Manual Pengguna Lampu LED Berterusan Dwi-Warna DIGITEK® DCL-100 WBC 100W

pengenalan

Thank you for choosing the DIGITEK® DCL-100 WBC 100W Bi-Color Continuous LED Light. This professional lighting solution is designed for videography and photography, offering powerful illumination, versatile color temperature control, and innovative special effects. With its robust construction and user-friendly controls, the DCL-100 WBC is an essential tool for content creators seeking high-quality lighting. This manual provides detailed instructions for setup, operation, maintenance, and troubleshooting to ensure optimal performance and longevity of your device.

Figure 1: DIGITEK® DCL-100 WBC 100W Bi-Color Continuous LED Light.

Kandungan Pakej

Sila sahkan bahawa semua item yang disenaraikan di bawah disertakan dalam pakej anda. Jika ada item yang hilang atau rosak, sila hubungi sokongan pelanggan.

• DCL-100 WBC LED Light Unit
• Pemantul
• Silicon Diffuser
• Pegangan Pegangan
• Kabel Jenis C
• Sarung Bawa
• Power Adapter (Optional, may vary by region/bundle)

Rajah 2: Perwakilan visual kandungan pakej.

Ciri-ciri Produk

The DIGITEK® DCL-100 WBC LED Light is equipped with advanced features to enhance your creative workflow:

• Pencahayaan Kuat: Delivers 13000LM luminous flux with a high 97+ CRI value for accurate color rendering.
• Suhu Warna Serbaguna: Adjustable from 2700K to 6500K, plus 200 color temperature presets.
• Innovative FX Modes: Features 20 special effects including Paparazzi, Firework, Thunder Flash, and more.
• Robust and Durable Design: Constructed with high-strength aluminum alloy and durable engineering plastic.
• Efficient Power Options: Includes a 14.8V / 4500mAh Li-ion battery and supports DC power input.
• Kawalan Mesra Pengguna: Manual adjustments via knobs and buttons, or remote control via the Smartlife APP (up to 60 meters).
• Sistem Penyejukan Pintar: Integrated cooling fan and vents ensure optimal performance and prevent overheating.

Figure 3: Key technical specifications and capabilities of the DCL-100 WBC.

Figure 4: Internal cooling system with vents and an inbuilt fan for heat dissipation.

Persediaan

1. Membongkar: Carefully remove all components from the carry case.
2. Attaching Reflector/Diffuser: Align the reflector or silicon diffuser with the Mini Bowen Mount on the front of the LED light and twist to secure.
3. Pemasangan:
   • Attach the handle grip to the 1/4" mounting screw at the bottom of the light for handheld use.
   • For stand mounting, attach the light directly to a compatible light stand using the 1/4" screw thread.
4. Sambungan Kuasa:
   • To use with the included battery, ensure the battery is charged.
   • For continuous power, connect the power adapter to the DC Power Socket on the unit and plug into a wall outlet.
   • The unit also supports 30W PD Type-C charging.

Figure 5: Power input options and specifications.

Arahan Operasi

Panel Kawalan Terlaluview

Rajah 6: Depan view of the control panel and ports.

• Skrin LCD: Displays current settings such as brightness, color temperature, and FX mode.
• Suis kuasa: Menghidupkan / mematikan unit.
• Tombol Pemalap: Melaraskan kecerahan daripada 0% hingga 100%.
• Adjustment Knob (CCT/FX):
  • In CCT mode, rotates to adjust color temperature (2700K-6500K).
  • In FX mode, rotates to select different special effects.
• Butang Mod: Toggles between CCT (Color Temperature) mode and FX (Special Effects) mode.
• Bluetooth Connection Reset Button: Used to reset Bluetooth pairing for app control.
• Max Mode Button: Activates maximum brightness output.

Operasi Asas

1. Hidupkan/Mati Kuasa: Press the Power Switch to turn the light on or off.
2. Melaraskan Kecerahan: Rotate the Dimmer Knob to increase or decrease the light intensity.
3. Changing Color Temperature (CCT Mode):
   • Press the Mode button until "CCT" or a color temperature value is displayed on the LCD screen.
   • Rotate the Adjustment Knob (CCT/FX) to select your desired color temperature between 2700K and 6500K.
4. Using FX Modes:
   • Press the Mode button until "FX" or an effect name is displayed on the LCD screen.
   • Rotate the Adjustment Knob (CCT/FX) to cycle through the 20 available special effects (e.g., Paparazzi, Firework, Thunder Flash, Candle, Fault Bulb, SOS, Flame, Fade, Camp Fire, Bulb, Pulse, Lightning, TV, Explosion).

Gambar 7: Cthamples of special CCT effects for creative lighting.

Smartlife APP Control

The DCL-100 WBC can be controlled remotely via the Smartlife APP, offering extended range and precise adjustments.

1. Muat turun Aplikasi: Imbas kod QR di bawah atau layari smartapp.tuya.com/smartlife to download the Smartlife App for iOS or Android.
2. Berpasangan:
   • Pastikan Bluetooth didayakan pada peranti mudah alih anda.
   • Turn on the DCL-100 WBC.
   • Open the Smartlife App and follow the on-screen instructions to add a new device. The app should automatically detect the light. If not, press the Bluetooth Connection Reset button on the light.
3. Kawalan Jauh: Once paired, you can adjust brightness, color temperature, and select FX modes directly from your phone, up to 60 meters away.

Figure 8: Remote control via Smartlife App for seamless adjustments.

Penyelenggaraan

• Pembersihan: Gunakan kain lembut dan kering untuk membersihkan bahagian luar lampu. Jangan gunakan pembersih atau pelarut yang kasar.
• Storan: When not in use, store the light in its carry case in a cool, dry place, away from direct sunlight and extreme temperatures.
• Penjagaan Bateri: If using the internal battery, charge it regularly, even if not in use, to maintain battery health. Avoid fully discharging the battery for extended periods.
• Pengudaraan: Ensure the vents are clear of obstructions during operation to allow for proper cooling.

Menyelesaikan masalah

Spesifikasi

Waranti dan Sokongan

For warranty information, technical support, or service inquiries, please contact Digitek customer care:

• Bebas tol: 1800-123-544-444
• e-mel: support@digitek.net.in
• Pengeluar: IMS Merchantiles Pvt. Ltd

Sila simpan bukti pembelian anda untuk tuntutan waranti.
