WZYBUTA DMX512 180W RGBW LED Stage Cahaya

1. Pengenalan

The WZYBUTA DMX512 180W RGBW LED Stage Light is a versatile lighting fixture designed for various entertainment and event settings. It features three continuously rotating lamp heads, each equipped with 12 RGBW 4-in-1 lamp beads, providing high-quality beam output and rich color saturation. This manual provides essential information for the safe and effective operation of your device.

Image 1.1: Various light effects produced by the WZYBUTA DMX512 LED Stage Light in different colors and patterns.

Image 1.2: The WZYBUTA DMX512 LED Stage Light creating dynamic lighting effects in both a bar environment and a lively party setting, highlighting its versatile application.

2. Arahan Keselamatan

• Keselamatan Elektrik: Always connect the device to a grounded power outlet. Ensure the power supply voltage matches the device's requirements. Disconnect power before cleaning or servicing.
• Pengudaraan: Ensure adequate ventilation around the unit to prevent overheating. Do not block ventilation openings. The integrated silent fan aids in heat dissipation.
• Perlindungan Mata: Elakkan pendedahan mata secara langsung kepada sumber cahaya, kerana ia boleh menyebabkan kerosakan mata.
• Pemasangan: For overhead or wall mounting, ensure the mounting surface and hardware can safely support the weight of the fixture. Professional installation is recommended for complex setups.
• Persekitaran: Do not expose the device to rain, moisture, or extreme temperatures. Use only in dry indoor locations.
• Penyelenggaraan: Refer to the maintenance section for proper cleaning and care. Do not attempt to repair the device yourself; contact qualified service personnel.

3. Kandungan Pakej

Sila semak kandungan bungkusan selepas diterima untuk memastikan semua item ada dan tidak rosak:

• 1 x Lampu Kepala Bergerak
• 1 x Kuasa Kuasa
• 1 x Manual Arahan
• 2 x Pendakap Pemasangan

Image 3.1: The complete packing list for the WZYBUTA DMX512 LED Stage Light, including the light, power cord, instruction manual, and two mounting brackets.

4. Persediaan dan Pemasangan

The WZYBUTA DMX512 LED Stage Light is designed for easy installation and is plug-and-play. It comes with mounting brackets for flexible placement options.

4.1 Pilihan Pemasangan

• Pemasangan Kekuda: Use the provided brackets to securely hang the light from a lighting truss.
• Pemasangan Dinding: The brackets allow for fixing the unit to a wall. Ensure the wall material can support the weight.
• Peletakan Lantai: The light can also be placed directly on the floor for uplighting or other effects.

Always ensure the fixture is stable and securely fastened to prevent accidental falls, which could cause injury or damage.

Image 4.1: The WZYBUTA DMX512 LED Stage Light with its main board, high precision optic lens, and heat dissipation area highlighted. Dimensions are provided: 33 cm height, 37 cm width, and 36 cm depth.

5. Mod Operasi

The WZYBUTA LED Stage Light offers four distinct operating modes to suit various performance and event requirements:

• DMX512 Mode (15CH): This professional control mode allows you to program multiple lights via a DMX console to create complex and synchronized light shows. Refer to the DMX channel chart in the full manual for detailed programming instructions.
• Mod Diaktifkan Bunyi: In this mode, the light reacts to ambient sound and music, creating dynamic effects that synchronize with the beat.
• Mod Automatik: The light cycles through pre-programmed patterns and color changes automatically, providing continuous visual effects without external control.
• Mod Tuan-Hamba: Connect two or more lights in series using DMX cables. Designate one unit as the 'Master' and the others as 'Slaves'. The slave units will then mimic the master unit's operation, allowing for synchronized lighting across multiple fixtures.

6. Penyelenggaraan

Regular maintenance ensures the longevity and optimal performance of your WZYBUTA LED StagCahaya.

6.1 Pembersihan

• Luaran: Use a soft, dry cloth to wipe down the exterior of the fixture. For stubborn dirt, a slightly damp Kain boleh digunakan, diikuti dengan kain kering.
• Kanta: Gently clean the optical lenses with a soft, lint-free cloth and a specialized lens cleaning solution to maintain beam clarity.
• Bukaan Pengudaraan: Periodically check and clean the ventilation openings and the heat dissipation fan to prevent dust buildup, which can hinder airflow and lead to overheating. The integrated high-quality silent fan is crucial for stable operation and extended lifespan.

6.2 Penyimpanan

When not in use for extended periods, store the light in a cool, dry place, away from direct sunlight and excessive dust. It is recommended to store it in its original packaging or a protective case.

Imej 6.1: Terperinci view of the WZYBUTA DMX512 LED Stage Light showing RGBW lamp beads, the heat dissipation fan, and X-axis/Y-axis rotation capabilities.

7. Penyelesaian masalah

If you encounter issues with your WZYBUTA LED Stage Light, refer to the following common troubleshooting steps:

• Tiada Kuasa:
  • Periksa sama ada kord kuasa disambungkan dengan kukuh pada kedua-dua lekapan dan soket kuasa.
  • Sahkan bahawa salur keluar kuasa berfungsi.
  • Periksa kord kuasa untuk sebarang kerosakan yang boleh dilihat.
• Tiada Output Cahaya:
  • Ensure the unit is receiving power.
  • Check the selected operating mode. If in DMX mode, ensure the DMX signal is present and correctly configured.
  • Verify that the brightness settings are not set to zero.
• Incorrect Movement/Effects:
  • In DMX mode, check your DMX controller settings and channel assignments.
  • In Master-Slave mode, ensure the master unit is functioning correctly and DMX cables are properly connected between units.
  • Reset the unit by disconnecting and reconnecting power.
• Terlalu panas:
  • Pastikan bukaan pengudaraan bersih daripada halangan.
  • Operate the light in an environment with adequate airflow.

Jika langkah ini tidak menyelesaikan isu ini, sila hubungi sokongan pelanggan untuk mendapatkan bantuan lanjut.

8. Spesifikasi Teknikal

Image 8.1: The EU Energy Label for the WZYBUTA ZQ02253EU, indicating an energy efficiency class of E and an energy consumption of 100 kWh per 1000 hours. More information can be found di sini.

9. Waranti dan Sokongan

WZYBUTA is committed to providing quality products and customer satisfaction. While specific warranty details are not provided in this manual, please retain your proof of purchase for any warranty claims.

If you have any questions during use, require technical assistance, or need to report an issue, please do not hesitate to contact WZYBUTA customer support. Refer to your purchase documentation or the retailer's webtapak untuk maklumat hubungan terkini.
