GreenLaw GreenLaw Surface Pro 9 Keyboard
GreenLaw Bluetooth Keyboard for Surface Pro 9/8/X (13-inch) - Instruction Manual
Model: GreenLaw Surface Pro 9 Keyboard | Brand: GreenLaw
pengenalan
This manual provides comprehensive instructions for the setup, operation, and maintenance of your GreenLaw Bluetooth Keyboard. This keyboard is designed for use with Microsoft Surface Pro 9, Surface Pro 8, and Surface Pro X 13-inch models, offering enhanced functionality and protection.
Image: The GreenLaw Bluetooth Keyboard seamlessly integrated with a Microsoft Surface Pro tablet, showcasing its use as a laptop replacement.
Keserasian
The GreenLaw Bluetooth Keyboard is compatible with the following Microsoft Surface models:
- Surface Pro 9
- Surface Pro 8
- Surface Pro X
Nota: This keyboard is not compatible with Surface Pro 7+, Surface Pro 7, Surface Pro 6, Surface Pro 5, Surface Pro 4, Surface Pro 3, or Surface Go models.
Image: A visual guide illustrating the compatible and incompatible Microsoft Surface Pro models for the keyboard.
Ciri-ciri Utama
- Multi-Gesture Touchpad: Microfiber touch panel with intelligent core design for efficient navigation and simplified operations.
- Lampu Belakang 7 Warna: Adjustable 3 brightness levels and 7 color options for enhanced visibility in various lighting conditions.
- Kesambungan Bluetooth 5.1 Tanpa Wayar: Stable long-distance connection (up to 10 meters) allowing separate use of keyboard and tablet.
- Reka bentuk Ultra-Slim: Lightweight and ergonomic keys with 7° tilt support to reduce typing pressure and wrist fatigue.
- Bahan Mesra Kulit: Faux microfiber fabric provides protection for the tablet screen and is dirt-resistant.
Panduan Persediaan
1. Pengecasan Awal
Before first use, ensure the keyboard is fully charged. Connect the provided USB-C charging cable to the keyboard's charging port and a power source. The battery indicator will show charging status.
Imej: A terperinci view of the USB-C charging port on the keyboard, indicating where to connect the charging cable.
2. Attaching Your Tablet
The keyboard features a magnetic attachment for easy connection to your Surface Pro. Align the bottom edge of your Surface Pro with the magnetic strip on the keyboard and allow it to snap into place.
Image: A user demonstrating the magnetic attachment of the Surface Pro tablet to the keyboard, forming a laptop-like setup.
3. Berpasangan Bluetooth
- Flip the power switch on the right side of the keyboard to the "ON" position. The indicator light will turn on.
- Tekan ke "Fn" + "C" keys simultaneously to enter Bluetooth pairing mode. The Bluetooth indicator will flash.
- Pada Surface Pro anda, pergi ke Settings > Bluetooth & devices.
- Pilih "Tambah peranti" dan pilih "Bluetooth".
- Cari "Papan Kekunci Bluetooth" in the list of available devices and click to connect. The indicator light will stop flashing once connected.
Video: A step-by-step demonstration of how to connect the Bluetooth keyboard to a Microsoft Surface tablet, including activating pairing mode and selecting the device in settings.
Arahan Operasi
Fungsi Papan Kekunci
- Kawalan Lampu Latar: Tekan "Fn" + "Shift" to adjust the 3 brightness levels or cycle through the 7 available colors.
- Kekunci Fungsi: The top row of keys (F1-F12) can be used for multimedia control or standard function keys. Refer to the key legends for specific actions.
- Pad sentuh: The integrated multi-gesture touchpad supports various gestures for navigation and control.
Image: A user interacting with the multi-gesture touchpad, highlighting its functionality for precise control.
Image: The keyboard's keys glowing with a vibrant 7-color backlight, demonstrating its visibility in low-light conditions.
Gerak Isyarat Pad Sentuh
The touchpad supports various multi-finger gestures for efficient navigation:
- Ketukan satu jari: Klik kiri.
- Ketik dua jari: Klik kanan.
- Tatal dua jari: Tatal ke atas/bawah atau kiri/kanan.
- Cubit untuk zum: Zum masuk / keluar.
- Leret ke atas dengan tiga jari: Buka Tugas View (Windows).
- Three-finger swipe down: Show desktop (Windows).
- Leret tiga jari ke kiri/kanan: Switch between open applications (Windows).
Penyelenggaraan
- Pembersihan: Gunakan kain lembut dan kering untuk membersihkan permukaan papan kekunci. Untuk kotoran degil, sedikit damp cloth can be used, ensuring no moisture enters the key gaps or ports.
- Storan: When not in use, close the keyboard cover to protect the tablet screen and keyboard from dust and scratches.
- Penjagaan Bateri: To prolong battery life, avoid fully discharging the keyboard frequently. Charge it regularly, especially if it will not be used for an extended period.
Menyelesaikan masalah
| Masalah | Penyelesaian |
|---|---|
| Papan kekunci tidak bersambung melalui Bluetooth. |
|
| Backlight not working or stuck on one color. |
|
| Touchpad is unresponsive. |
|
Spesifikasi
- Dimensi Produk: 12.4 x 9.28 x 0.4 inci
- Berat Barang: 1.23 paun
- Teknologi Ketersambungan: Bluetooth 5.1
- Bateri: 1 bateri Polimer Litium (termasuk)
- Ciri Khas: Backlit, Lightweight, Multi-Gesture Trackpad
- warna: Grey (RGB backlighting)
- Pengeluar: GreenLaw
- Nombor Model: GreenLaw Surface Pro 9 Keyboard
Waranti dan Sokongan
For warranty registration and product support, please refer to the documentation included with your product or contact GreenLaw customer service. If you encounter any difficulties or have inquiries, please do not hesitate to reach out to us at your earliest convenience.
For the quickest and most efficient support experience, please contact us directly through Amazon or via the provided contact information in your product packaging.
Sumber Tambahan
Produk Selesaiview Video
Video: An official product video from the seller showcasing the Microsoft Surface Pro 11 / Pro 10 / Pro 9 / Pro 8 / Pro X keyboard, highlighting its features and compatibility.
