Illustrates sliding the safety lock up and pressing the ignition button to create the windproof arc pulse.
LcFun Electric Candle Lighter igniting various items
Gambar 4: Cthamples of use for the LcFun Electric Candle Lighter, including candles, fireworks, gas cookers, and campkebakaran.

Penyelenggaraan

  • Pembersihan: Use a soft, dry cloth to clean the lighter. Do not use abrasive cleaners or solvents.
  • Storan: Store the lighter in a cool, dry place, away from direct sunlight and extreme temperatures.
  • mengecas: Recharge the lighter when the LED battery indicators show low power to ensure optimal performance and battery longevity.

Menyelesaikan masalah

MasalahKemungkinan PuncaPenyelesaian
Lighter does not produce an arc.Battery is low or depleted. Safety lock is not engaged.Charge the lighter fully. Ensure the safety lock is slid upwards to the "ON" position.
Arc stops after a few seconds.Automatic 7-second shut-off engaged.Release the ignition button, slide the safety lock down and then up again to reset, then press the ignition button to reactivate.
Lighter not charging.Masalah kabel pengecas atau sumber kuasa.Pastikan kabel USB disambungkan dengan selamat. Cuba port USB atau penyesuai kuasa yang lain.

Spesifikasi

JenamaLcFun
ModelB0F9NFD8TR
warnaHitam
bahanplastik
Jenis Bahan ApiElektrik
Dimensi Produk7.3" L x 0.63" W x 0.63" Th
Berat Barang2.08 auns
Masa Mengecaslebih kurang 40 minit untuk cas penuh
Ignitions per Charge500+

Waranti dan Sokongan

For any questions, suggestions, or needs regarding your LcFun Electric Candle Lighter, please do not hesitate to contact us. We aim to respond within 24 hours.

Rujuk kepada dokumentasi pembelian anda untuk butiran waranti tertentu.

Pengeluar: MvM

© 2025 LcFun. All rights reserved.
