Ulanzi HP004 Smartphone Mount Instruction Manual

1. Pengenalan

The Ulanzi HP004 Smartphone Mount is a versatile and portable accessory designed to securely hold your smartphone for various photography, videography, and viewing needs. Its foldable design, stable base, and multi-angle adjustment capabilities make it suitable for both professional and casual use. This manual provides detailed instructions for the proper setup, operation, and maintenance of your device.

Image 1.1: The Ulanzi HP004 Smartphone Mount, designed for photographers and general users.

2. Kandungan Pakej

Sila sahkan bahawa semua komponen terdapat dalam pakej anda:

• Ulanzi HP004 Crab Tripod Smartphone Mount
• Tool Wrench (Hex Key)
• Manual Arahan (dokumen ini)

Image 2.1: Contents of the Ulanzi HP004 package, including the mount and a tool wrench.

3. Arahan Persediaan

3.1 Unfolding the Mount

1. Gently unfold the base legs of the mount until they form a stable triangular stand.
2. Extend the main arm of the mount to your desired height and angle.

Image 3.1: The Ulanzi HP004 in its compact, folded state.

Image 3.2: The compact size of the Ulanzi HP004 when folded, demonstrating its portability.

3.2 Menyambungkan Telefon Pintar Anda

1. Locate the smartphone clamp di bahagian atas gunung.
2. Tarik perlahan-lahan penutup springamp to widen the opening.
3. Masukkan telefon pintar anda ke dalam clamp, ensuring it is centered and securely held by the rubberized grips. The clamp supports phones with a width of 6 to 9.5 cm (2.36 to 3.74 inches).

Image 3.3: A smartphone securely mounted in the Ulanzi HP004 in portrait mode.

3.3 Adjusting Angles

The Ulanzi HP004 features multiple articulation points for flexible angle adjustment:

• Base Hinge: Allows for forward and backward tilt of the main arm.
• Mid-Arm Hinge: Provides additional height and angle adjustments.
• Telefon Clamp Putaran: Telefon clamp can rotate 360 degrees for quick switching between portrait and landscape orientations.

Image 3.4: Diagram illustrating the multi-angle adjustment capabilities of the Ulanzi HP004.

3.4 Using Expansion Ports

The mount is equipped with several expansion options:

• 1/4-inch Screw Hole: Located at the base, this allows attachment to other tripods or accessories.
• Arca Slot: Integrated into the base for quick mounting on Arca-Swiss compatible tripod heads.
• Dual Cold Shoes: Two cold shoe mounts are available on the phone clamp for attaching accessories like fill lights or microphones.

Imej 3.5: Terperinci view of the Ulanzi HP004's versatility and expandability, highlighting its 1/4" screw hole, Arca slot, and cold shoe mounts.

4. Arahan Operasi

4.1 Desktop Stand Usage

For stable desktop use, ensure the base legs are fully extended and placed on a flat, stable surface. Adjust the arm and phone clamp to achieve your desired viewing angle for video calls, content consumption, or recording.

Image 4.1: The Ulanzi HP004 functioning as a desktop stand with a smartphone in landscape orientation.

Image 4.2: The Ulanzi HP004 holding a smartphone in portrait orientation on a desk.

4.2 Handheld Usage

When folded, the Ulanzi HP004 can be used as a compact handheld grip for vlogging or mobile photography. Ensure the mount is securely held to prevent accidental drops.

4.3 Aplikasi Pelbagai Senario

The Ulanzi HP004 is designed for various applications, including:

• Desktop viewing dan rakaman
• Attaching to larger tripods for elevated shots
• Handheld vlogging or mobile photography
• Live streaming with external accessories (light, microphone)

Image 4.3: A collage demonstrating various usage scenarios for the Ulanzi HP004, including desktop, handheld, and mounted on a larger tripod.

5. Penyelenggaraan

5.1 Pembersihan

To clean the Ulanzi HP004, wipe it with a soft, dry cloth. For stubborn dirt, a slightly damp cloth can be used. Avoid using harsh chemicals or abrasive materials, as these may damage the finish or rubberized grips.

5.2 Penyimpanan

When not in use, fold the mount into its compact form and store it in a dry, cool place away from direct sunlight and extreme temperatures. This helps preserve the integrity of the materials and moving parts.

6. Penyelesaian masalah

6.1 Mount is unstable

• Ensure the base legs are fully extended and locked into position.
• Verify that the surface on which the mount is placed is flat and stable.
• Check that your smartphone is properly centered in the clamp.

Image 6.1: The stable structure of the Ulanzi HP004, featuring a base split-leg design for enhanced stability.

6.2 Phone not fitting in clamp

• Confirm your phone's width is within the supported range of 6-9.5 cm (2.36-3.74 inches).
• Ensure you are fully extending the spring-loaded clamp before inserting the phone.

6.3 Difficulty adjusting angles

• The hinges are designed to provide moderate damping for stable positioning. Apply gentle, firm pressure when adjusting.
• If any hinge feels excessively stiff, ensure no debris is obstructing the mechanism.

7. Spesifikasi

8. Maklumat Waranti

The Ulanzi HP004 Smartphone Mount comes with a Waranti terhad 1 tahun dari tarikh pembelian. Waranti ini meliputi kecacatan pembuatan dan mutu kerja di bawah penggunaan biasa. Ia tidak melindungi kerosakan yang disebabkan oleh penyalahgunaan, kemalangan, pengubahsuaian yang tidak dibenarkan atau haus dan lusuh biasa. Sila simpan bukti pembelian anda untuk tuntutan waranti.

9. Sokongan Pelanggan

For technical assistance, warranty claims, or general inquiries regarding your Ulanzi HP004 Smartphone Mount, please contact Ulanzi customer support through the official website or your retailer's support channels. When contacting support, please have your product model (HP004) and proof of purchase available.
