Manual Arahan Ketuhar Penggoreng Udara LLIVEKIT 12L

1. Pengenalan

Thank you for choosing the LLIVEKIT 12L Air Fryer Oven. This appliance is designed to provide a healthier way to cook your favorite meals with less oil, utilizing rapid hot air circulation. Please read this manual thoroughly before operating the appliance and retain it for future reference. Proper use and maintenance will ensure years of delicious results.

2. Arahan Keselamatan Penting

AMARAN: Untuk mengelakkan kejutan elektrik, kebakaran atau kecederaan, sentiasa ikuti langkah berjaga-jaga keselamatan asas apabila menggunakan peralatan elektrik.

• Baca semua arahan sebelum digunakan.
• Jangan rendam unit utama dalam air atau cecair lain.
• Pastikan voltage yang ditunjukkan pada perkakas sesuai dengan sumber listrik tempatan andatage sebelum menyambung.
• Jauhkan perkakas dan kordnya daripada jangkauan kanak-kanak.
• Jangan kendalikan sebarang perkakas dengan kord atau palam yang rosak.
• Always unplug the appliance when not in use and before cleaning. Allow it to cool down completely before handling.
• Do not place the appliance against a wall or other appliances. Leave at least 10 cm of free space on the back, sides, and above the appliance.
• Jangan letakkan apa-apa di atas perkakas.
• Jangan gunakan perkakas untuk sebarang tujuan selain daripada yang diterangkan dalam manual ini.
• Exercise extreme caution when removing the drip tray or handling hot accessories.
• Perkakas beroperasi pada suhu tinggi. Jangan sentuh permukaan panas. Gunakan pemegang atau tombol.
• Ensure food is cooked thoroughly.

3. Produk Lebihview dan Komponen

The LLIVEKIT 12L Air Fryer Oven is a versatile kitchen appliance designed for various cooking methods, including air frying, roasting, baking, and dehydrating. It features a large capacity and a user-friendly digital touch screen.

Rajah 3.1: The LLIVEKIT 12L Air Fryer Oven shown with its primary accessories, including the rotisserie spit, rotating basket, and mesh trays. This image illustrates the appliance's capacity and the range of cooking options it supports.

Rajah 3.2: A terperinci view of the seven accessories provided with the air fryer. These include a rotisserie spit, rotating basket, skewer set, two mesh trays, a drip tray, and a rotisserie handle, enabling diverse cooking applications.

Komponen Utama:

• Unit Utama: Menempatkan elemen pemanas, kipas dan panel kawalan.
• Digital LED Touch Screen: For selecting cooking functions, adjusting time and temperature.
• Viewdalam Tetingkap: Membolehkan pemantauan kemajuan memasak tanpa membuka pintu.
• Lampu Dalaman: Menerangi ruang memasak untuk penglihatan yang lebih baik.
• pintu: Front-opening door with a secure latch.

Aksesori yang disertakan:

• Rotisserie Spit: Untuk memanggang ayam keseluruhan atau potongan daging yang besar.
• Bakul Berputar: Ideal for fries, nuts, or other small items that benefit from tumbling.
• Skewer Set: Untuk menyediakan kebab.
• Mesh Trays (x2): For multi-level cooking and air circulation.
• Dulang Drip: Collects excess oil and food particles for easy cleaning.
• Pemegang Rotisserie: For safe removal of the rotisserie spit and rotating basket.

4. Persediaan Awal

1. Bongkar: Keluarkan semua bahan pembungkusan dan aksesori dengan berhati-hati.
2. Bersih: Lap bahagian luar unit utama dengan iklanamp cloth. Wash all accessories (mesh trays, drip tray, rotisserie parts, etc.) with warm, soapy water. Rinse thoroughly and dry completely.
3. Bau Penggunaan Pertama: During the first few uses, a slight odor may be present. This is normal and will dissipate. To minimize this, run the air fryer empty for about 10-15 minutes at 200°C (390°F) before cooking food. Ensure good ventilation.
4. penempatan: Place the appliance on a stable, heat-resistant, and level surface. Ensure there is adequate space (at least 10 cm) around the unit for proper ventilation.

5. Arahan Operasi

The LLIVEKIT Air Fryer Oven features an intuitive digital touch screen for easy operation.

Rajah 5.1: The digital LED touch screen allows for precise control of cooking settings. Users can easily select pre-set functions or manually adjust temperature and time.

Rajah 5.2: Berakhirview of the 12 pre-set cooking functions available on the air fryer, including options for French Fries, Roast, Fish, Vegetables, Pizza, Chicken, Bake, Rotisserie, Dehydrate, Preheat, Reheat, and Frozen Food.

