1. Pengenalan
Thank you for choosing the iWALK DBL5000PC Portable USB-C Power Bank. This compact and powerful device is designed to provide convenient and fast charging for your USB-C compatible smartphones and other devices, ensuring you stay connected wherever you go. Please read this manual carefully before use to ensure optimal performance and safety.
2. Maklumat Keselamatan
- Jangan dedahkan bank kuasa kepada suhu yang melampau, cahaya matahari langsung atau api.
- Elakkan daripada menjatuhkan, memukul atau membuka peranti.
- Jauhkan daripada kanak-kanak.
- Do not use the power bank if it is damaged or appears to be swelling.
- Gunakan hanya kabel pengecasan dan penyesuai yang diperakui.
- Lupuskan bank kuasa secara bertanggungjawab mengikut peraturan tempatan.
3. Produk Lebihview
The iWALK DBL5000PC is a compact 4,800mAh power bank featuring an integrated USB-C connector for direct device charging and 18W PD fast charging capabilities. It includes a digital display to show the remaining battery percentage.
Image: The iWALK DBL5000PC portable USB-C power bank in pink, showcasing reka bentuknya yang padat.
3.1 Ciri-ciri Utama
- Built-in USB-C Connector: Directly plugs into your device for cable-free charging.
- Kapasiti 4,800mAh: Provides significant power for smartphones.
- Pengecasan Pantas PD 18W: Supports rapid charging for both the power bank and connected devices.
- Paparan Digital: Menunjukkan peratusan bateri yang tepattage.
- Padat & Ringan: Direka untuk mudah alih dan mudah dibawa.
3.2 Keserasian
This power bank is compatible with a wide range of USB-C devices, including:
- iPhone 15/16/17 Series (Pro/Max/Plus)
- Samsung Galaxy S25/S24/S23/S22/S21/S20/S10, Note 22/21/10/9, Z Flip/Fold series
- Google Pixel 8/7/6/5
- LG G7/V30/V40
- Motorola, OnePlus, and other USB-C phones
- iPad Pro/Air/Mini (USB-C models)
Image: A detailed compatibility chart illustrating various smartphone and tablet models that can be charged with the iWALK power bank.
4. Kandungan Pakej
Upon opening your iWALK DBL5000PC package, you should find the following items:
- iWALK 4,800mAh Power Bank (x1)
- Kabel USB-C ke USB-C (x1)
- Manual Arahan (x1)
Image: The iWALK power bank, a USB-C charging cable, and the welcome guide, as included in the product package.
5. Sediakan dan Mengecas Power Bank
Before using your iWALK power bank to charge other devices, it is recommended to fully charge the power bank itself.
- Sambungkan Kabel USB-C: Use the provided USB-C to USB-C cable. Plug one end into the USB-C input port on the side of the power bank.
- Sambungkan ke Sumber Kuasa: Palamkan hujung kabel USB-C yang satu lagi ke dalam penyesuai dinding USB yang serasi (tidak disertakan) atau port USB-C komputer.
- Pengecasan Monitor: The digital display on the power bank will show the charging progress, indicating the battery percentage.
- Petunjuk Caj Penuh: The display will show 100% when the power bank is fully charged. A full recharge takes approximately 1.5 hours with 18W PD fast recharging.
Image: Illustration of the iWALK power bank being recharged, showing both a direct plug into a wall adapter and a wired connection via USB-C cable.
6. Operating Instructions (Charging Your Device)
The iWALK DBL5000PC offers convenient, cable-free charging for your USB-C devices.
- Tanggalkan Penutup Pelindung: Gently remove the protective cap from the built-in USB-C connector.
- Sambung ke Peranti: Plug the built-in USB-C connector directly into your smartphone or other compatible device's USB-C port.
- Mulakan Pengecasan: The power bank should automatically begin charging your device. The digital display will show the power bank's remaining charge.
- Status Pengecasan: Your device's screen will indicate that it is charging.
- Putuskan sambungan: Once your device is charged, or you wish to stop charging, simply unplug the power bank from your device and replace the protective cap.
Image: A pink iWALK power bank directly plugged into the bottom of a smartphone, actively charging the device.
Image: A woman holding a smartphone with the iWALK power bank attached, demonstrating how the compact design allows for continued phone use during charging.
7. Paparan Digital
The iWALK DBL5000PC features a clear digital display that shows the remaining battery percentage of the power bank. This allows you to easily monitor its charge level and know when it needs to be recharged.
Imej: Dari dekat view of the iWALK power bank, highlighting its digital display which shows the current battery percentage.
8. Penyelenggaraan dan Penjagaan
- Bersihkan bank kuasa dengan kain lembut dan kering. Jangan gunakan bahan kimia yang keras atau bahan yang melelas.
- Simpan power bank di tempat yang sejuk dan kering, jauh dari cahaya matahari langsung dan kelembapan.
- Jika tidak digunakan untuk tempoh yang lama, cas bank kuasa sekurang-kurangnya sekali setiap tiga bulan untuk mengekalkan kesihatan bateri.
- Ensure the protective cap is always on the USB-C connector when not in use to prevent dust and damage.
9. Penyelesaian masalah
| Masalah | Kemungkinan Punca | Penyelesaian |
|---|---|---|
| Power bank tidak dicas | Low battery; faulty cable/adapter; loose connection | Ensure cable is securely connected; try a different cable/adapter; allow sufficient time for charging. |
| Peranti tidak dicas | Power bank low/empty; device incompatibility; loose connection | Recharge power bank; verify device compatibility; ensure power bank is firmly plugged into device. |
| Pengecasan perlahan | Non-PD compatible adapter; device drawing high power | Use an 18W PD compatible wall adapter for faster charging; avoid using the device heavily while charging. |
| Paparan digital tidak berfungsi | Power bank completely discharged; internal fault | Charge the power bank for a few minutes; if issue persists, contact customer service. |
10. Spesifikasi
| Ciri | Perincian |
|---|---|
| Nombor Model | DBL5000PC |
| Kapasiti Bateri | 4800 Miliamp jam |
| Jenis Penyambung | USB Jenis C (Terbina Dalam) |
| Kelajuan Mengecas | Pengecasan Pantas PD 18W |
| Dimensi Produk | 1.02 x 2.3 x 1.02 inci |
| Berat Barang | 0.24 auns |
| Ciri Khas | Auto Shut-Off, Digital Display, Fast Charging, Pocket Size, Slim |
| Pengeluar | U2O GLOBAL CO., LTD. |
11. Waranti dan Sokongan
Your iWALK DBL5000PC Power Bank comes with a standard manufacturer's warranty. For specific warranty details, please refer to the documentation included in your product packaging or visit the official iWALK webtapak.
For any questions, technical support, or customer service inquiries, please contact iWALK customer service. The product includes 7x24 customer service.
Maklumat Hubungan:
- Refer to your product packaging for the most up-to-date contact details.
- Visit the official iWALK weblaman web untuk sumber sokongan dan Soalan Lazim.
