Micool DY20PLUS Bluetooth 5.4 Headset

pengenalan

Thank you for choosing the Micool DY20PLUS Bluetooth 5.4 Headset. This single-ear wireless headset is designed for clear communication and extended use, featuring advanced noise cancellation and long battery life. This manual provides detailed instructions to help you get the most out of your device.

Image: The Micool DY20PLUS Bluetooth 5.4 Headset, showcasing its sleek black and gold design with an ear hook and LED battery indicators.

Apa yang ada dalam Kotak

Upon opening your Micool DY20PLUS package, you should find the following items:

• Micool DY20PLUS Bluetooth Headset
• Kabel Pengecas USB-C
• Manual Pengguna
• Eartips Tambahan (pelbagai saiz)

Persediaan

1. Mengecas Alat Dengar

Before first use, fully charge your headset. The Micool DY20PLUS features a Type-C charging port for convenience.

• Sambungkan kabel pengecas USB-C yang disediakan ke port pengecasan set kepala.
• Sambungkan hujung kabel yang satu lagi ke sumber kuasa USB yang serasi (cth, penyesuai dinding, port USB komputer).
• Pengecasan penuh mengambil masa kira-kira 1.5 hingga 2 jam.
• The LED Power Display Light on the headset indicates the remaining battery level. There are four levels, with each grid representing 25% of the battery. Double-click the Volume+ button to check the remaining power.

Image: Visual representation of the headset's quick charge capability, showing that 10 minutes of charging provides 4 hours of continuous use.

2. Berpasangan dengan Peranti Anda

The DY20PLUS uses Bluetooth 5.4 for a stable and efficient connection.

1. Pastikan set kepala dicas dan dimatikan.
2. Press and hold the Multi-Function Button (MFB) on the headset for more than 3 seconds until the indicator light flashes, indicating it's in pairing mode.
3. Pada peranti anda (telefon pintar, tablet, komputer), dayakan Bluetooth dan cari peranti yang tersedia.
4. Select "DY20PLUS" from the list of found devices to connect.
5. Sebaik sahaja berjaya dipasangkan, lampu penunjuk akan berhenti berkelip.

The headset offers a wireless connection distance of up to 50 meters (150 feet) in a straight line and can be connected to two devices simultaneously, allowing you to seamlessly switch between music and calls.

Image: A person wearing the headset, illustrating the 150 feet / 50 meters wireless range and seamless Bluetooth connectivity.

Arahan Operasi

Biasakan diri anda dengan kawalan alat dengar untuk penggunaan yang optimum.

Fungsi Butang:

Image: A detailed diagram showing the location and function of each button on the Micool DY20PLUS headset, including the Multi-Function Button (MFB), volume controls, and mute button.

• Hidupkan/Mati Kuasa: Press and hold the MFB for >3 seconds.
• Main/Jeda Muzik: One-tap the MFB.
• Jawab/Tamatkan Panggilan: One-tap the MFB.
• Tolak Panggilan: Press and hold the MFB for >2 seconds.
• Aktifkan Pembantu Suara (Siri/Google Assistant): Double-tap the MFB.
• Tukar Lagu: Press Volume+ for 2 seconds for next song, Volume- for 2 seconds for previous song.
• Kawalan Kelantangan: Short press Volume+ to increase volume, short press Volume- to decrease volume.
• Fungsi Redam: Press the dedicated mute button for >2 seconds to mute/unmute your microphone during a call.
• Tukar Bahasa: Three-tap the MFB.
• Redial Last Outgoing Call: Three-tap the call button (MFB).

Ciri-ciri Utama

Advanced Noise Cancellation

The DY20PLUS headset is equipped with two microphones for noise reduction and omnidirectional silicon microphone technology. It filters out approximately 80% of external noise. An updated Bluetooth 5.4 version with an integrated digital noise reduction algorithm further enhances noise reduction by 30%, ensuring clearer calls even in noisy environments.

Image: An illustration demonstrating how the two noise-cancelling microphones work to block background noise and maintain clear call quality.

Jangka Hayat Bateri

The headset provides up to 36 hours of talk time and 45 hours of music playback on a single charge. With a standby time of 20 days, it's designed for long-lasting performance, suitable for extended meetings or travel.

Image: An illustration emphasizing the headset's 36+ hour talk time and 45 hours of music playback, designed to power through work calls and daily activities.

Comfortable and Lightweight Design

Weighing only 12 grams, the DY20PLUS is ultra-small and light. Its ergonomic design ensures a secure and comfortable fit for all-day wear without causing ear fatigue. The ear canal-mouth canal design is airtight and optimized for bass.

Image: A person wearing the headset, highlighting its 12g ultra-lightweight design and compatibility with various devices like laptops, computers, pads, and phones.

Keserasian Luas

The Micool DY20PLUS is compatible with a wide range of devices, including telephones, smart speakers, and cellphones, making it versatile for various communication needs.

Penyelenggaraan

• Pembersihan: Gunakan kain lembut dan kering untuk membersihkan set kepala. Elakkan menggunakan bahan kimia yang keras atau bahan yang melelas.
• Storan: Simpan alat dengar di tempat yang sejuk dan kering, jauh daripada suhu ekstrem dan cahaya matahari langsung.
• Tahan Air: The headset is water-resistant. However, avoid submerging it in water or exposing it to heavy rain for prolonged periods.
• mengecas: Always use the provided USB-C cable or a certified equivalent for charging to prevent damage.

Menyelesaikan masalah

Spesifikasi

Waranti dan Sokongan

For warranty information and customer support, please refer to the documentation included with your purchase or contact Micool customer service directly. Details can typically be found on the manufacturer's official webtapak atau melalui tempat pembelian anda.