Panel Kawalan Terlaluview:

• Butang Kuasa: Hidupkan/matikan unit dan mulakan/jeda memasak.
• Kawalan Suhu (+/-): Melaraskan suhu memasak (80-200°C).
• Kawalan Masa (+/-): Adjusts cooking time (up to 90 minutes, 2 hours for Keep Warm).
• Pre-set Function Icons: Pilih daripada 12 mod memasak yang telah diprogramkan.
• Butang Rotisserie: Activates the rotisserie function for rotating accessories.
• Butang Cahaya: Menghidupkan/mematikan lampu dalaman.

Langkah Operasi Am:

1. Menyediakan makanan: Place food on the appropriate accessory (mesh tray, rotating basket, rotisserie spit).
2. Sisip Aksesori: Slide the accessory into the desired cooking position inside the oven. Ensure the drip tray is at the bottom.
3. Hidupkan kuasa: Plug the appliance into a grounded wall outlet. The power button will illuminate.
4. Pilih Fungsi: Press the power button to activate the display. Choose a pre-set function by tapping its icon, or manually set the temperature and time using the +/- buttons.
5. Mula Memasak: Press the power button again to start the cooking process.
6. Pantau: Gunakan viewing window and internal light to monitor food.
7. Selesai: The appliance will beep when cooking is complete. Carefully remove food using heat-resistant gloves and the rotisserie handle if applicable.

Menggunakan Aksesori:

• Mesh Trays: Insert into the side grooves. The air fryer supports 3 cooking positions, allowing simultaneous cooking of different items.
• Rotating Basket/Rotisserie Spit: Insert the shaft into the rotisserie drive socket on the left side and secure it with the screw on the right side. Press the rotisserie button on the control panel to activate rotation.

6. Panduan Memasak

The LLIVEKIT Air Fryer Oven uses 360° hot air circulation to cook food evenly and efficiently, resulting in crispy exteriors and juicy interiors with up to 85% less fat compared to traditional frying.

Rajah 6.1: Illustration of the 360° hot air circulation technology, which ensures even cooking and crispy results by distributing heat uniformly around the food.

Petua Umum:

• Prapemanasan: Untuk hasil terbaik, panaskan penggoreng udara selama 3-5 minit sebelum menambah makanan.
• Penggunaan minyak: While not required, a light spray of oil can enhance crispiness, especially for fresh vegetables or homemade fries.
• Goncang/Terbalik: For even cooking, shake the rotating basket or flip items on mesh trays halfway through the cooking time.
• Kesesakan: Avoid overcrowding the basket or trays. Cook in batches if necessary to ensure proper air circulation.
• Saiz Makanan: Cut food into uniform sizes for consistent cooking.

Example Cooking Settings:

7. Penyelenggaraan dan Pembersihan

Regular cleaning of your LLIVEKIT Air Fryer Oven will ensure optimal performance and extend its lifespan. All removable accessories are dishwasher safe for convenience.

Rajah 7.1: The image demonstrates that the air fryer's accessories, such as the drip tray, are dishwasher safe, simplifying the cleaning process after use.

Langkah Pembersihan:

1. Cabut dan Sejukkan: Sentiasa cabut plag perkakas dan biarkan ia sejuk sepenuhnya sebelum dibersihkan.
2. Unit Utama Bersih: Lap bahagian luar dengan iklanamp kain. Jangan gunakan pembersih atau penyental yang kasar.
3. Dalaman Bersih: Lap dinding dalaman dengan iklanamp cloth and mild detergent if necessary. For stubborn residue, a non-abrasive sponge can be used.
4. Aksesori Bersih: All removable accessories (mesh trays, rotating basket, rotisserie spit, drip tray) can be washed by hand with warm, soapy water or placed in the dishwasher.
5. Dulang Drip: Empty and clean the drip tray after each use to prevent grease buildup.
6. Storan: Pastikan semua bahagian bersih dan kering sebelum menyimpan perkakas di tempat yang sejuk dan kering.

8. Penyelesaian masalah

If you encounter any issues with your LLIVEKIT Air Fryer Oven, please refer to the following common problems and solutions:

9. Spesifikasi Teknikal

10. Waranti dan Sokongan Pelanggan

LLIVEKIT products are manufactured to high-quality standards. This product comes with a standard manufacturer's warranty. For specific warranty details, claims, or technical assistance, please refer to the warranty card included with your product or contact LLIVEKIT customer support through the retailer where you purchased the appliance.

For further inquiries or support, please visit the official LLIVEKIT store or contact their customer service department.
