Alat Urut Kaki KNQZE dengan Haba dan Alat Kawalan Jauh (Model KF9) - Manual Pengguna

pengenalan

Thank you for choosing the KNQZE Foot Massager, Model KF9. This device is designed to provide a comprehensive foot massage experience, incorporating 3D kneading, shiatsu rollers, 360° full-wrapped air compression, and adjustable heat. This manual provides essential information for safe operation, setup, maintenance, and troubleshooting to ensure optimal performance and user satisfaction.

Maklumat Keselamatan

Please read all safety instructions carefully before using the KNQZE Foot Massager. Failure to follow these instructions may result in injury or damage to the device.

• May cause burns if used for extended periods at high heat settings.
• Avoid use if you have a blood clotting disorder, deep vein thrombosis, or are pregnant.
• Jangan gunakan pada kulit yang luka atau luka terbuka.
• Jauhkan daripada air.
• Cabut pijat semasa tidak digunakan.
• Always follow the instructions in this user manual.
• This foot massager accommodates up to men's size 12. It is not suitable for wider or larger feet.

Kandungan Pakej

Sahkan bahawa semua item terdapat dalam pakej:

• 1x KNQZE Foot Massager Machine (Model KF9)
• 1x Kawalan Jauh Tanpa Wayar
• 1x UL Listed Power Adapter
• 1x Manual Pengguna

Rajah 1: Package contents of the KNQZE Foot Massager, including the main unit, remote, power adapter, and user guide.

Ciri & Kawalan Produk

The KNQZE Foot Massager offers multiple features for a personalized massage experience:

• 3D Kneading & Shiatsu Rollers: Provides deep tissue massage to the soles and arches of the feet.
• 360° Air Compression: Full-wrapped air compression with adjustable intensities (OFF/L/M/H) for comprehensive foot relaxation.
• Fungsi Haba: 3 adjustable heat levels (113°F, 122°F, 131°F) to improve circulation and relieve muscle soreness.
• Tetapan Pemasa: 3 timer options (15/20/30 minutes) for customized session durations.
• Wireless Remote Control & LCD Touchscreen: Allows for easy adjustment of settings without bending over. The illuminated display ensures clear navigation.

Rajah 2: KNQZE Foot Massager control panel and foot inserts.

Rajah 3: Wireless remote control for convenient operation.

Rajah 4: Professional Shiatsu Massage zones and techniques.

Persediaan

1. Bongkar: Keluarkan pengurut kaki dan semua aksesori dari bungkusan dengan berhati-hati.
2. penempatan: Place the massager on a flat, stable surface near an electrical outlet. Ensure there is enough space for comfortable use.
3. Sambungkan Kuasa: Plug the UL Listed Power Adapter into the massager's power port, then plug the adapter into a standard electrical outlet.
4. Sediakan untuk Penggunaan: Ensure the removable foot covers are properly installed.

Arahan Operasi

The KNQZE Foot Massager can be operated using the integrated LCD touchscreen panel or the wireless remote control.

1. Hidupkan kuasa: Place your feet into the foot inserts. Press the kuasa button on the control panel or remote to turn on the device. The default session time is 15 minutes.
2. Adjust Kneading Intensity: Tekan ke Uli button to cycle through 3 levels of kneading massage (L/M/H) or turn it off. It is recommended to start at lower settings.
3. Adjust Air Compression Intensity: Tekan ke Udara button to cycle through 3 levels of air compression (L/M/H) or turn it off.
4. Laraskan Tahap Haba: Tekan ke Panas button to select from 3 heat levels (113°F, 122°F, 131°F) or turn it off.
5. Tetapkan Pemasa: Tekan ke Pemasa button to choose a session duration of 15, 20, or 30 minutes.
6. Matikan: The massager will automatically shut off after the selected timer duration. To manually turn off the device, press the kuasa butang.

Nota: For optimal comfort, ensure your feet are placed centrally within the foot inserts. The remote control allows for convenient adjustments without needing to reach the main unit.

Rajah 5: Easy operation with remote control and LCD touchscreen.

Penyelenggaraan

Regular cleaning and maintenance will prolong the life of your KNQZE Foot Massager.

• Membersihkan Bahagian Luar: The massager is crafted with upgraded water-resistant ABS material. Wipe the exterior with a soft, damp kain. Jangan gunakan pembersih yang melelas atau rendam unit di dalam air.
• Pembersihan Penutup Kaki: The internal foot covers are removable and machine-washable for superior hygiene. Unzip and remove the covers, then wash them according to fabric care instructions. Ensure they are completely dry before reattaching.
• Storan: Store the massager in a cool, dry place away from direct sunlight when not in use. Its compact design allows for easy storage under furniture or in a closet.

Rajah 6: Maintenance features: removable foot covers and water-resistant material.

Spesifikasi

Waranti dan Sokongan

The KNQZE Foot Massager comes with a one-year warranty. If you encounter any issues or have questions regarding your product, please reach out to customer support. Information on extending the warranty may be available through product registration or specific promotions.
