pengenalan
This manual provides essential information for the safe and efficient operation of your new Household Dehumidifier. This appliance utilizes advanced semiconductor refrigeration technology to effectively reduce humidity, preventing issues such as mold growth, electrical short circuits, and discomfort from damp environments. With a 1200ml water tank capacity and automatic shut-off, it is designed for convenience and continuous operation when connected to an external water pipe. Please read this manual thoroughly before use and retain it for future reference.
Arahan Keselamatan
Untuk memastikan operasi yang selamat dan mengelakkan kerosakan, sila patuhi langkah berjaga-jaga keselamatan berikut:
- Always connect the dehumidifier to a grounded power outlet with the correct voltage (100-240V).
- Do not operate the unit with a damaged power cord or plug. If damaged, contact customer support.
- Keep the dehumidifier away from heat sources, flammable materials, and direct sunlight.
- Ensure adequate air circulation around the unit. Do not block air inlets or outlets.
- Jangan rendam unit, kord kuasa, atau palamkan ke dalam air atau cecair lain.
- Always unplug the dehumidifier before cleaning, performing maintenance, or when not in use for extended periods.
- Do not allow children or individuals with reduced physical, sensory, or mental capabilities to operate the appliance without supervision.
- Empty the water tank regularly to prevent overflow, especially if not using the external drainage pipe.
- Use only manufacturer-recommended accessories and replacement parts.
Produk Selesaiview
The Generic Household Dehumidifier is designed for efficient and quiet operation. Key features include:
- Semiconductor Refrigeration Technology: Enhanced condensation for effective moisture removal (500-600ml/24 hours).
- Tangki Air 1200ml: Kapasiti besar dengan penutupan automatik apabila penuh.
- External Water Pipe Option: Allows for continuous drainage without manual emptying.
- Paparan led: Front-mounted display for easy monitoring of functions.
- Kawalan Jauh: Operasi yang mudah dari jauh.
- Operasi senyap: Noise reduction turbine fan and bionic blades for low noise levels, suitable for bedrooms.
- Mod tidur: When activated, the LED display will turn off, and the fan speed will decrease to ensure a quiet environment for sleep.
- Pemasa 24 Jam: Schedule operation for convenience.
- Matikan Automatik: Unit powers off when the water tank is full or the timer expires.
Rajah 1: Dehumidifier unit with its remote control, illustrating convenient operation from a distance.
Rajah 2: Dalaman view highlighting the semiconductor refrigeration technology for efficient moisture condensation.
Rajah 3: Illustration of the noise reduction turbine fan and bionic blades, demonstrating the unit's quiet operation.
Persediaan
- Membongkar: Carefully remove the dehumidifier from its packaging. Retain all packaging materials for future transport or storage.
- penempatan: Place the dehumidifier on a flat, stable surface in the desired room. Ensure there is at least 20 cm (8 inches) of space around the air inlet and outlet for optimal airflow. Avoid placing it directly against walls or furniture.
- Sambungan Kuasa: Insert the power adapter into the dehumidifier's power port, then plug the adapter into a suitable grounded electrical outlet (100-240V).
- Pemasangan Tangki Air: Pastikan tangki air dipasang dengan betul di dalam unit. Unit ini tidak akan beroperasi jika tangki tidak dipasang dengan betul atau penuh.
- External Drainage (Optional): For continuous operation without manual emptying, connect the provided external water pipe to the drainage outlet on the unit. Ensure the pipe is routed downwards to a drain or larger container, allowing gravity to facilitate water flow.
Rajah 4: The dehumidifier with its 1200ml water tank and the connection point for the external drainage pipe.
Arahan Operasi
Once set up, operate your dehumidifier using the control panel or the remote control.
Panel Kawalan dan Alat Kawalan Jauh
- Butang Kuasa: Tekan untuk menghidupkan atau MATI unit.
- Butang Mod: Cycle through available operating modes (e.g., standard, sleep).
- Butang Pemasa: Set the 24-hour timer for automatic operation or shut-off. Press repeatedly to adjust the duration.
