Chuboor Air Purifier Replacement Filter Instruction Manual

1. Pengenalan

This manual provides essential information for the proper use, installation, and maintenance of your Chuboor 3-in-1 True HEPA Replacement Filter. This filter is specifically designed for Chuboor PJ01 and PJ08 Air Purifiers to ensure optimal air quality in your home or office environment.

This image displays the Chuboor 3-in-1 True HEPA replacement filter, designed for optimal air purification. It features a cylindrical shape with a yellow pleated filter material, a black activated carbon layer visible at the top, and a sturdy white frame.

2. Ciri-ciri Produk

The Chuboor replacement filter features a comprehensive 3-in-1 filtration system designed to capture a wide range of airborne particles and odors:

• Pra-penapis: Captures large particles such as dust, lint, fibers, and pet fur, extending the life of the other filters.
• Penapis HEPA Benar H13: Traps 99.97% of airborne particles 0.3 microns in size, including pollen, dust mites, pet dander, and smoke particles.
• Penapis Karbon Teraktif: Absorbs various household odors from pets, cooking, smoke, and harmful VOCs (Volatile Organic Compounds).

This image illustrates the internal construction of the Chuboor filter, emphasizing its advanced sealing for a secure fit and the high-efficiency filtration materials used to capture airborne particles. It shows the pleated HEPA layer and the activated carbon layer.

This image visually compares the filtration effectiveness of a Chuboor filter (yellow) against a generic filter (gray). It highlights that Chuboor filters achieve 99.9% filtration for certain particles (like viruses) compared to 89% for generic filters, and 95% for other particles (like bacteria) compared to 85% for generic filters, demonstrating superior performance.

3. Spesifikasi

This image provides the precise measurements of the Chuboor replacement filter: 6.89 inches in diameter, 5.08 inches in height, and a top opening diameter of 4.53 inches. The filter weighs 0.42 lbs.

4. Installation (Filter Replacement Procedure)

To maintain optimal performance of your Chuboor Air Purifier, replace the filter according to the following steps:

1. Langkah 1: Matikan dan Cabut Palam. Before replacing the filter, ensure your air purifier is turned off and unplugged from the power outlet.
2. Step 2: Remove Top Cover. Gently twist and lift the top cover of the air purifier to expose the filter compartment.
3. Langkah 3: Buang Penapis Lama. Carefully lift the old filter out of the air purifier. Dispose of the used filter responsibly.
4. Step 4: Insert New Filter. Place the new Chuboor replacement filter into the compartment, ensuring it is seated correctly.
5. Step 5: Replace Top Cover. Align the top cover and twist it back into place until it is securely fastened.
6. Step 6: Reset Filter Indicator. Plug in the air purifier. Locate the filter reset button on the control panel (it may be flashing red). Press and hold the reset button for a few seconds until the indicator light turns off or changes color, signifying the filter has been reset.

This diagram outlines the four-step procedure for replacing the filter in your Chuboor air purifier. It shows how to remove the top cover, lift out the old filter, insert the new filter, and then reset the filter indicator on the control panel.

5. Penyelenggaraan

Regular filter replacement is crucial for maintaining the efficiency and effectiveness of your air purifier. The lifespan of the filter depends on air quality and usage frequency.

• Kekerapan Penggantian: We generally recommend replacing the filter every 2-3 months.
• Penunjuk Penapis: The air purifier is equipped with a filter reset button and an indicator light. When the filter needs to be replaced, this indicator will flash red.
• Pembersihan: The filter itself is not washable. Do not attempt to clean the HEPA or activated carbon layers with water or other liquids, as this can damage the filter and reduce its effectiveness.

6. Penyelesaian masalah

Jika anda menghadapi masalah selepas menggantikan penapis anda, pertimbangkan perkara berikut:

• Filter Indicator Still Flashing Red: Ensure you have pressed and held the filter reset button on the air purifier's control panel for the required duration (typically a few seconds) after installing the new filter. If the light persists, try unplugging the unit for 10 minutes and then plugging it back in and resetting again.
• Aliran Udara atau Bau berkurangan: If you notice reduced airflow or persistent odors shortly after replacement, verify that the new filter is correctly seated and that the air purifier's top cover is securely closed. Ensure you are using a genuine Chuboor replacement filter.

This image shows a white Chuboor air purifier alongside a new Chuboor replacement filter, illustrating the compatible components. The air purifier's display shows air quality readings, emphasizing the system's function.

7. Maklumat Keselamatan

• Always unplug the air purifier from the power outlet before attempting any filter replacement or maintenance.
• Do not wash or reuse the filter. The filtration media is designed for single-use and loses effectiveness when wet.
• Keep replacement filters in their sealed packaging until ready for use to maintain their integrity and effectiveness.
• Buang penapis terpakai mengikut peraturan pelupusan sisa tempatan.

8. Waranti dan Sokongan

Specific warranty details and direct support contact information for this replacement filter are not available in the provided product data. For warranty claims, technical support, or further inquiries, please refer to the original air purifier's user manual or visit the official Chuboor weblaman web untuk mendapatkan maklumat terkini.