- Mod tidur: When activated, the LED display will turn off, and the fan speed will decrease to ensure a quiet environment for sleep.
Rajah 5: The dehumidifier in sleep mode, demonstrating the screen-off feature for nighttime use.
- Paparan led: Shows current settings and operational status.
Pemadaman Automatik
The dehumidifier will automatically power off when the 1200ml water tank is full. An indicator light may illuminate, and the unit will beep to signal that the tank needs to be emptied. The unit will resume operation once the tank is emptied and reinserted correctly.
Penyelenggaraan
Penyelenggaraan tetap memastikan prestasi optimum dan jangka hayat dehumidifier anda.
- Mengosongkan Tangki Air:
- When the water tank is full, the unit will stop operating.
- Tarik keluar tangki air dari unit dengan berhati-hati.
- Press in the specified direction to open the lid.
- Tuangkan air yang terkumpul.
- Close the lid and reinsert the tank firmly into the dehumidifier.
Rajah 6: Step-by-step guide for removing, emptying, and reinserting the water tank.
- Membersihkan Tangki Air: Periodically clean the water tank with mild soap and warm water to prevent mold and bacterial growth. Rinse thoroughly and dry before reinserting.
- Cleaning the Air Filter (if applicable): While not explicitly mentioned, most dehumidifiers have an air filter. If your model includes one, gently remove it and clean it with a soft brush or vacuum cleaner. If washable, rinse with water, dry completely, and reinsert. Refer to visual inspection for filter location.
- Pembersihan Luaran: Lap bahagian luar dehumidifier dengan lembut, damp kain. Jangan gunakan pembersih atau pelarut yang melelas.
- Storan: If storing the unit for an extended period, ensure the water tank is empty and clean. Unplug the unit, coil the power cord neatly, and store it in a cool, dry place.
Menyelesaikan masalah
Sebelum menghubungi sokongan pelanggan, sila rujuk isu dan penyelesaian biasa berikut:
| Masalah | Kemungkinan Punca | Penyelesaian |
|---|---|---|
| Dehumidifier tidak dihidupkan. | No power supply; power cord loose; water tank not properly installed or full. | Check power connection and outlet. Ensure water tank is empty and correctly seated. |
| Tiada air yang terkumpul atau penyahlembapan yang rendah. | Room humidity too low; ambient temperature too low; air inlets/outlets blocked; unit too small for room size. | Ensure room humidity is above 40% RH and temperature is above 5°C (41°F). Clear any obstructions. Consider if the unit is appropriate for the space. |
| Unit mengeluarkan bunyi yang luar biasa. | Unit bukan pada permukaan yang stabil; isu komponen dalaman. | Letakkan unit pada permukaan yang rata dan stabil. Jika bunyi bising berterusan, hubungi sokongan pelanggan. |
| Air bocor dari unit. | Water tank not properly installed; external drainage pipe loose or blocked. | Re-seat the water tank. Check external drainage pipe connection and ensure it's not kinked or blocked. |
Spesifikasi
| Ciri | Perincian |
|---|---|
| Jenama | Generik |
| Model | 22W |
| kuasa | 22W |
| Voltage | 100-240V |
| Kapasiti Tangki Air | 1200ml (maksimum) |
| Kadar Penyahlembapan | 500-600ml/day (at 30℃, 80%RH) |
| Covering Area | 10-20 meter persegi |
| Berat Barang | 1.6 kg (3.52 paun) |
| Dimensi | 11.42 x 8.27 x 5.51 inci (Saiz Pakej) |
| Ciri Khas | Quiet Operation, Sleep Mode, Timer, Remote Control, LED Display, Automatic Power Off, External Water Pipe Connection |
Rajah 7: Illustration of the dehumidifier's low power consumption, highlighting its energy-saving design.
Waranti dan Sokongan
Your Generic Household Dehumidifier is designed for reliability and performance. If you encounter any issues or require assistance, please contact our customer support team.
- Perkhidmatan Pelanggan: For any problems or inquiries, please contact us via email. We aim to respond and resolve issues within 24 hours.
- Maklumat Produk: For more styles or product variations, please refer to the seller's store (JSSSLC).
